Assembly
Figure 6
Emitter
Transducer
Wire Slot
8. Install the media on top, log
assembly or rock media and
media tray, so that the opening
is not blocked (Figure 7).
CAUTION: Do not arrange the
rock media while the unit is running,
since the rocks may be hot.
9. Make sure the On/Off switch
is switched to Off (refer to
Operating Instruction section).
10. Plug the unit into a 15 Amp/
120 volt outlet.
10
Top
Cover
Water Tank
Figure 7
!
NOTE: Rock media shown, install
log assembly in the same way.
Retaining
Tab
Fan
Housing
