Bosch MIC400 Product Manual
Mic series fully functional pan-tilt-zoom cameras
Hide thumbs
Also See for MIC400:
- Quick manual (8 pages) ,
- Specification sheet (4 pages) ,
- Quick start manual (3 pages)
Advertisement
Quick Links
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Bosch MIC400
Summary of Contents for Bosch MIC400
- Page 1 MIC series product guide Fully functional pan-tilt-zoom cameras...
-
Page 2: Table Of Contents
2 | MIC series product guide Introduction Contents MIC400 ranges MIC412 thermal range MIC440 ATEX (explosion protected) range MIC series Power Supply Units (PSUs), brackets and accessories MIC series installation examples MIC series – How to commission MIC series product code matrix... - Page 3 MIC series applications With seven unique ranges forming the MIC series - aluminum, stainless steel, underwater, ATEX certified (explosion protected), infrared, public address and thermal – a suitable camera solution can be found for virtually any application. What’s more, with a host of easy Traditional CCTV: High security: Hostile environments:...
-
Page 4: Mic400 Ranges
Scottish Seabird Centre. (Photo by Outersight UK) MIC400 Stainless Steel (MIC400ST) Marine/coastal Shipping Oil rigs Nuclear MIC400 Public Address (MIC400PA) u 6mm thick aluminum casing u Rated to IP68 (speakers rated to IP66) - Page 5 Popular configuration examples Part Number Description MIC400ALBUP14618P MIC400 aluminum, black, upright, Bosch protocol, integrated wiper, 18x day/night camera, PAL MIC400ALGUD14618P MIC400 aluminum, gray, upright, Pelco protocol, integrated wiper, 18x day/night camera, PAL MIC400IRBUP14618P MIC400 infrared, black, upright, Bosch protocol, integrated wiper, 18x day/night camera, PAL...
-
Page 6: Application Examples
6 | MIC series product guide MIC412 range Containing both a high quality optical day/night camera module and an FLIR thermal imaging module that sit side- by-side within the camera housing, the compact MIC412 thermal range turns from a high resolution overview camera into a high performance thermal camera at the press of a single button on the control keyboard. - Page 7 Step 1 Camera Range And Head Part No MIC412 range - camera heads Step 1 ¼" dual spectra "thermal" PTZ, 470TVL optical 18x day/night camera, FLIR 50mm 9Hz thermal imager, Choose camera MIC412TI IP67, built-in telemetry, choice of protocols, aluminum case head Part No MIC412 range - colours...
- Page 8 8 | MIC series product guide MIC440 range The MIC440 ATEX certified (explosion protected) range meets the exacting requirements of CSA/UL certification and ATEX Directive 94/9/EC Exd IIC T6 for safe use in explosive atmospheres, like those found in oil, gas, MIC440 ATEX certified (explosion protected) range (MIC440AX) u Dual spectra unit certified to...
- Page 9 Step 1 Camera Range And Head Part No MIC440 range - camera heads Step 1 1/4" ATEX certified PTZ, 470TVL, 18x day/night camera, IP68, built-in telemetry, choice of protocols, Choose camera MIC440AX aluminum case head Part No MIC440 range - colours Step 2 Black - RAL9005 Choose color...
-
Page 10: Mic Series Power Supply Units (Psus), Brackets And Accessories
MIC-SCA-B shallow conduit adapter attached MIC-CMB-B corner mount bracket MIC-WMB-B with MIC400 aluminum attached Cables Power, video and telemetry are transmitted through a single MIC series cable. All cables come complete with the MIC series connector for easy connection to the camera head. - Page 11 MIC series accessories MIC-WKT Washer kit for non IR MIC400 models (incl. Washer pump drive card, washer nozzle and mounting bracket for 4" PCD base) MIC-WKT-IR Washer kit for IR MIC400 and MIC412 models (incl. washer nozzle and mounting bracket for 4" PCD base)
-
Page 12: Mic Series Installation Examples
12 | MIC series product guide MIC Installation examples An example of a public space CCTV installation with MIC series cameras using Bosch Bi-phase protocol Control room Bosch Plena PA system Bosch IntuiKey keyboard controller Bosch Divar DVR (5 Bi-phase channels) PA speaker cable Telemetry cable (maximum of 8... - Page 13 A typical vehicle installation with optional transmission facility MIC400AL Mounting plate or extendable pole MIC series cable (typically 12V Telemetry Additional battery (optional) Vehicle battery supply Vehicle roof Mobile DVR Video encoder (optional) MIC series product guide | 13 501 or 516 controller Radio transceiver (optional) Video monitor (Coax)
- Page 14 14 | MIC series product guide MIC Installation examples An example of a network using the MIC400 connected via VIPx1/ethernet MIC series cable MIC-PSU Video out Additional VIPx1 units Telemetry via VIPx1 twised pair + shield Composite cable Ethernet hub or switch...
-
Page 15: Mic Series - How To Commission
MIC series cameras come complete with the powerful CAMSET configuration software to enable complete set-up of the camera head. To access the camera you will need the following: 1. Software disk (shipped with every camera and also available as a download) 2. -
Page 16: Mic Series Product Code Matrix
16 | MIC series product guide MIC Series product code matrix Codes 400 = Various models 412 = Thermal Product range 440 = ATEX certified (explosion protected) AL = Standard aluminum IR = Twin IR lamps PA = Speakers ST = Stainless steel Version UL = Underwater aluminum UT = Underwater stainless... - Page 17 MIC series product guide | 17 Customer care and warranty statements Standard Warranty All MIC series cameras come complete with a comprehensive 3-year warranty. 3-year warranty valid from date of delivery. Warranty covers back-to-base repair at a MIC series Bosch approved service center. Post Warranty Support MIC products which have no valid warranty will be repaired where deemed possible by an...
- Page 18 18 | MIC series product guide Notes...
- Page 19 MIC series product guide | 19 Notes...
- Page 20 A Tradition of Quality and Innovation For over 100 years, the Bosch name has stood for quality and reliability. Bosch is the global supplier of choice for innovative technology, backed by the highest standards for service and support. Bosch Security Systems proudly offers a wide range of security, safety, communications and sound solutions that are relied upon every day in...
