InSinkErator Model SST-FLTR Submittal Sheet

Dimensions
11"
6.125"
DEPTH IS 6.75"
Job Specifications
©IN-SINK-ERATOR Printed in USA
I N S T A N T H O T W A T E R D I S P E N S E R S
Model SST-FLTR
Stainless Steel Tank with F-201 Filtration System*
*Water dispenser sold separately
Submittal Sheet
Stainless Steel Tank dispenses filtered
near-boiling 200°F water instantly.
• F-201 Filtration System included for
•
• fresher tasting water
• 35% more near-boiling water from larger
2
gallon stainless steel tank
3
• Easy to adjust temperature control
• Tool-free tank connections and dry start
protection to ease installation
• Provides 60 cups/hour of near-boiling water
• 3-Year We Come To You™ In-Home
Service Warranty*
• 120 volts, 750 watts, 6.25 amps
• For use with In-Sink-Erator Series 1100 and
other dispenser models
* The complete In-Sink-Erator warranty is
included in the Installation, Care & Use Booklet
packed with each unit.
Sample Specification
• Capacity:
2
200°F water per hour
• Electrical: 120 volts A.C., 750 watts, 6.25 amp
heating element with grounded three (3)
prong plug
• Thermostat: Snap action, adjustable from 160°F
to 210°F (factory pre-set at approximately 200°F)
ADJUSTABLE
THERMOSTAT
• Insulation: Meets U.L. 94HF-1 flammability
specification
• Recommended Supply Pressure: 30-125 psi
• Shipping Weight: Approximately 4.2 lbs.
DRAIN PLUG
To ensure optimum performance, maximum
distance between tank and dispenser head
should be 16" or less.
(Not for use with Model Hot1)
gallon tank dispenses 60 cups of
3

Specifications

gallon tank
Capacity
dispenses 60 cups of
200 º F water per hour
Electrical 120 volts A.C., 750
watts, 6.25 amp
heating element
with grounded
three (3) prong
plug
Thermostat Snap-action,
adjustable from
160 º F to 210 º F
(factory pre-set
at 200 º F)
Insulation Meets U.L. 94HF-1
flammability
specification
Recommended 30-125 psi
Supply Pressure
Shipping Weight Approximately
4.2 lbs.
The Emerson logo is a trademark and
a service mark of Emerson Electric Co.
In-Sink-Erator is a division of
Emerson Electric Co.
Form No. HWD 301-05H-19-12
