Doyon BTF080 Owner's Manual

Planetary mixer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ÉQUIPEMENT DOYON INC.
1255, rue Principale
Linière, Qc, Canada G0M 1J0
Tel.: 1 (418) 685-3431
Canada: 1 (800) 463-1636
US: 1 (800) 463-4273
FAX: 1 (418) 685-3948
Internet:
http://www.doyon.qc.ca
e-mail:
doyon@doyon.qc.ca
BTF080, 100, 120, 140
Product / Produit:
Serial number / Numéro de série:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BTF080 and is the answer not in the manual?

Questions and answers

Related Manuals for Doyon BTF080

Summary of Contents for Doyon BTF080

  • Page 1 1255, rue Principale Linière, Qc, Canada G0M 1J0 Tel.: 1 (418) 685-3431 Canada: 1 (800) 463-1636 US: 1 (800) 463-4273 FAX: 1 (418) 685-3948 Internet: http://www.doyon.qc.ca e-mail: doyon@doyon.qc.ca BTF080, 100, 120, 140 Product / Produit: Serial number / Numéro de série:...

  • Page 2: Table Of Contents

    BTF080/BTF100/BTF120/BTF140-E1R2 DOYON PLANETARY MIXER BTF080/ BTF100/ BTF120/ BTF140 ALWAYS READ AND FOLLOW THE OWNER’S MANUAL AND ALL APPLICABLE SAFETY STANDARDS. INDEX CHAPTER 1..................................3 MACHINE REGISTRATION..............................3 CHAPTER 2..................................4 GENERAL DESCRIPTION..............................4 2.1.- MACHINE’S MANUAL ............................4 2.2.- IN CASE OF BREAKDOWN ..........................4 2.3.- PACKAGING .................................4 CHAPTER 3..................................5...
  • Page 3 BTF080/ BTF100/ BTF120/ BTF140-E1R2 8.2.2.- WITH BELTS..........................30 8.2.3.- WITH ELECTRIC CURRENT......................31 8.2.4.- WITH HYGIENE..........................31 8.3. – PRODUCT LIFE CYCLE ..........................31 I:\Travaux\MANUEL\FERNETO\BTF\EN REVISION\BTF080-140-A.doc Page 2...

  • Page 4: Chapter 1

    BTF080/BTF100/BTF120/BTF140-E1R2 CHAPTER 1 MACHINE REGISTRATION Each unit has a nameplate located on the back part, where all the general characteristics of the unit are registered, such as : - Manufacturer’s name, address, phone and fax numbers. - Technical features: 1. Unit’s model number 2.

  • Page 5: Chapter 2

    BTF080/ BTF100/ BTF120/ BTF140-E1R2 CHAPTER 2 GENERAL DESCRIPTION The instruction manual is part of the unit and should be preserved during the entire machine’s use. 2.1.- MACHINE’S MANUAL • Before starting the unit, please read carefully this manual, especially the chapter related to safety.

  • Page 6: Chapter 3

    BTF080/ BTF100/ BTF120/ BTF140-E1R2 CHAPTER 3 USING THE MACHINE 3.1.- GENERAL FEATURES The machine has to be used by qualified people. It is designed to work with dough, cream and pastry used in confectioneries. 3.2.- MACHINE PROPERTIES The planetary mixer is best if used for producing any types of creams, mixed drinks, brioches, puff pastries, etc.

  • Page 7: Chapter 4

    BTF080/ BTF100/ BTF120/ BTF140-E1R2 CHAPTER 4 TECHNICAL DATA 4.1.- OVERALL DIMENSIONS Illustration 2 shows the unit’s overall dimensions. BTF080 BTF100 BTF120 BTF140 [835mm] [1110 mm] [1600 mm] Page 6...

  • Page 8: Technical Specifications

    50% water) 4.3.- ELECTRICAL INSTALLATION DOYON has developed the electrical system complying with present regulations, especially with North American standards UL763, CSA 22.2 no195 NSF-8 and European normative EN 60204-1: ”Machinery Security – Machines’ electrical equipment – Part 1: General Applications”.

  • Page 9: Safety System

    BTF080/ BTF100/ BTF120/ BTF140-E1R2 4.4.- SAFETY SYSTEM The unit’s dangerous area is where tools work. Nevertheless, the user is not exposed to the risks because of the solutions adopted to avoid injuries. There is a safety grid that has to be closed at all time during operations.

  • Page 10: Chapter 5

    BTF080/ BTF100/ BTF120/ BTF140-E1R2 CHAPTER 5 SHIPPING, POSITIONING AND ELECTRICAL CONNECTIONS 5.1.- SHIPPING The machine’s weight is indicated on the following table. Model Weight [kg] BTF080 BTF100 BTF120 BTF140 The machine can be lifted, as seen on Illustration 7, with elevators, cables, ropes or hooks. These tools have to be perfectly dimensioned to withstand the machine’s weight.

  • Page 11: Positioning

    BTF080/ BTF100/ BTF120/ BTF140-E1R2 BTF080/ BTF100/ BTF120/ BTF140 Illustration 7 5.2.- POSITIONING The faulty installation of the machine may cause material and personal damage. In this case, the manufacturer cannot be considered responsible. The ground surface where the machine will be positioned has to be perfectly rigid and firm and allow the machine to be balanced, avoiding it to fall during operation.

  • Page 12: Electrical Connections

    BTF080/ BTF100/ BTF120/ BTF140-E1R2 5.3.- ELECTRICAL CONNECTIONS Make sure all electrical wall outlet of the building have the same voltage and power than described on the machine’s registration plate (chapter 1). The outlet should be near the machine. Avoid connecting more than one machine on the same power connection.

  • Page 13: Chapter 6

    BTF080/ BTF100/ BTF120/ BTF140-E1R2 CHAPTER 6 PLANETARY MIXER WORKING OPERATION 6.1.- PLACING THE INGREDIENTS • Placing the ingredients is a very important step. The machine’s performance may depend on how they are placed. They must be put in a way that does not force the machine’s components.
  • Page 14 BTF080/ BTF100/ BTF120/ BTF140-E1R2 BTF080/ BTF100/ BTF120/ BTF140 Illustration 8 • The tools should not be installed if the bowl is not correctly placed on the machine. That would be considered faulty and irrational use of the machine. • Select a function on the display (speed should suit the product, in order to avoid the risk of forming excessive dust).
  • Page 15 BTF080/ BTF100/ BTF120/ BTF140-E1R2 Manual Mode – Screen Functions A – State: off Button to access the automatic screen. (see section Automatic Mode “D”). Display of time visualisation, format “minutes : seconds”, increase in seconds, regulation every 30 seconds. Display of speed scale, increase of 1 unity, regulation from “01” to “20”.
  • Page 16 BTF080/ BTF100/ BTF120/ BTF140-E1R2 B – State: in function Inactive button. is in “0” (zero) on start, the time showed during the work is ascending and is incremented until the machine stops or it will automatically stop when 99 minutes and 99 seconds in is reached.
  • Page 17 BTF080/ BTF100/ BTF120/ BTF140-E1R2 C – State: Pause Inactive button. Display with constant value. Display with function defined in “A”. Button to access the function defined in “A”. Button to access the function defined in “A”. Button to access the function defined in “A”.
  • Page 18 BTF080/ BTF100/ BTF120/ BTF140-E1R2 List of program names To edit each name, press the program wanted to go to the next screen. The white area shows the text written. Available buttons from “A” to “Z”. Button “CLR” moves from the screen without saving and turns back to the screen “D”.
  • Page 19 BTF080/ BTF100/ BTF120/ BTF140-E1R2 The white area shows the numbers written. Available buttons from “0” to “9”. Button “ ” moves on the screen without saving and turns back to screen “D”. Button “OK” saves and turns back automatically to screen “D”.
  • Page 20 BTF080/ BTF100/ BTF120/ BTF140-E1R2 Button to access the programming screen (see screen “D”). Display of visualisation of the time. Total of Display with the function defined in “A”. Button to access the function defined in “A”. Button to access the function defined in “A”.
  • Page 21 BTF080/ BTF100/ BTF120/ BTF140-E1R2 F – State: in function (first speed) (first speed) (second speed) The frame shows the speed and time of the first and second speed. This allows the possibility of changing the programmed values, i.e., if the frame is in speed 1 and time 1, use the buttons , and to change the values.
  • Page 22 BTF080/ BTF100/ BTF120/ BTF140-E1R2 Button to access the function defined in “A”. Button to access the function defined in “A”. Button to access the rising of the bowl’s arm. (when applicable). Button to access the descent of the bowl’s arm (when applicable).
  • Page 23 BTF080/ BTF100/ BTF120/ BTF140-E1R2 Inactive button. Display with constant value. Button to access the function defined in “A”.. Button to access the function defined in “A”. Button to access the function defined in “A”. Button to access the function defined in “A”.
  • Page 24 BTF080/ BTF100/ BTF120/ BTF140-E1R2 Button to select the Spanish language. Button to select the German language. Button to access the instructions screen “L”. Machine model Serial number machine Display of visualisation of the machine’s software version. L – How to use the equipment Button to access the screen “K”.
  • Page 25 BTF080/ BTF100/ BTF120/ BTF140-E1R2 N - Other products (2/2) Button to access the screen “M”. Button to access the maintenance screen “O”. Brief text with the list of other products. O – In and out Screen to consult information on the inputs and outputs of the machine’s automaton.
  • Page 26 BTF080/ BTF100/ BTF120/ BTF140-E1R2 Not used. Button to introduce the machine’s model (for example “BTF”). Press button and enter the model. Button to introduce the machine’s capacity (for example “080”). Press button and enter the model. Button to introduce the machine’s specificity (for example “M”). Press button and enter the model.
  • Page 27 BTF080/ BTF100/ BTF120/ BTF140-E1R2 Q – Erase partial counters By pressing any of the options, it returns automatically to the screen “P”. Button to accept the reset of the partial counters. Button to reject the reset the partial counters. R – Messages to the user This machine, due to its particularity of functioning, needs all electrical phases to be connected in order to work, and for the phases to be in the correct sequence.
  • Page 28 BTF080/ BTF100/ BTF120/ BTF140-E1R2 This message appears when the machine is malfunctioning, by undue use or a mechanical problem. It’s necessary to disconnect the machine with the main switch and wait a few minutes to allow the booster to restart. If the message occurs frequently, request an intervention from the authorised technical assistance.

  • Page 29: Chapter 7

    BTF080/ BTF100/ BTF120/ BTF140-E1R2 CHAPTER 7 MAINTENANCE WARNING: BEFORE EVERY CLEANING OR MAINTENANCE OPERATION, CUT OFF THE POWER BY THE MAIN SWITCH AND DISCONNECT THE ELECTRIC PLUG FROM THE CURRENT TAP. When doing potentially dangerous operations such as refinements, maintenance, dismantling, electric, mechanical or pneumatic component replacements, etc, the user must be sure that the plug is pulled out.

  • Page 30: Check The State Of The Bowl's Fixing System

    BTF080/ BTF100/ BTF120/ BTF140-E1R2 If necessary, proceed as follows to stretch the belts: • Disconnect the electrical current at the master switch and pull the plug out from the electrical socket. • Unbolt the screw of the upper cover. •...

  • Page 31: Chapter 8

    BTF080/ BTF100/ BTF120/ BTF140-E1R2 CHAPTER 8 SAFETY INSTRUCTIONS 8.1.- SAFETY INSTRUCTIONS • This machine was designed to be used only by qualified and trained personnel for the production of dough, creams, pastries and confectioneries. The manufacturer should never be considered responsible for any damage on people or objects caused by its faulty, irrational or misuse.

  • Page 32: With Electric Current

    BTF080/ BTF100/ BTF120/ BTF140-E1R2 8.2.3.- WITH ELECTRIC CURRENT The electrical system complies with the security European legislation, particularly with the Directives 98/37/CE, 93/68/CEE and 89/336/CEE and has been tested according to the International Normative EN 60204-1. Also has been tested according to North American standards UL763, CSA22.2 no 195 and NSF-8, also has been tested to meet IP54 Normative.
