Valve lever design may vary

Safety Instructions

Please be certain that the person who installs or uses this
appliance carefully reads and understands the Safety
Instructions contained in this manual. This appliance pro-
duces extremely hot water. Do not allow children to operate
this appliance.
Important
Do not install this appliance in public areas where there
is unsupervised access to this appliance.
The Installation, Care and Use of Your New
"Hot-1" Hot
®
Water Dispenser
Warnings alert you to hazards or unsafe practices which could result in severe
personal injury or death.
Cautions alert you to hazards or unsafe practices which could result in minor personal
injury or product/property damage.
How your hot water

dispenser works

Water is electrically heated to a brew-
ing/cooking hot 190°F (88° C)* by a
compact tank that mounts under the
sink. A thermostat maintains it at this
approximate temperature. When you
push the valve lever, cold water enters
the bottom of the tank and forces hot
water out of the faucet. The system is
vented so the tank is not pressurized.

Specifications

Capacity
1/3 gallon (1.3L), up to 40 cups
of 190°F*(88°C) water per
hour.
Electrical
115 volts A.C., 4.3 amps, 500
watts. Energy consumption .95
KWH/day. Three-wire cord &
plug provided.
Valve
Self-closing
*approximate
Thermostat
Snap-action adjustable, factory
preset at approximately 190°F
(88°C).
Construction
Copper tank and valve. Copper
tubing.
Shipping weight
4 lbs. (1.8 kg.)
P/N42898 04/03
