MIC400 PTZ Camera Series Installation and Operation Manual For the MIC400AL, MIC400UL, MIC400ST, MIC400UT, MIC400PA and MIC400IR PTZ camera models Chapters_______________________________________________ 1. Introduction 2. Hardware Installation 3. Power Supply Installation & Setup 4. Configuring the MIC400 Camera 5. Technical Specifications...
MIC400 Series Camera | Installation and Operation Manual AAAEN | 3 Introduction............. 1-12 Configuring the MIC400 Camera………………… 4-27 MIC400 PTZ Camera................. Connecting the MIC to a PC..............4-27 MIC400 Versions and Options............Commissioning the MIC through Camset..........4-27 MIC400 Power Supply Option Versions and Options......
WARNING INSTALLATION SHOULD BE CARRIED OUT BY QUALIFIED PERSONNEL ONLY IN ACCORDANCE WITH THE APPLICABLE LOCAL CODES. BOSCH SECURITY SYSTEMS ACCEPT NO LIABILITY FOR ANY DAMAGES OR LOSSES CAUSED DUE TO INCORRECT OR IMPROPER INSTALLATION Bosch Security Systems Issue 1...
Page 5
9. Do not use caustic or abrasive cleaning products on the unit 10. Do not point the MIC400 camera at the sun. BOSCH Group will not be liable for any damages to cameras which have been directly pointed at the sun This equipment contains electrical or electronic components 11.
AAAEN | 6 Reference Introduction CHAPTER 1 Glossary of Terms The MIC400 family of PTZ cameras are BOSCH Group s current range of weatherproof, ruggedized, high specification, fully functional pan tilt zoom CCTV Pan/Tilt/Zoom cameras. Bi-phase Bosch Bi-phase telemetry protocol (see pg8)
MIC400AL The MIC400AL is made from machined and cast aluminium and is BOSCH Group has designed a range of power supplies for the MIC400 cameras to then pre-treated and painted with two part epoxy power coat paint in either cater for a variety of common voltages and provide all the connections needed for RAL7001 (Grey) or RAL9005 (Jet Black).
Wide range of mounting options for varied applications MIC-BP3 Bosch Bi-phase converter card for power supplies without • Optically flat viewing window expansion slots available, including all IR psu’s MIC-BP4 Bosch Bi-phase converter card for power supplies with an expansion slot available. Bosch Security Systems Issue 1...
• Do not use if any component appears to be damaged. Please contact Bosch Security Systems CCTV Ltd in the event of damaged goods. • The shipping cartoon is the best way to transport the unit, save it & all other packaging materials for future use.
For mounting directly onto buildings Bosch Security Systems manufacture a range of brackets suitable for all typical building installations for upright (90°), canted (45°) or Inverted camera positions, examples are shown below.
Page 11
2. 90mm stainless steel pole banding 3. Pole mount bracket blocks 4. Pole mount bracket plate 5. Pole mount block securing securing bolts 6. Shallow conduit adaptor 7. “O”-ring 8. Wall mount bracket 9. Wall mount bracket securing bolts Bosch Security Systems Issue 1...
4” PCD base to the mounting bracket. An additional Nebar gasket or suitable silicone sealant can be used to ensure a water tight seal between the 4” PCD base & mounting surface. Ensure all bolts are securely tightened. Secure all cabling & conduit. Bosch Security Systems Issue 1...
5. If dual earthing is unavoidable then a video isolation transformer should be Brackets (MIC-WMB) can also be used to mount the MIC400 underwater following fitted between the two earths. the same precautions as outlined above. Bosch Security Systems Issue 1...
5) Screw termination of all cable into and out of the box. Power input 1. 6) Correct video termination for the camera coaxial cable. Power input 2. Green 7) Earth isolation and termination within the unit to correctly control Video earthing and thus prevent Earth loop. Bosch Security Systems Issue 1...
CN1 - Video out connection header (BNC) CN2 - Add on card header (plug in) Figure A and the following tables show the connections required. Table B – Power Connection to Header HD1 Live HD1-1 Neutral HD1-2 Earth HD1-3 Bosch Security Systems Issue 1...
The following table shows the fuse values fitted for the different supplies for operating the power supply: TXA or Tx - Pin 6 Pin 4 Pin 4 Note FS 4 does not exist TXB or Tx + Pin 7 Pin 5 Pin 5 Bosch Security Systems Issue 1...
4. Connect the composite cable to HD3 following the colour coding as shown in the Table C & printed on the PCB. 5. If a tamper switch relay is to be used, connect this at HD2. 6. Connect the Coaxial video cable to the CN1 header. Bosch Security Systems Issue 1...
Table G – Power Input wiring connections for MIC-12PSU Positive HD1-1 Negative HD1-2 For 12V vehicle installations the composite cable wiring is identical to that shown Earth and Negative HD1-3 earlier in this manual on Table C Bosch Security Systems Issue 1...
IR psu’s Grey wires in the composite cable. MIC-BP4 Bosch Bi-phase converter card for MIC power supplies with an 2. Using a terminal block connect the Brown and Grey wires from the available expansion slot.
Page 20
PCB and in. 7. The heaters are thermostatically controlled and will automatically turn on at +5°C and turn off at +15°C. 8. Check all connections, reseal the PSU enclosure and reapply power. Bosch Security Systems Issue 1...
If there are no other connections to the camera to earth via a locally connected and thus prevent Earth loop. fibre interface unit or via a video/opto transmission system or some other third party equipment, then the left Earth Link situated below FS4 should be left intact. Bosch Security Systems Issue 1...
MIC400 Washer pump Live HD7 pin 1 to the control room. Washer pump Neutral HD7 pin 2 9. Connect the power to HD1 carefully observing the polarity and voltage as per Table A. Bosch Security Systems Issue 1...
Page 24
Earthing; the power supply and all equipment connected to it is earthed to the –ve side of the battery supply permanently. Bosch Security Systems Issue 1...
IR Lamp supply fuse. Glass 5A Quick blow. Local +5v supply fuse Glass 0.5A Quick Blow. Washer supply protection Glass 5A Quick Blow. fuse. Note: there are no PCB link options on this PSU. Bosch Security Systems Issue 1...
15. LED 4 monitors the internally generated +5v rail used to drive the alarm interface circuits around HD2. This +5v supply is not available externally. 6. Connect the Coaxial video cable to the CN1 header. Bosch Security Systems Issue 1...
The PSU board LED should start flashing (LED 6) Connection and wire F 778-758. called PIC OK to indicate correct operation. colour. DATA OUT 6-3+ RXB White DATA OUT 5-4- RXA Yellow SCREEN DATA IN 4-5- TXA Blue DATA IN 3-6+ TXB Violet Bosch Security Systems Issue 1...
Page 28
K2-ADE Connection. Pin 3 RXB White Pin 9 RXA Yellow Pin 5 Not required TXA Blue Not required TXB Violet DIP Switch Setting Sw 1 Sw 2 Sw 3 Sw 4 Sw 5 Sw 6 Bosch Security Systems Issue 1...
USB485CVTR connect to the MIC power supply depending upon the protocol and selected communication mode you may only need a 2 wire configuration. CAUTION: Should be taken to avoid earth loops when connecting 0v from the converter to GND terminal in the MIC power supply Bosch Security Systems Issue 1...
Commissioning the MIC400 through Universal Camset Universal Camset comes with WHQL certified drivers for the MIC-USB485CVTR Universal Camset is a Windows PC based configuration software from BOSCH that must be installed prior to connecting the converter to the PC. Group; it is issued free on the CD that comes with each MIC camera. Universal Camset supersedes all previous versions of Camsets used.
Camset the MIC may not respond. To regain control should this happen, reset the therefore needs to match the address of the MIC that needs to be controlled. Camset Protocol back to what the MIC originally was. Bosch Security Systems Issue 1...
This will work for most manual controls, but anything that requires a indicating this on the Camset Baud Rate drop down list. response, such as Pot Test, Exact Positioning, Programming etc will fail. Bosch Security Systems Issue 1...
Near buttons. Zoom In Zoom Out control the zoom position of the camera lens at a fixed rate. Latch PTZ: This tickbox will Latch the PTZ controls for continuous tilt or rotation as required. Bosch Security Systems Issue 1...
This also needs to have Digital Zoom Enabled under the MIC Setup tab. Auto Pan: This will start the MIC panning between left and right defined limits. On Screen Data: This activates the Sony modules on screen icons. Bosch Security Systems Issue 1...
Tour. This initiates a simple tour with each steps preset position being fixed and the dwell time constant across the tour, stored to the Tour Number. More comprehensive program methods are normally available through the control system. Bosch Security Systems Issue 1...
This manually inverts the image from the camera module, which may be used on an inverted camera where the head cannot be rotated through 180 degrees. Inverting the image would normally also require some modification of the control directions. Bosch Security Systems Issue 1...
MIC will simply remain stationary until the next user input. zoom no matter what the state of the aux. The amount of time before this takes place can be set using the input boxes and Set Time button. Bosch Security Systems Issue 1...
MIC and also a way of copying the settings from one into the next. Self Diagnosis This function is for future products and does not work with the MIC400 or MIC412. Bosch Security Systems Issue 1...
FPS for shutter speed. The On Screen Data auxiliary command will indicate the current frame rate if required. The values are set by simply selecting the desired option from the drop down lists. Bosch Security Systems Issue 1...
If Crosshair and Mask Style are both turned On this function can be used to step through each of the available mask types one at a time. This will not update all the masks to the same type, only the ones that are created subsequent to the change. Bosch Security Systems Issue 1...
Captions Any changes to these settings may be difficult to correct, so please do not attempt to change anything unless under instruction from Bosch. Privacy Calibration section deals with the calibration settings of the privacy masking. I.e. how the masks track as the MIC is moved in Pan, Tilt or Zoom.
FLIR thermal imager in the MIC412 the start and end of the group in terms of an individual sector. Press Set Sector only; this screen has no function with a MIC400 Camera. Info to store the data. Bosch Security Systems Issue 1...
If the MIC reaches 70% humidity inside the head a small "H" is displayed in the top left corner indicating a Humidity problem. If this appears, make contact with Bosch Security Systems. Timers...
These files should not be edited under any circumstances. Upload EEPROM From File This will prompt for a ".epm" file to open, again if valid the process will begin and the progress bar will show the current progress. Bosch Security Systems Issue 1...
Watch button can be used to change the input channel on a Matrix (1 to 16) to the value specified in the lower input box. Bosch Security Systems Issue 1...
2007, so anything after this would use this option. command is sent. The numeric key pad controls also work whilst in pot test although the learn preset method using the number keys does not. Bosch Security Systems Issue 1...
Hex bytes, without the header or CS. the MIC will be slightly slowed down, which may be very noticeable on features such as Pot Test, so unless specifically required it would be advised that this is turned off. Bosch Security Systems Issue 1...
So long as the MIC Comms are 100% reliable this will return the reliability of the comms to the Sony Module inside the MIC, again returning passes, fails and time outs in the same frame. If these are intermittent, please contact Bosch Security Systems for advice.
MIC. The data is stored to the preset number as indicated in the SonySet normal running auto everything, and another set-up for ANPR, with a specified Preset Number in list. frame rate and gain etc. Bosch Security Systems Issue 1...
If the command type requires a numeric input, the corresponding Value box will indicate the lower bound of the range, which can then be changed to any valid value. Bosch Security Systems Issue 1...
Page 52
Auto / Iris Auto / Gain Auto Slow Shutter Mode Auto / Manual Shutter Control Reset / Plus 1 / Minus 1 Shutter Set 0 to 19 Iris Control Reset / Plus 1 / Minus 1 Iris Set 0 to 19 Bosch Security Systems Issue 1...
The MIC programmer allows users to change the protocol of the MIC400 camera unit; you must have the protocol file (.MOT) you wish to upload available, these are available on the CD with the MIC or from Bosch Security Systems. CAUTION: Ensure you have the correct version and software for your MIC400.
Page 54
7. After programming a MIC the status of the settings can be undefined, therefore it is good practice to reset them to the factory defaults then make any modifications required for the specific installation. Bosch Security Systems Issue 1...
1.4 lux (1/60s NTSC, 1/50s PAL), 0.1 lux (1/4s NTSC, 1/3s PAL), 0.01 lux or less (1/4s NTSC, 1/3s PAL, ICR ON) MECHANICAL Shutter speed 1/4 to 1/10,000s (20 steps) NTSC, 1/3 to 1/10,000s (20 steps) PAL Bosch Security Systems Issue 1...
Page 56
Upright mount, inverted mount or upright canted at 45° mount options Colour/Finish Bespoke colours and finishes available on request Camera module 18x camera module or 36x camera module Camera colour system NTSC or PAL Installed protocol Choose from current protocol list Bosch Security Systems Issue 1...
-20°C to +50°C, No heater option available OPERATIONAL* Weatherproofing NEMA 4x / IP68, Speakers IP67 AS MIC400AL ELECTRICAL COMMUNICATION & PROTOCOLS AS MIC400AL AS MIC400AL AVAILABLE OPTIONS CONNECTIVITY AS MIC400AL AS MIC400AL ACCESSORIES ALARMS AS MIC400AL AS MIC400AL MECHANICAL AS MIC400AL Bosch Security Systems Issue 1...
Page 58
For other options see Version and Options Stainless steel – stainless steel Dimensions 205(W) x 360(H) x 165(D)mm (upright & inverted) Weight Aluminium - 5.5Kg (including 4" PCD base) Stainless steel – 16.5Kg (including 4" PCD base) Bosch Security Systems Issue 1...
Grade 316 stainless steel Viewing window Tempered flat glass Standard colours Stainless steel (no colour options) Standard finish Stainless steel (no finish options) Dimensions 205(W) x 360(H) x 165(D) mm (upright & inverted) Weight 16.5Kg Bosch Security Systems Issue 1...
Telemetry control card Built-in Alarm inputs 1 tamper input and 4 alarm inputs in PSU Window wiper Optional, factory fit Alarm communication Tamper switch (ground connection) Washer Optional, factory fit (bracket and nozzle supplied only) Bosch Security Systems Issue 1...
ACCESSORIES Power supply Choose from 115V AC, 230V AC or 12V DC versions (IR Specific PSU) Mounting hardware Compatible with all MIC1 series bracketry Cabling Optional choose from 2M, 10M, 20M or 25M versions Bosch Security Systems Issue 1...
