5 en | Bosch Security Systems
1.
2.
3.
4.
5.
1.3
Setting camera IP address
The camera is supplied with installation software on CD. The
installation software assists setting up the camera's IP address.
To run the installation software:
1.
2.
1.3.1
Configure firewall
As you start the application, your PC may prompt you to permit
its access to the network.
Allow the Camera Installer program to access the network.
1.3.2
Assigning IP addresses
Choosing between Basic or Advanced modes:
–
–
F.01U.032.595 | V 1.0 | 2007.03
Attach camera to the 100 Mbps network input of the PC
with the cross-link CAT 5 cable.
Manual iris lens: check the lens to make sure the F-Stop is
between F2.8 and F4.0.
DC-iris lens: plug in the DC-iris cable into the iris connec-
tor on the rear of the camera.
Plug in the camera power cord.
A yellow LED on the back of the camera should light up
after a few seconds.
–
This LED indicates that a link to the computer has
been established.
–
A green LED will blink when the camera is accessed.
Make sure your Windows XP/2K account has administrative
privileges.
Using Windows Explorer, navigate to the CD and double
click the installer.exe file. The camera installer program
opens.
Only use Basic mode (default) if the network does not
have other devices connected.
Use Advanced mode if the network has other devices con-
nected (this is because using Automatic mode risks dupli-
cating existing IP addresses).
Quick Install Guide
Megapixel IP Cameras
Bosch Security Systems
