Doyon AEF015 Owner's Manual

Spiral mixer
Hide thumbs Also See for AEF015:
Table of Contents

Advertisement

Quick Links

See also: Manual
ÉQUIPEMENT DOYON INC.
1255, rue Principale
Linière, Qc, Canada G0M 1J0
Tel.: 1 (418) 685-3431
Canada: 1 (800) 463-1636
US: 1 (800) 463-4273
FAX: 1 (418) 685-3948
Internet:
http://www.doyon.qc.ca
e-mail:
doyon@doyon.qc.ca
DOYON SPIRAL MIXER AEF 015/025/035/05x/08x/10x/15x
OWNER'S MANUAL
Product : ___________________________________
Serial number : ______________________

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AEF015 and is the answer not in the manual?

Questions and answers

Related Manuals for Doyon AEF015

Summary of Contents for Doyon AEF015

  • Page 1 1255, rue Principale Linière, Qc, Canada G0M 1J0 Tel.: 1 (418) 685-3431 Canada: 1 (800) 463-1636 US: 1 (800) 463-4273 FAX: 1 (418) 685-3948 Internet: http://www.doyon.qc.ca e-mail: doyon@doyon.qc.ca DOYON SPIRAL MIXER AEF 015/025/035/05x/08x/10x/15x OWNER’S MANUAL Product : ___________________________________ Serial number : ______________________...

  • Page 2: Table Of Contents

    DOYON SPIRAL MIXER AEF 015/025/035/05x/08x/10x/15x IMPORTANT SAFETY INSTRUCTIONS READ AND SAVE THESE INSTRUCTIONS DANGER TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, CAREFULLY FOLLOW THESE INSTRUCTIONS. TABLE OF CONTENTS TO GET THE BEST PERFORMANCE OF YOUR MACHINE, READ CAREFULLY THIS MANUAL.
  • Page 3 CHAPTER 5 – CLEANING 5.1. – When the machine is new..... . . ……. 5.2. – Every day ........CHAPTER 6 –...

  • Page 4: Chapter 1 - Reception Of The Merchandise

    Drawings, electrical diagram and replacement parts numbers are included in this manual. ATTENTION DOYON is not responsible for damages to the property or the equipment caused by personnel who is not certified by known organisations. SHIPPING For your safety, this equipment has been verified by qualified technicians and carefully crated before shipment.

  • Page 5: Important Safeguards

    IMPORTANT SAFEGUARDS Read all instructions. Remove plug from the outlet when the appliance is not in use, before putting on or taking off parts, and before cleaning. Do not use outdoors. Do not let cord hang over edge of table or counter or touch hot surfaces. Do not operate any appliance with a damaged cord or plug or after the appliance malfunctions or is dropped or damaged in any manner.

  • Page 6: Safety Instructions

    SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS • The machine must be used only for the functions that it has been conceived for. Doyon Equipment will not be responsible for the damages caused by an improper, bad or irrational use of the machine.

  • Page 7: General Description

    CHAPTER 2 GENERAL DESCRIPTION Doyon Spiral Mixers are designed to be used by qualified people in the Bakery production. The particular shapes and speeds of the spirals and bowls allow you to have in a short period of time, very smooth dough, even when small quantities of water are used. Our spiral mixers are able to work with small quantities of flour (for instance, the mixer of 220 Lbs.

  • Page 8: Chapter 2 – General Dimensions

    CHAPTER 3 TECHNICAL DATA 3.1 – GENERAL DIMENSIONS AND SPECIFICATIONS Fig.1 Dimensions and specifications of spiral mixers: Flour Capacity Dough Model Inch (cm) Inch (cm) Inch (cm) Lbs (kg) Capacity Lbs. (kg) AEF 015SP 41"(104) 29"(73.5) 16"(40.5) 2.2-33 (1-15) 3.5-50 (1.5-25) AEF 025SP 41.5"(105.4) 32.

  • Page 9: Technical Characteristics

    3.2. – TECHNICAL CHARACTERISTICS • Steel body. • Independent electric motors for stainless steel hook and bowl (except AEF015 & AEF025). • Belt driven transmission. • Two speeds on stainless steel hook. • Two speeds on stainless steel bowl. • Safety guard with micro switch.
  • Page 10 Figure # 2 Control panel Machine structure Security bars Spiral Bottom body Stainless steel bowl Machine floor fixer Roller Side board Main switch AEF-A.DOC 11/2011...

  • Page 11: Security System

    3.6 – SECURITY SYSTEM The potentially most dangerous area on these machines is the one that surrounds the moving spiral. So, there is a safety guard that obstructs the entry in this area. This safety guard is designed in a way to allow the user to watch the dough.

  • Page 12: Parts Description

    10. Electric cable / cord 11. Main switch Note: The AEF015 and AEF025 do not have part # 4, only the motor part # 3 to drive the hook and the bowl Note : on The AEF015SP and AEF025SP parts # 6, 7 and 8 are replace by a motor drive inverter.

  • Page 13: General Characteristics

    CHAPTER 4 DOYON SPIRAL MIXER AEF 015/025/035/05X/08X/10X/15X OPERATION .- GENERAL CHARACTERISTICS • Electric commands with two modes: manual or automatic mode. • 9 different program capacities. • In each program, you may adjust the time of work for the 1 and 2 speed.
  • Page 14 YOU WILL ALSO HAVE TO STUDY THE CONTROL PANEL. BUTTON 1. ON and OFF switch 2. Speed change (Manual Mode) 3. Start the machine, bowl motor and hook motor, simultaneously 4. Emergency STOP 5. Select automatic mode (AM) 6. Stops the machines bowl and hook motors simultaneously 7.
  • Page 15 GETTING STARTED : • Supply the machine according to the plate specifications • Turn the main switch into position I • Verify if the Emergency STOP button is unlocked • All displays stay ON during 2 seconds displaying number “8” •...

  • Page 16: Programming The Automatic Working Time

    4.5.- AUTOMATIC OPERATION (AUTOMATIC MODE) • When the machine in on Manual mode, press • If the machine in on Standby mode, press and after pulse • Close the safety guards. If you lift up the safety guards, the machine will stop immediately. •...

  • Page 17: How To Stop The Spiral Mixer

    4.7.- HOW TO STOP THE SPIRAL MIXER There are four different ways to switch off the spiral mixer: • Lift the safety guards. • Push the red stop button • Push the red emergency stop switch. • When in automatic mode, if the programmed time expires, the machine will stop automatically.

  • Page 18: When The Machine Is New

    CHAPTER 5 OPERATOR MAINTENANCE AND CLEANING Attention: Before doing maintenance and cleaning, switch off the machine with the main switch and unplug it, some operations might be dangerous. If you need to remove some protections, do not start working without them. 5.1.

  • Page 19: Every 6 Months

    To stretch it, it is necessary to call an authorised technician. 6.1.3 – SAFETY INSTRUCTIONS • The machine must be used only for the functions that it has been conceived for. Doyon Equipment will not be responsible for the damages caused by an improper, bad or irrational use of the machine.

  • Page 20: Every Year

    CHAPTER 7 7.1 – EVERY YEAR 7.1.1 – CONTROL OF THE STAINLESS STEEL BOWL Once a year, it is necessary to control the stainless steel bowl. Verify if the bowl has any damages. If you follow the procedures of 5.2., it is not normal that the bowl’s surface have damages, but if there are some, you should replace it.

  • Page 21: Limited Warranty

    The purchaser is responsible for having the equipment properly installed, operated under normal conditions with proper supervision and to perform periodic preventive maintenance. If any parts are proven defective during the period of one year from date of purchase, Doyon Equipment Inc. hereby guarantees to replace, without charge, F.O.B. Linière, Quebec, Canada, such part or parts.
