11. Slide the Right Upright Cover (89) up against
the Right Handrail (64). Attach the Right Upright
Cover with two M4.2 x 16mm Screws (56). Be
careful not to overtighten the Screws.
Attach the Left Upright Cover (not shown) as de-
scribed above.
See steps 4 and 5. Tighten the six 3/8" x 3 1/4"
Screws (2).
12. Attach the Latch Housing (67) to the Left Upright
(66) with two #10 x 1/2" Screws (86); make
sure that the knob is on the indicated side.
Start both Screws, and then tighten them. Be
careful not to overtighten the Screws.
13. Make sure that all parts are properly tightened before you use the treadmill. If there are sheets of plas-
tic on the treadmill decals, remove the plastic. To protect the floor or carpet, place a mat under the treadmill.
Note: Extra hardware may be included. Keep the included hex keys in a secure place; one of the hex keys is
used to adjust the walking belt (see pages 23 and 24).
11
64
89
12
Knob
86
12
56
67
66
