Installation
ensure that the receptacle cord is
positioned so that the face is per-
pendicular to the floor as in Figure
4.
CAUTION: For continued pro-
tection against risk of fire, replace
only with same type and rating of
fuse, 10 amp fuse maximum.
5. The receptacle is intended for
plugging in a Dimplex heater
(supplied with the mantel),
which will allow the heater to
be controlled with the provided
remote. (Figure 4)
CAUTION:
cord is intended for use only with
the Dimplex heater 6909070159.
If this receptacle is used with any
other product, Dimplex will not be
liable for any damage or issues
that may arise.
8
The receptacle
Figure 4
10A 120V
Receptacle
15A 120V
Plug
