American Dryer Corp. AD-310 Parts Manual

Phase 7 with tilt options
Hide thumbs Also See for AD-310:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Installation Manual
AD-310 Phase 7
Parts Manual
(with Tilt Options)
American Dryer Corporation
88 Currant Road
Fall River MA 02720-4781
Telephone: (508) 678-9000 / Fax: (508) 678-9447
E-mail: techsupport@amdry.com
ADC Part No. 450032

Advertisement

Table of Contents
loading

Related Manuals for American Dryer Corp. AD-310

Summary of Contents for American Dryer Corp. AD-310

  • Page 1 AD-310 Phase 7 Parts Manual (with Tilt Options) American Dryer Corporation 88 Currant Road Fall River MA 02720-4781 Telephone: (508) 678-9000 / Fax: (508) 678-9447 E-mail: techsupport@amdry.com ADC Part No. 450032...
  • Page 2 These instructions must be posted in a prominent location near the dryer. POUR VOTRE SÉCURITÉ Ne pas entreposer ni utiliser d’essence ni d’autres vapeurs ou liquides inflammables dans le voisinage de cet appareil ou de yout autre appareil. Important AD-310 Tilt MODEL NO. __________________________________________...

  • Page 3: Table Of Contents

    Table of Contents Front Panel Assembly Automatic Door ... 4, 5 Front Panel Assembly Manual Door ... 6, 7 Rear Panel Assembly 1 Door/Forward Tilt ... 8 Rear Panel Assembly 1 Door/2-Way Tilt ... 9 Rear Panel Assembly 2 Automatic Doors ... 10, 11 Rear Panel Assembly 2 Manual Doors ...
  • Page 4 Left Hand Electrical Control Panel Assembly For Models Mfd. with Thermal-Magnetic Protection ONLY ... 29, 30 Right Hand Electrical Control Panel ... 31, 32 Base Main Electrical Junction Box Assembly For Models Mfd. with Thermal-Magnetic Protection ONLY ... 33, 34 Idler Shaft and Basket (Tumbler) Assembly ...
  • Page 5 Guard Panel Assemblies 2-Way Tilt ... 76, 77 Guard Panel Assemblies 1-Way Tilt ... 78 Selector Switch, Nameplate, and Mounting Base Chart ... 79 Right Rear/Front Control Panel ... 80 Right Hand Electrical Control Panel Chart ... 81 Right Hand Base Electrical Panel and Left Hand Electrical Panel Chart ... 82...

  • Page 6: Automatic Door

    Illus. No. Part No. Qty. Description 332680 Left Gusset (for gas models Only) 150522 1/4-20 x 1/2” Hex Washer Head Machine Screw (for gas models Only) 332681 Right Gusset (for gas models Only) 332679 Top Front Panel (for gas models Only) 826033 Upper Guard American Dryer Corporation...

  • Page 7: Front Panel Assembly

    Front Panel Assembly (continued) Automatic Door Illus. No. Part No. Qty. Description 821239 Middle Guard 881117 Left Control Cabinet 821285 Bottom Guard 153001 5/16” Flat Washer 153002 5/16” Lock Washer 150501 5/16-18 x 3/4” Hex Head Machine Bolt 150510 1/4-20 x 3/4” Hex Head Machine Bolt 153007 1/4”...

  • Page 8: Front Panel Assembly

    Illus. No. Part No. Qty. Description 332680 Left Gusset (for gas models Only) 150522 1/4-20 x 1/2” Hex Washer Head Machine Screw (for gas models Only) 826033 Upper Guard 332681 Right Gusset (for gas models Only) 332679 Top Front Panel (for gas models Only) American Dryer Corporation Front Panel Assembly...
  • Page 9 Front Panel Assembly (continued) Manual Door Illus. No. Part No. Qty. Description 821239 Middle Guard 881117 Left Control Cabinet 821285 Bottom Guard 153001 5/16” Flat Washer 150501 5/16-18 x 3/4” Hex Head Machine Bolt 153002 5/16” Lock Washer 150510 1/4-20 x 3/4” Hex Head Machine Bolt 153007 1/4”...

  • Page 10: Rear Panel Assembly

    Illus. No. Part No. Qty. Description 821310 Bottom Panel Assembly -------- Basket (tumbler) Retaining Wheel (refer to Basket [tumbler] Retaining Wheel Assembly on page 36) 332787 Basket (tumbler) Retaining Wheel Guard 150301 #8-18 x 7/16” Phillips Pan Head TEK Screw 150523 1/4-20 x 3/4”...

  • Page 11: Door/2-Way Tilt

    Rear Panel Assembly 1 Door/2-Way Tilt Illus. No. Part No. Qty. Description 821310 Bottom Back Panel Assembly 332571 Rear Panel Reinforcement 821312 Middle Back Panel Assembly 150625 5/16-18 x 1-1/4” Hex Head Machine Bolt 153001 5/16” Flat Washer 153002 5/16” Lock Washer 152004 5/16-18 Hex Nut 821244...

  • Page 12: Automatic Doors

    Illus. No. Part No. Qty. Description 332680 Left Gusset (for gas models Only) 150522 1/4-20 x 1/2” Hex Washer Head Machine Screw (for gas models Only) 332681 Right Gusset (for gas models Only) 332679 Top Front Panel (for gas models Only) 826033 Upper Guard American Dryer Corporation...

  • Page 13: Rear Panel Assembly

    Rear Panel Assembly (continued) 2 Automatic Doors Illus. No. Part No. Qty. Description 821239 Middle Guard 881117 Left Control Cabinet 821285 Bottom Guard 153001 5/16” Flat Washer 153002 5/16” Lock Washer 150501 5/16-18 x 3/4” Hex Head Machine Bolt 150510 1/4-20 x 3/4”...

  • Page 14: Manual Doors

    Illus. No. Part No. Qty. Description 332680 Left Gusset (for gas models Only) 150522 1/4-20 x 1/2” Hex Washer Head Machine Screw (for gas models Only) 826033 Upper Guard 332681 Right Gusset (for gas models Only) 332679 Top Front Panel (for gas models Only) American Dryer Corporation Rear Panel Assembly...

  • Page 15: Manual Doors

    Rear Panel Assembly (continued) 2 Manual Doors Illus. No. Part No. Qty. Description 821239 Middle Guard 881117 Left Control Cabinet 821285 Bottom Guard 153001 5/16” Flat Washer 150501 5/16-18 x 3/4” Hex Head Machine Bolt 153002 5/16” Lock Washer 150510 1/4-20 x 3/4”...

  • Page 16: Left Load Door Assembly

    Illus. No. Part No. Qty. Description 821728 Left Manual Load Door Assembly Complete (includes illus. nos. 1 through 15) 150112 1/4-20 x 1-1/4” Hex Head Machine Screw 153018 1/4” Flat Washer 170367 Stainless Steel Stationary Bushing 170366 Stainless Steel Sealed Wheel 153007 1/4”...

  • Page 17: Right Load Door Assembly

    Right Load Door Assembly Manual Door Illus. No. Part No. Qty. Description 821727 Right Manual Load Door Assembly Complete (includes illus. nos. 1 through 15) 102215 Door Window 170730 Door Window Adhesive (10.3 oz. cartridge) 150112 1/4-20 x 1-1/4” Hex Head Machine Screw 153018 1/4”...

  • Page 18: Left Load Door Assembly

    Left Load Door Assembly Automatic Door American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...

  • Page 19: Left Load Door Assembly

    Left Load Door Assembly Automatic Door Illus. No. Part No. Qty. Description 881112 Left Automatic Load Door Assembly Complete (includes illus. nos. 1 through 11) 881106 Left Automatic Load Door ONLY 150112 1/4-20 x 1-1/4” Hex Head Machine Screw 153018 1/4”...

  • Page 20: Right Load Door Assembly

    Right Load Door Assembly Automatic Door American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...

  • Page 21: Automatic Door

    Right Load Door Assembly Automatic Door Illus. No. Part No. Qty. Description 881113 Right Automatic Load Door Assembly Complete (includes illus. nos. 1 through 12) 881107 Right Automatic Load Door ONLY 150112 1/4-20 x 1-1/4” Hex Head Machine Screw 153018 1/4”...

  • Page 22: End Of Cycle Light Assembly

    Illus. No. Part No. Qty. Description 151001 #8-32 Pal Nut 150415 #10-16 x 1/2” Phillips Round Head Crimptite Screw 150108 #8-32 x 1/2” Phillips Pan Head Machine Screw 821480 Cycle Light Bracket (for steam models Only) 152001 #8-32 Hex Nut 153012 #8 Star Washer 332850...

  • Page 23: Pneumatic Assembly

    Pneumatic Assembly Automatic Door Illus. No. Part No. Qty. Description 150308 #8-32 x 2-1/2” Phillips Pan Head Machine Screw 153000 #8 Flat Washer 100431 Cable Cylinder 128978 1/8” N.P.T. x 1/4” Tube Flow Control 143156 1/4” Poly Tee 143154 1/4” Brass Poly Connector 143110 1/4”...

  • Page 24: Magnetic Door Switch Assembly

    Illus. No. Part No. Qty. Description 826514 Magnetic Door Switch Assembly with Nuts (includes illus. nos. 1 through 3) 122598 2-Pin Connector (male) 137028 137021 Microprocessor Socket 122599 2-Pin Socket Connector (female) 881240 Door Switch “Closed Position” Harness (includes illus. nos. 4 through 8) 122598 2-Pin Connector (male) 137028...

  • Page 25: Left Control Door Assembly

    Left Control Door Assembly For 1 Door or 2 Door Models Illus. No. Part No. Qty. Description 160140 160050 160014 Cam ONLY 112360 ADC Logo ONLY (tape kit not included) 870011 Logo Double Tape Kit 821334 Left Hand Control Door * Specify color when ordering.

  • Page 26: Front Control Door Assembly

    Illus. No. Part No. Qty. Description 821597 Front Right Control Door ONLY --------- Front Right Control Door Panel ONLY (refer to Right Rear/Front Control Panel on page 80) 122438 Engraved Nameplate: Load - Dry - Unload 122361 3-Position Maintained Operator 123203 Black Push Button Operator 122415...
  • Page 27 Front Control Door Assembly Illus. No. Part No. Qty. Description 132386 Normally Opened (N.O.) Contact Block 132387 Normally Closed (N.C.) Contact Block 123201 Green Lighted Push Button Operator 122410 Engraved Nameplate: ON 123212 24 Volt Lamp 132388 Normally Opened (N.O.) Contact Block with Direct Supply 132395 Mounting Base with Normally Closed (N.C.) Contact Block 122421...

  • Page 28: Right Rear Control Door Assembly

    Right Rear Control Door Assembly 2 Door Models ONLY American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...

  • Page 29: Door Models Only

    Right Rear Control Door Assembly 2 Door Models ONLY Illus. No. Part No. Qty. Description 814364 Right Rear Control Door ONLY --------- Right Rear Door Control Panel (refer to Right Rear/Front Control Panel on page 80) 122438 Load/Dry/Unload Nameplate 122361 3-Position Maintained Operator 123202 White Push Button Operator...

  • Page 30: Side Panel Assemblies

    Illus. No. Part No. Qty. Description 826035 Left Top Side Panel 150523 1/4-20 x 3/4” Hex Washer Machine Screw 881189 Lower Side Panel For Hinged Doors 150523 1/4-20 x 3/4” Hex Washer Machine Screw 881190 Locking Hinged Side Panel Door Less Locks 160034 Lock Cam ONLY 160050...

  • Page 31: Left Hand Electrical Control Panel Assembly

    Left Hand Electrical Control Panel Assembly For Models Mfd. with Thermal-Magnetic Protection ONLY Telephone: (508) 678-9000 Fax: (508) 678-9447...
  • Page 32 Illus. No. Part No. Qty. Description 334269 Left Hand Electrical Panel 832677 Left Hand Electrical Panel Assembly Complete (includes illus. nos. 1 through 20) 112075 Ground Label 114007 Danger High Voltage Label -------- Auxiliary Contact Block For Gas and Steam Models (refer to Chart For Left Hand Electrical Panel on page 82) -------- Manual Starter/Thermal-Magnetic Breaker For Gas and Steam Models...

  • Page 33: Right Hand Electrical Control Panel

    Right Hand Electrical Control Panel Illus. No. Part No. Qty. Description 821833 Front Right Electrical Panel ONLY 150334 3/8” Flat Washer 153005 3/8” Split Lock Washer 152005 3/8-16 Hex Nut 121422 28” 1” Wire Duct Cover 121430 28” 1” x 3” Slotted Wall Wire Duct 121422 31”...
  • Page 34 Illus. No. Part No. Qty. Description 120773 2-Position Green/Yellow Ground Block 120772 2-Position Blue Neutral Block 120765 End Stop 120768 35 x 15mm Din Mounting Rail 150300 #10-16 x 1/2” Hex Washer TEK Screw 122424 Power Warning Label 150300 #10-16 x 1/2” Hex Washer TEK Screw --------- Transformer Assembly (refer to Right Hand Electrical Control Panel Chart on page 81)

  • Page 35: Base Main Electrical Junction Box Assembly

    Base Main Electrical Junction Box Assembly For Models Mfd. with Thermal-Magnetic Protection ONLY Telephone: (508) 678-9000 Fax: (508) 678-9447...
  • Page 36 Illus. No. Part No. Qty. Description 120770 End Bracket 120760 Terminal Block 131957 Circuit Breaker #4 (25-40 amp manual starter) -------- Auxiliary Contact Block (refer to Chart For Right Hand Electrical Panel on page 82) -------- Manual Starter (refer to Chart For Right Hand Electrical Panel on page 82) -------- Auxiliary Contact Block (refer to Chart For Right Hand Electrical Panel on page 82)

  • Page 37: Idler Shaft And Basket (Tumbler) Assembly

    Idler Shaft and Basket (Tumbler) Assembly Illus. No. Part No. Qty. Description 826017 Basket (tumbler) Assembly (for 1 door models) 826046 Basket (tumbler) Assembly (for 2 door models) 821465 Drive Wheel Assembly 101227 SK x 1-1/2” Bushing 880880 1-1/2” Pillow Block Bearing with Setscrews and Grease Fitting 814489 External Grease Fitting Kit 150620...

  • Page 38: Basket (Tumbler) Retaining Wheel Assembly

    Illus. No. Part No. Qty. Description --------- Basket (tumbler) Retaining Wheel Cover/Guard (refer to appropriate Front Panel Assembly or Rear Panel Assembly) 150301 #8-18 x 7/16” Phillips Pan Head TEK Screw 820566 Basket (tumbler) Retaining Wheel Assembly 152004 5/16-18 Hex Nut 150509 5/16-18 x 3”...

  • Page 39: Lint Drawer/Basket Assembly

    Lint Drawer/Basket Assembly Illus. No. Part No. Qty. Description 826119 Stainless Steel Screened Lint Basket Assembly (includes illus. nos. 1 and 2) For Models Mfd. as of August 14, 2000 881497 Lint Draw Assembly Complete (includes illus. nos. 1 and 2) For Models Mfd.

  • Page 40: Temperature Sensor Bracket Assembly

    Illus. No. Part No. Qty. Description 820967 Sensor Bracket Assembly 820968 Sensor Bracket Assembly Complete (includes illus. nos. 1 through 10) 150000 #6-32 x 1/4” Slotted Round Head Machine Screw 153010 #6 Star Washer 130112 225° Thermostat ONLY 152000 #6-32 Hex Nut 121028 1/4”...

  • Page 41: Basket (Tumbler) Drive Shaft Assembly

    Basket (Tumbler) Drive Shaft Assembly Telephone: (508) 678-9000 Fax: (508) 678-9447...
  • Page 42 Illus. No. Part No. Qty. Description 821465 11” Drive Wheel Assembly 101227 SK x 1-1/2” Taper Lock Bushing 880880 1-1/2” Pillow Block Bearing with Grease Fitting 814489 External Grease Fitting Kit 170511 1/8-27 N.P.T. Grease Fitting 153011 9/16” Flat Washer 150620 1/2-13 x 2-1/2”...

  • Page 43: Tilt Switch Assembly

    Tilt Switch Assembly Illus. No. Part No. Qty. Description 881252 Tilt Switch Assembly Complete (includes illus. nos. 1, 2, and 4) 122365 Limit Switch Rotary Head 122369 Tilt Switch Arm 150211 #10-32 x 2” Round Head Machine Screw 122367 Tilt Switch Body 153009 #10 Star Washer 152008...

  • Page 44: Tilt Piston Assembly

    Illus. No. Part No. Qty. Description 100559 5” Bore x 14” Stroke Piston 143283 3/8” Poly x 3/8” M.P.T. Connector 143221 3/8” Brass Poly Tee 143120 3/8” Poly Tubing (sold by the foot) 143213 3/8” Poly x 3/8” M.P.T. Brass Elbow 334309 Cylinder Pin Nylon Bumper 150435...

  • Page 45: Post Assembly

    Post Assembly Illus. No. Part No. Qty. Description 100487 3/4” Diagram Pin (with cotter pin) 881529 Post Assembly 100553 Rod Eye 154315 1/4-20 x 1” Socket Head Setscrew 334309 Cylinder Pin Nylon Bumper 150435 3/8-16 x 3” Socket Head Cap Screw 331543 Rod Eye Pin 150599...

  • Page 46: Drive Motor Assembly

    Illus. No. Part No. Qty. Description 101144 SH x 1-1/8” Bushing 101187 2B x 3.6 Motor Pulley (for 60 Hz models Only) 101195 2B x 4.4 Motor Pulley (for 50 Hz models Only) 100152 AX-25 V-Belt (for 60 Hz models Only) 100160 AX-26 V-Belt (for 50 Hz models Only) 100705...

  • Page 47: Fan Motor Assembly

    Fan Motor Assembly For Gas Models ONLY Telephone: (508) 678-9000 Fax: (508) 678-9447...
  • Page 48 Illus. No. Part No. Qty. Description 100062 Motor Base (213T frame) 153004 3/8” Flat Washer 153005 3/8” Lock Washer 150617 3/8-16 x 1” Hex Head Machine Bolt 153004 3/8” Flat Washer 153005 3/8” Lock Washer 152005 3/8-16 Hex Nut 100087 15 HP 208-230/380/460 Volt 3ø...

  • Page 49: Fan Motor Assembly

    Fan Motor Assembly For Steam Models ONLY Telephone: (508) 678-9000 Fax: (508) 678-9447...
  • Page 50 Illus. No. Part No. Qty. Description 181007 Motor Base (256T frame) 153014 1/2” Flat Washer 153026 1/2” Lock Washer 150605 1/2-13 x 1-1/2” Hex Head Machine Bolt 153004 3/8” Flat Washer 153005 3/8” Lock Washer 152005 3/8-16 Hex Nut 181006 25 HP 208-230/380/460 Volt 3ø...

  • Page 51: Front Gas Burner Assembly

    Front Gas Burner Assembly Telephone: (508) 678-9000 Fax: (508) 678-9447...
  • Page 52 Illus. No. Part No. Qty. Description 141241 5-Port Front Manifold 142548 1” x 90° Elbow 150309 #10-16 x 1/2” Hex Head TEK Crimptite Screw 334085 Pipe Bracket 142724 1” x 2” Long Nipple 140017 1” 24 VAC Natural Gas Valve 140018 1”...

  • Page 53: Rear Gas Burner Assembly

    Rear Gas Burner Assembly Telephone: (508) 678-9000 Fax: (508) 678-9447...
  • Page 54 Illus. No. Part No. Qty. Description 141242 5-Port Rear Manifold 142711 1” Close Nipple 150309 #10-16 x 1/2” Hex Head TEK Crimptite Screw 334085 Pipe Bracket 140017 1” 24 VAC Natural Gas Valve 881011 ADG-310 Direct Spark Igniton (DSI) Liquid Propane (L.P.) Conversion Kit (includes orifices) 334085 Pipe Bracket...

  • Page 55: Sail Switch Assembly

    Sail Switch Assembly Illus. No. Part No. Qty. Description 105500 Sail Switch Actuator Rod 332689 Sail Switch Damper (flat) 154002 1/8” Push On Fastener 802800 Sail Switch Box with Cover and Bracket ONLY (includes illus. nos. 4 and 8) 881376 Sail Switch Box Assembly Complete (includes illus.

  • Page 56: Direct Spark Ignition (Dsi) Module Assembly

    Illus. No. Part No. Qty. Description 128935 Direct Spark Ignition (DSI) Module ONLY - 50/60 Hz (for models mfd. as of April 1, 2000) 880815 Direct Spark Ignition (DSI) Module ONLY - 50/60 Hz (for models mfd. prior to April 1, 2000) 820100 Direct Spark Ignition (DSI) Module Mount Assembly ONLY 121400...

  • Page 57: Gas Piping Assembly

    Gas Piping Assembly Telephone: (508) 678-9000 Fax: (508) 678-9447...
  • Page 58 Illus. No. Part No. Qty. Description 142931 2” x 1-1/2” Double Tapped Bushing 150504 5/16-18 x 1” Hex Head Machine Bolt 142514 2” Floor Flange 153002 5/16” Lock Washer 152004 5/16-18 Hex Nut 142568 1-1/2” x 8” Nipple 142611 1-1/2” x 1-1/4” x 1/4” Tee 142522 1-1/4”...
  • Page 59 Gas Piping Assembly continued from page 56 Illus. No. Part No. Qty. Description 142842 1-1/4” x 19” Nipple 142558 1-1/4” Union 142725 1-1/4” x 2” Nipple 142554 1-1/4” x 90° Elbow 142575 1-1/4” x 18” Nipple 142728 1-1/4” to 1” Reducing Elbow 142844 1”...

  • Page 60: Steam Coil Assembly

    Illus. No. Part No. Qty. Description 165034 Steam Coil Assembly 150523 1/4-20 x 3/4” Hex Washer Machine Bolt 153007 1/4” Lock Washer 152002 1/4-20 Hex Nut 820321 Steam Damper Hinge Assembly 115995 144 Steam Damper Gasket (sold by the inch) -------- Steam Damper Assembly (includes illus.
  • Page 61 Steam Coil Assembly (continued) Illus. No. Part No. Qty. Description 153007 1/4” Lock Washer 100544 Piston Support Bracket with Pivot Pin 143238 1/8” Brass Close Nipple 143264 1/4” Poly to 1/8” Brass Reducing Bushing 100496 1/8” Needle Valve 100472 1/4” Poly x 1/8” M.P.T. Connector 143115 1/4”...
  • Page 62 Tilting Steam Piping Assembly American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...

  • Page 63: Tilting Steam Piping Assembly

    Tilting Steam Piping Assembly Illus. No. Part No. Qty. Description 142534 2” x 12” Nipple 152004 5/16-18 Hex Nut 153002 5/16” Lock Washer 142550 2” x 45° Elbow 143125 2” x 72” Flex Hose 154352 2” U-Bolt 142747 1/2” Pipe Plug 142920 2”...
  • Page 64 continued from page 61 Illus. No. Part No. Qty. Description 153002 5/16” Lock Washer 332533 Pipe Bracket 152004 5/16-24 Hex Nut 154352 2” U-Bolt 142542 2” Union 150522 1/4-20 x 1/2” Hex Washer Head Machine Screw 154353 1-1/4” U-Bolt 332533 Pipe Bracket 153002 5/16”...

  • Page 65: Pneumatic Valve Assembly 1 Auto Door/2-Way Tilt W/Optional Sprinkler

    Pneumatic Valve Assembly 1 Auto Door/2-Way Tilt w/Optional Sprinkler Telephone: (508) 678-9000 Fax: (508) 678-9447...
  • Page 66 Pneumatic Valve Assembly 1 Auto Door/2-Way Tilt w/ Optional Sprinkler Illus. No. Part No. Qty. Description 826810 Pneumatic Plate ONLY 100498 3-Way MAC Valve - 24 VAC 100545 MAC Valve 24 VAC 100521 1 Auto Door Pneumatic Valve Assembly (includes illus. nos. 2 through 5) 100472 1/4”...
  • Page 67 Pneumatic Valve Assembly 2 Auto Doors/1-Way Tilt w/Optional Sprinkler Telephone: (508) 678-9000 Fax: (508) 678-9447...

  • Page 68: Pneumatic Valve Assembly 2 Auto Door/1-Way Tilt W/Optional Sprinkler

    Pneumatic Valve Assembly 2 Auto Door/1-Way Tilt w/Optional Sprinkler Illus. No. Part No. Qty. Description 826810 Pneumatic Plate ONLY 100498 3-Way MAC Valve - 24 VAC 100545 MAC Valve 24 VAC 803402 2 Auto Doors Pneumatic Valve Assembly (includes illus. nos. 2 through 5) 100472 1/4”...

  • Page 69: Air Jet Assembly

    Air Jet Assembly Illus. No. Part No. Qty. Description 332700 Air Jet Tube 143287 1/4” x 1/8” M.P.T. Tee 143259 1/4” Compression x 1/8” F.P.T. Bulkhead Fitting 332531 Air Jet Mounting Plate 143100 1/4” Aluminum Tube (sold by the foot) 143152 1/4”...

  • Page 70: Optional Sprinkler Control Panel

    Optional Sprinkler Control Panel American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...
  • Page 71 Optional Sprinkler Control Panel Illus. No. Part No. Qty. Description 120765 Standard End Stop 120750 Ground Terminal Block 120761 4-Position Feed Thru Terminal Block 120758 Feed Thru Terminal Block 120999 Blank Marking Tags 120766 End Section 120768 35 x 15mm Din Mounting Rail 121429 Slotted Wall Wire Duct 121422...
  • Page 72 Optional Sprinkler Assembly American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...

  • Page 73: Optional Sprinkler Assembly

    Optional Sprinkler Assembly Illus. No. Part No. Qty. Description 143135 48” Flex Hose 331794 Inlet Pipe Bracket 153007 1/4” Lock Washer 152002 1/4-20 Hex Nut 150522 1/4-20 x 1/2” Hex Head Washer Machine Screw 154350 1” Pipe U-Bolt 152002 1/4-20 Hex Nut 153007 1/4”...
  • Page 74 continued from page 71 Illus. No. Part No. Qty. Description 153007 1/4” Lock Washer 150522 1/4-20 x 1/2” Hex Head Washer Machine Screw 142602 1” Union 142746 1” x 24” Nipple 142590 1” 45° Elbow 142808 1” x 3” Nipple 142598 1”...

  • Page 75: Optional Sprinkler Temperature Probe Junction Box Assembly

    Optional Sprinkler Temperature Probe Junction Box Assembly Illus. No. Part No. Qty. Description 331877 Temperature Sensor Mounting Plate 150523 1/4-20 x 3/4” Hex Washer Machine Screw 881227 Resistive Temperature Device (RTD) Sprinkler Temperature Probe Assembly (includes illus. nos. 3, 4, and 8) 143296 1/4”...

  • Page 76: Base Panel Assemblies

    Base Panel Assemblies American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...
  • Page 77 Base Panel Assemblies Illus. No. Part No. Qty. Description 334169 Front Base Panel 150522 1/4-20 x 1/2” Hex Washer Head Machine Screw 334169 Front Base Panel 150522 1/4-20 x 1/2” Hex Washer Head Machine Screw 881530 Left Side Base Panel (for gas models Only) 881531 Left Base Panel...

  • Page 78: Guard Panel Assemblies

    Guard Panel Assemblies 2-Way Tilt American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...
  • Page 79 Guard Panel Assemblies 2-Way Tilt Illus. No. Part No. Qty. Description 881200 Front Guard Door ONLY 150300 #10 x 1/2” Hex Washer TEK Screw 170606 Door Magnet 881199 Front Guard Panel ONLY (includes illus. nos. 3 through 6) 881201 Front Guard Assembly Complete (includes illus.

  • Page 80: 1-Way Tilt

    Illus. No. Part No. Qty. Description 881200 Front Guard Door ONLY 150300 #10 x 1/2” Hex Washer TEK Screw 170606 Door Magnet 881199 Front Guard Panel ONLY (includes illus. nos. 3 through 6) 170348 Front Guard Nylon Glide 150412 #10-16 x 3/4” Phillips Round Head Crimptite Screw 334239 Right Side Shield 150522...

  • Page 81: Selector Switch, Nameplate, And Mounting Base Chart

    Selector Switch, Nameplate, and Mounting Base Chart Telephone: (508) 678-9000 Fax: (508) 678-9447...

  • Page 82: Right Rear/Front Control Panel

    Right Rear/Front Control Panel American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...

  • Page 83: Right Hand Electrical Control Panel Chart

    Right Hand Electrical Control Panel Chart Telephone: (508) 678-9000 Fax: (508) 678-9447...

  • Page 84: Right Hand Base Electrical Panel And Left Hand Electrical Panel Chart

    Right Hand Base Electrical Panel and Left Hand Electrical Panel Charts American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...
  • Page 85 ADC 450032 2 - 08/18/05-0...
