Sony Installation

Sony Projector Configuration

__________ Before changing anything, remove the AC power cord to the System 8/10 P
Config Model
as
Sony
_RS5 is for RGB switching
delay. See page 3-4 for
more information on switch
functions.
______ Secure the screws on all D connectors.
Extron • System 8/10 P
LUS
Verify that the System 8/10 P
The general setup is explained on page 3-4 and the switch settings for the
projector are repeated below.
1. Use a small screwdriver to remove the access cover from the System 8/10 P
front panel. See bottom of page 3-3. The label on the back of the access cover
also has the configuration information.
to verify that the main power is OFF; also turn the projector power OFF.
2. Set the switches as follows:
Rotary Switches Cable
RS1 RS2 RS3 RS4 J2/J3
0 0 5 3
RS2
RS5 RS2
RS1
3. Use a grease pencil (or other rub-off marker) to mark the space on the label next
to "Sony".
4. Locate the switcher's Address DIP switches on the rear panel, lower right.
Unless this is part of a master/slave system, set #3 and #5 to the up position and
the others down. See illustration to the left.
Use the illustration on the next page to do the following steps.
5. Connect the Comm Adapter's 9-pin male connector to the 9-pin female "Remote
1" connector on the rear panel of the projector.
6. Connect the CC-50' (or CC-100') cable from the 9-pin male connector of the
Comm Adapter to the 15-pin HD "Projector Control" port located on the rear
panel of the System 8/10 P
7. Connect the BNC (RGBS) cables from the System 8/10 P
Sony projector inputs according to the application requirements.
8. Apply Main Power to the System 8/10 P
Main Power LED should light. Apply power to the projector.
9. Return System 8/10 P
• User's Manual • P/N 68-408-01 Rev. A
Configuration and Connections
is already configured for the Sony projector.
LUS
SW15 Settings
1 2 3 4 5 6
J2
ON
SW15 DIP Switch
RS1
Configured For:
RS-232
.
LUS
by connecting the power cord. The
LUS
and projector to normal operation.
LUS
LUS
LUS
Comm
7 8 9 10 Adapter
26-312-01
¯
RS3
RS4
RS3 RS4
outputs to the
LUS
