InSinkErator Model Hot1 Owner's Manual page 4

Maximum
Countertop
Thickness
for Mounting
2"
(5.1cm)
4
DIMENSIONS
Spout
6"
(15.2cm)
Mounting
Nut
Rubber
Gasket
3"
(7.6cm)
11¾"
8
(28.9cm)
3 Wire
Power Cord
30" Long
(76cm)
2½"
(6.4cm)
4"
(10.2cm)
2¼ "
9
16
(6.5cm)
Spout Holder
Valve
Lever
Slotted
Set Screw
(Opposite Side)
Wing
Nut
Width of
Unit 5¼"
(13.3cm)
¼" Copper Tube
16" Long
(40.6cm)
Cold Water Line
