Useful information | Technical data

Useful information

Warranty

We provide a manufacturer's warranty for prod-
ucts bought within the European Union. For de-
vices purchased outside the European Union, the
warranty terms issued by our respective responsi-
ble domestic agency are valid. The warranty terms
can be called up from www.blaupunkt.com.

Service

In some countries, Blaupunkt off ers a repair and
pick-up service.
Information about the availability of this service in
your country can be found at www.blaupunkt.com.
If you want to take advantage of this service, you
may request a pick-up service for your car sound
system via the Internet.

Technical data

Voltage supply
Operating voltage:
Current consumption
In operation:
10 sec. after switch-off : < 3.5 mA
Amplifi er
Output power:
Tuner
Wavebands in Europe/Thailand:
FM:
AM (MW):
LW (Europe only):
Wavebands in the US:
FM:
AM (MW):
32
10.5 – 14.4 V
< 10 A
4 x 22 watts sine at
14.4 V at 4 ohms.
4 x 50 watts max. power
87.5 – 108 MHz
531 – 1,602 kHz
153 – 279 kHz
87.7 – 107.9 MHz
530 – 1,710 kHz
Wavebands in South America:
FM:
AM (MW):
FM frequency response: 30 – 15,000 Hz
CD
Frequency range:
Pre-amp out
4 channels:
Input sensitivity
Front AUX-IN:
Dimensions and weight
W x H x D:
Weight:
Subject to changes
87.5 – 107.9 MHz
530 – 1,710 kHz
20 – 20,000 Hz
2 V
300 mV / 10 kΩ
178 x 50 x 160 mm
approx. 1.70 kg
