MLG-96
(DSI)
Parts Manual
2000
American Dryer Corporation
88 Currant Road
Fall River, MA 02720-4781
Telephone: (508) 678-9000 / Fax: (508) 678-9447
e-mail:
techsupport_large_dryer@amdry.com
ADC Part No. 450193

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MLG-96 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for American Dryer Corp. MLG-96

Summary of Contents for American Dryer Corp. MLG-96

  • Page 1 MLG-96 (DSI) Parts Manual 2000 American Dryer Corporation 88 Currant Road Fall River, MA 02720-4781 Telephone: (508) 678-9000 / Fax: (508) 678-9447 e-mail: techsupport_large_dryer@amdry.com ADC Part No. 450193...
  • Page 2 For your convenience, log the following information: MODEL NO. __________________________________________ “IMPORTANT NOTE TO PURCHASER” POUR VOTRE SÉCURITÉ Ne pas entreposer ni utiliser d’essence ni d’autres vapeurs ou liquides inflammables dans le voisinage de cet appareil ou de autre appareil. MLG-96...

  • Page 3: Table Of Contents

    Table of Contents Control Door Assembly ... 2 Phase 6 Microprocessor Panel Assembly ... 3 Main Door/Front Panel Assembly ...4, 5 Main Door Assembly ...6, 7 Main Door Switch Assembly ... 8 Temperature Sensor Bracket Assembly ... 9 Wrapper Assembly ... 10 Lint Door Assembly ...

  • Page 4: Control Door Assembly

    Illus. No. Part No. Qty. Description 882246 White Control Door Assembly Complete (includes illus. nos. 1 and 3) 882376 Cornflower Blue Control Door Assembly Complete (includes illus. nos. 1 and 3) 882355 Corvel Dry Blue Control Door Assembly Complete (includes illus. nos. 1 and 3) 882357 Coral Wrinkle Blue Control Door Assembly Complete (includes illus.

  • Page 5: Phase 6 Microprocessor Panel Assembly

    Phase 6 Microprocessor Panel Assembly Illus. No. Part No. Qty. Description 112537 Phase 6 OPL Keyboard (touch pad) 112276 OPL Stick-On Labels (English Only) ... Not Illustrated 112275 OPL Stick-On Labels (Spanish, Italian, and Hebrew) ... Not Illustrated 112277 3-Language OPL Stick-On Labels (English, Spanish, and Hebrew) ...

  • Page 6: Main Door/Front Panel Assembly

    Main Door/Front Panel Assembly American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...

  • Page 7: Main Door/Front Panel Assembly

    Main Door/Front Panel Assembly Illus. No. Part No. Qty. Description -------- Main Door (refer to Main Door Assembly on page 6 and page 7) 150443 Socket Cap Screw 881441 White Bottom Hinge Block 882306 Cornflower Blue Bottom Hinge Block 881735 Corvel Dry Blue Bottom Hinge Block 882283 Coral Wrinkle Blue Bottom Hinge Block...

  • Page 8: Main Door Assembly

    Main Door Assembly American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...

  • Page 9: Main Door Assembly

    Main Door Assembly Illus. No. Part No. Qty. Description 881968 White CRS Main Door Assembly (includes illus. nos. 1 through 10) 882308 Cornflower Blue CRS Main Door Assembly (includes illus. nos. 1 through 10) 881761 Corvel Dry Blue CRS Main Door Assembly (includes illus.

  • Page 10: Main Door Switch Assembly

    Illus. No. Part No. Qty. Description 150006 #6-32 x 7/8” Phillips Pan Head Machine Screw 152013 #6-32 Hex Nut 153010 #6 Star Washer 137005 Main Door Switch ONLY 881702 White Main Door Switch Housing Assembly Complete (includes illus. nos. 1 through 5) 882314 Cornflower Blue Main Door Switch Housing Assembly (includes illus.

  • Page 11: Temperature Sensor Bracket Assembly

    Temperature Sensor Bracket Assembly Illus. No. Part No. Qty. Description 859372 Temperature Sensor Bracket Complete (includes illus. nos. 1 through 6 and 9 through 12) 881089 Sensor Bracket 884258 4” Temperature Sensor Probe Assembly 154007 1/4” Push On Fastener 121028 1/4”...

  • Page 12: Wrapper Assembly

    Illus. No. Part No. Qty. Description 150309 #10-16 x 1/2” Hex Head TEK Crimptite Screw 859367 Bottom Right Wrapper -------- Idler Shaft (refer to Idler Shaft Assembly on page 14) -------- Temperature Sensor Bracket (refer to Temperature Sensor Bracket Assembly on page 9) 859368 Bottom Left Wrapper --------...

  • Page 13: Lint Door Assembly

    Lint Door Assembly Illus. No. Part No. Qty. Description 882347 White Lint Drawer Assembly (includes illus. nos. 1, 2, and 4) 882378 Cornflower Blue Lint Drawer Assembly (includes illus. nos. 1, 2, and 4) 882348 Corvel Dry Blue Lint Drawer Assembly (includes illus.

  • Page 14: Basket (Tumbler) Assembly

    Illus. No. Part No. Qty. Description 859342 Basket (tumbler) Assembly Complete (includes illus. nos. 1 through 3) 882234 Perforated Basket (tumbler) Panel 150123 1/4-20 x 1/4” Socket Button Head Cap Screw American Dryer Corporation Basket (Tumbler) Assembly 88 Currant Road / Fall River, MA 02720-4781...

  • Page 15: Basket (Tumbler) Bearing Assembly

    Basket (Tumbler) Bearing Assembly Illus. No. Part No. Qty. Description 882244 1-3/4” Flanged Bearing (includes illus. nos 1 and 5) 153025 9/16” Lock Washer 152050 9/16-12 Hex Nut 100816 1-3/4” E-Clip Retaining Ring 102120 Rotational Sensor Magnet 882333 White Bearing/Rotational Sensor Cap 882382 Cornflower Blue Bearing/Rotational Sensor Cap 882330...

  • Page 16: Idler Shaft Assembly

    Illus. No. Part No. Qty. Description 859328 Idler Shaft Assembly Complete (includes illus. nos. 1 through 10) 390232 Idler Shaft ONLY 180033 6” Wheel 180038 1” Taper Lock Bushing 880205 1” Pillow Block Bearing 152004 5/16-18 Hex Nut 153002 5/16” Lock Washer 153001 5/16”...

  • Page 17: Drive Shaft Assembly

    Drive Shaft Assembly Illus. No. Part No. Qty. Description 859329 Drive Shaft Assembly Complete (includes illus. nos. 1 through 11) 390243 Drive Shaft ONLY 180033 6” Wheel 180038 1” Taper Lock Bushing 880205 1” Pillow Block Bearing 152004 5/16-18 Hex Nut 153002 5/16”...

  • Page 18: Drive Motor Assembly

    Illus. No. Part No. Qty. Description 882245 Motor Mount Assembly Complete (includes illus. nos. 1, 2, 6, and 9 through 11) 882237 Motor Mount ONLY 152004 5/16-18 Hex Nut 150501 5/16-18 x 3/4” Tap Bolt 153001 5/16” Flat Washer 153002 5/16”...

  • Page 19: Motorized Impellor (Fan) Assembly

    Motorized Impellor (Fan) Assembly Illus. No. Part No. Qty. Description 882319 White Coop Cone 882380 Cornflower Blue Coop Cone 882324 Corvel Dry Blue Coop Cone 882328 Coral Wrinkle Blue Coop Cone 882329 Coral Blue Coop Cone 100617 Motorized Impellor (fan) - 208 Volt 60 Hz ONLY 100622 Motorized Impellor (fan) - 230 Volt 60 Hz ONLY 100619...

  • Page 20: Direct Spark Ignition (Dsi) Burner Assembly

    Direct Spark Ignition (DSI) Burner Assembly American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...
  • Page 21 24 VAC Gas Valve Liquid Propane (L.P.) Conversion Kit 150415 #10-16 x 1/2” Hex Head TEK Crimptite Screw 331291 Gas Valve Pipe Bracket 141219 MLG-96/122 3-Port Manifold 140836 #10 Burner Orifice (natural gas) ONLY 140855 #33 Burner Orifice (liquid propane [L.P.] gas) ONLY 150309 #10-16 x 1/2”...

  • Page 22: Reversing Relay Panel Assembly

    Reversing Relay Panel Assembly American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...
  • Page 23 Reversing Relay Panel Assembly Illus. No. Part No. Qty. Description 150008 #6-32 x 1-1/4 Phillips Round Head Machine Screw 120701 4-Position Terminal Block 859356 208 Volt Reversing Relay Panel Assembly Complete (includes illus. nos. 1 through 4 and 8 through 15) 323743 Reversing Relay Panel ONLY 151000...

  • Page 24: Pneumatic Valve Assembly

    Illus. No. Part No. Qty. Description 330987 Micro Valve Bracket 836002 Air Jet Solenoid 150111 1/4-20 x 1/2” Phillips Round Head Machine Screw 152014 1/4-20 Free Spin Wash Nut 151000 #6-32 Pal Nut 100472 1/4” x 1/8” Male Connector 150002 #6-32 x 1”...

  • Page 25: Air Jet Assembly For Models Mfd. As Ofapril 9, 2004

    Air Jet Assembly For models mfd. as ofApril 9, 2004 Illus. No. Part No. Qty. Description 143100 1/4” Aluminum Tubing (sold by the foot) 143259 1/4” x 1/8” F.P.T. Bulkhead Fitting 143115 1/4” Poly-Flo Tubing (sold by the foot) 143154 1/4”...

  • Page 26: For Models Mfd. Prior To April 9, 2004

    Illus. No. Part No. Qty. Description 143100 1/4” Aluminum Tubing (sold by the foot) 143287 1/4” x 1/8” M.P.T. Male Run Tee 143259 1/4” x 1/8” F.P.T. Bulkhead Fitting 143115 1/4” Poly-Flo Tubing (sold by the foot) 143154 1/4” Poly Union American Dryer Corporation Air Jet Assembly For models mfd.

  • Page 27: Sail Switch Assembly

    Sail Switch Assembly Illus. No. Part No. Qty. Description 105500 Sail Switch Actuator Rod 319202 Sail Switch Damper (flat) 154002 1/8” Push On Fastener 802800 Sail Switch Box with Cover and Bracket ONLY 802801 Sail Switch Box Assembly Complete (includes illus. nos. 1 through 4 and 6 through 10) 150309 #10-16 x 1/2”...

  • Page 28: Exhaust Collar Assembly

    Illus. No. Part No. Qty. Description 882318 White Adapter Collar 882381 Cornflower Blue Adapter Collar 882320 Corvel Dry Blue Adapter Collar 882321 Coral Wrinkle Blue Adapter Collar 882322 Coral Blue Adapter Collar 152014 1/4-20 Free Spin Wash Nut 104006 16” Butterfly Damper Assembly American Dryer Corporation Exhaust Collar Assembly 88 Currant Road / Fall River, MA 02720-4781...
  • Page 29 Notes __________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________...
  • Page 30 ADC 450193 3-09/19/05-0...
