VP-885
TECHNICAL SPECIFICATIONS
5x8 composite video, 0.7Vpp/75Ω and S/PDIF digital audio or s−Video, 0.7Vpp/75Ω (Y), 0.7Vpp/75Ω
INPUTS:
(C); and component video, 0.7Vpp/75Ω on BNC connectors; 8 balanced stereo audio, 2.2V/10kΩ on
detachable terminal blocks; 1 external sync, 1Vpp on a BNC connector.
5x8 composite video, 0.7Vpp/75Ω and S/PDIF digital audio or s−Video, 0.7Vpp/75Ω (Y), 0.7Vpp/75Ω
OUTPUTS:
(C); and component video, 0.7Vpp/75Ω on BNC connectors; 8 balanced stereo audio, 2.2V/150Ω on
detachable terminal blocks.
MAX. OUTPUT
Video: 2.4Vpp (RGB); Audio: 15Vpp @max gain.
LEVEL:
Video: 350MHz, fully loaded; Audio: 22kHz.
BANDWIDTH (-
3dB):
Video: 74dB; Audio: 81dB @1kHz.
S/N RATIO:
Video: –47dB @5MHz; Audio: <–57dB @20kHz.
CROSSTALK (all
hostile):
0.05%.
DIFF. GAIN:
DIFF. PHASE:
0.05Deg.
Manual, RS−232, RS−485 or Ethernet.
CONTROLS:
0.089% @1kHz.
AUDIO THD +
NOISE:
100−240V AC, 50/60Hz, 23VA.
POWER
CONSUMPTION:
48.26cm x 17.78cm x 3U (19" x 7" x 3U) W, D, H.
DIMENSIONS:
WEIGHT:
5.5kg (12.2lbs) approx.
Power cord, Windows® based Ethernet Configuration software, Windows® based Kramer control
ACCESSORIES:
software, rack "ears".
External remote IR receiver cable.
OPTIONS:
