TechniSat DigiCom 1 Operating Instructions Manual page 2

Power
LNB input
LNB output
Parallel
port
4-digit LED display
SERIAL PORT
TV
HF output
Serial port RS-232
Input terrestrial antenna
Scart socket Scart socket
AUX
AUDIO OUT
Outputs
audio analogue/digital
Scart socket
Channel
up/down
TV
TV
AC 230V
~ 50 Hz
MAX 29 VA
VCR
Mains
socket
VCR
V O R S I C H T !
E L E K T R O S C H O C K - G E F A H R
N I C H T Ö F F N E N !
C A U T I O N !
R I S K O F E L E C T R I C S H O C K
D O N O T O P E N !
POWER
ON/OFF
Mains switch
(POWER ON/OF)
