5. Hold the Left Upright (66) against the Base (74).
Insert a 3/8" x 3 1/4" Screw (2) with a 3/8" Star
Washer (3) into the top hole in the Left Upright
(66). Then, partially tighten the Screw into the
Base (74).
Partially tighten two more 3/8" x 3 1/4" Screws
(2) with two 3/8" Star Washers (3) into the Left
Upright (66) and the Base (74); do not fully
tighten the Screws yet.
6. Identify the Left and Right Upright Covers (88,
89). Slide the Left Upright Cover onto the Left
Upright (66) as shown. Slide the Right Upright
Cover onto the Right Upright (76) as shown.
5
66
3
2
6
88
66
9
74
63
76
89
