3
WATER CONNECTION OPTIONS
Saddle valves are susceptible
cold water supply line
T-fitting
1/4" Diameter
Tube
Cold Water
Supply Line
to clogging
.
Attach the valve to a
Compression valve or T-fitting option
(not supplied):
I I
Ensure that a shutoff valve is installed
on the cold water supply line. If so, a
T-fitting or compression valve can be
used to connect the dispenser.
I I
Connect the 16" (40.6 cm) long, 1/4"
diameter copper tube on the
dispenser to the T-fitting as shown
(see step 4).
Saddle valve option (not supplied):
I I
Follow the directions for
"self-piercing attachment"
included with the valve.
I I
Connect the 16" (40.6 cm) long, 1/4"
diameter copper tube on the dispenser
to the saddle valve as shown (see step 4).
I I
Open the valve and let a small amount
of water run through it into a pan.
This will flush the line of sediment.
Shutoff valve option (not supplied):
I I
The water connection can be made
using a shutoff valve. This is a more
complex installation and should only
be attempted by an experienced
installer with the proper knowledge
and tools.
.
