American Dryer Corp. ML-95 Phase 6 Parts Manual

1996 thru february 1999
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ML-95 Parts Manual
1996 Thru February 1999
American Dryer Corporation
88 Currant Road
Fall River, MA 02720-4781
Telephone: (508) 678-9000 / Fax: (508) 678-9447
E-mail: techsupport@amdry.com
www.amdry.com
082997DMG/abe
ADC Part No. 450155

Advertisement

Table of Contents
loading

Related Manuals for American Dryer Corp. ML-95 Phase 6

Summary of Contents for American Dryer Corp. ML-95 Phase 6

  • Page 1 ML-95 Parts Manual 1996 Thru February 1999 American Dryer Corporation 88 Currant Road Fall River, MA 02720-4781 Telephone: (508) 678-9000 / Fax: (508) 678-9447 E-mail: techsupport@amdry.com www.amdry.com 082997DMG/abe ADC Part No. 450155...
  • Page 2 For your convenience, log the following information: MODEL NO. __________________________________________ “IMPORTANT NOTE TO PURCHASER” POUR VOTRE SÉCURITÉ Ne pas entreposer ni utiliser d’essence ni d’autres vapeurs ou liquides inflammables à proximité de cet appareil ou de tout autre appareil. ML-95 Phase 6...

  • Page 3: Table Of Contents

    Table of Contents Control Door Assembly ... 2 Phase 6 Microprocessor Panel Assembly for models mfd. as of February 11, 1998 ... 3 Phase 6 Microprocessor Panel Assembly for models mfd. prior to February 11, 1998 ... 4 Sensor Bracket Assembly ... 5 Front Panel/Main Door Assemblies for models mfd.

  • Page 4: Control Door Assembly

    Illus. No. Part No. Qty. Description 882093 White Control Door Assembly (As of February 11, 1998) 882092 Blue Control Door Assembly (As of February 11, 1998) 881732 White Control Door Assembly ONLY (Prior to February 11, 1998) 881731 Blue Control Door Assembly ONLY (Prior to February 11, 1998) 112368 Milnor Logo ONLY 160005...

  • Page 5: Phase 6 Microprocessor Panel Assembly For Models Mfd. As Of February 11, 1998

    Phase 6 Microprocessor Panel Assembly As of February 11, 1998 Illus. No. Part No. Qty. Description 112537 Phase 6 OPL Keyboard (touch pad) 112276 OPL Stick-On Labels (English Only) Not Illustrated 112275 3 Language OPL Stick-On Labels (Spanish, Italian, and Hebrew) Not Illustrated 112277 3 Language OPL Stick-On Labels (English, Spanish, and Hebrew) Not Illustrated...

  • Page 6: Phase 6 Microprocessor Panel Assembly For Models Mfd. Prior To February 11, 1998

    Illus. No. Part No. Qty. Description 112537 Phase 6 OPL Keyboard (touch pad) 112276 OPL Stick-On Labels (English Only) Not Illustrated 112275 3 Language OPL Stick-On Labels (Spanish, Italian, and Hebrew) Not Illustrated 112277 3 Language OPL Stick-On Labels (English, Spanish, and Hebrew) Not Illustrated 112278 5 Language OPL Stick-On Labels (Italian, Dutch, French, German, and Chinese) Not Illustrated...

  • Page 7: Sensor Bracket Assembly

    Sensor Bracket Assembly Illus. No. Part No. Qty. Description 880251 1/4” Temperature Sensor Probe Assembly Complete (includes illus. nos. 1 and 5 through 8) 130103 225º Large Automatic Thermostat ONLY 153010 #6 Star Washer 152000 #6-32 Hex Nut 121028 Insulated Terminal ONLY 122701 Socket Terminal ONLY 122605...

  • Page 8: Front Panel/Main Door Assemblies For Models Mfd. As Of October 24, 1997

    Front Panel/Main Door Assemblies As of October 24, 1997 American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...
  • Page 9 Front Panel/Main Door Assemblies As of October 24, 1997 Illus. No. Part No. Qty. Description 881804 White Front Panel Assembly (includes illus. nos. 1, 15, and 16) For models mfd. as of December 3, 1997 881696 White Front Panel Assembly (includes illus.

  • Page 10: Front Panel/Main Door Assemblies For Models Mfd. Prior To October 24, 1997

    Front Panel/Main Door Assemblies Prior to October 24, 1997 American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...
  • Page 11 Front Panel/Main Door Assemblies Prior to October 24, 1997 Illus. No. Part No. Qty. Description 881741 White Main Door Handle 881760 Blue Main Door Handle 151011 5/16-18 Acorn Nut 881817 White Front Panel/Main Door Assemblies with “EMERGENCY STOP” Button (includes illus. nos. 1 through 12) 881822 Blue Front Panel/Main Door Assemblies with “EMERGENCY STOP”...

  • Page 12: Main Door Switch For Models Mfd. As Of October 24, 1997

    Illus. No. Part No. Qty. Description 150006 #6-32 x 7/8” Phillips Pan Head Machine Screw 152013 #6-32 Hex Nut 153010 #6 Star Washer 137005 Single Pole Door Switch 150443 1/4-20 x 3/4” Stainless Steel Cap Screw 881687 White Main Door Switch Housing ONLY 881695 Blue Main Door Switch Housing ONLY 881702...

  • Page 13: Main Door Switch For Models Mfd. Prior To October 24, 1997

    Main Door Switch Prior to October 24, 1997 Illus. No. Part No. Qty. Description 150006 #6-32 x 7/8” Phillips Pan Head Machine Screw 152013 #6-32 Hex Nut 153010 #6 Star Washer 137005 Single Pole Door Switch 150443 1/4-20 x 3/4” Stainless Steel Cap Screw 881726 White Main Door Switch Housing ONLY 881727...

  • Page 14: Lint Door Assembly

    Lint Door Assembly American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...
  • Page 15 Lint Door Assembly Illus. No. Part No. Qty. Description 882115 White Lint Door Assembly ONLY (includes illus. nos. 1 and 2) 881724 White Lint Door and Panel Assembly for models with Knob Latch (includes illus. nos. 1, 2, and 6) 882114 Blue Lint Door Assembly ONLY (includes illus.

  • Page 16: Basket (Tumbler) Assembly

    Illus. No. Part No. Qty. Description 882100 Basket (Tumbler) Side 170068 Stainless Steel Basket (Tumbler) Side 881722 Basket (Tumbler) Assembly (includes illus. nos. 1 through 3) 881703 Basket (Tumbler) (includes illus. nos. 2, 4, and 5) 881721 Stainless Steel Basket (Tumbler) Assembly (includes illus.

  • Page 17: Front Thruster Wheel Assembly For Models Mfd. Between September 15, 1997 And April 6, 1998

    Front Thruster Wheel Assembly Between September 15, 1997 and April 6, 1998 Illus. No. Part No. Qty. Description 150220 3/8-24 Hex Nut (for models with 3/8” Hardware) 152004 5/16” Hex Nut (for models with 5/16” Hardware) 150501 5/16-18 x 3/4” Hex Head Machine Bolt 882096 Front Thruster Wheel Bracket --------...

  • Page 18: Front Thruster Wheel Assembly For Models Mfd. Prior To September 15, 1997

    Illus. No. Part No. Qty. Description 152004 5/16” Hex Nut 150501 5/16-18 x 3/4” Hex Head Machine Bolt 882097 Front Thruster Wheel Bracket 881758 Front Thruster Wheel Assembly 180046 Front Thruster Wheel ONLY 153001 5/16” Flat Washer American Dryer Corporation Front Thruster Wheel Assembly Prior to September 15, 1997 88 Currant Road / Fall River, MA 02720-4781...

  • Page 19: Rear Thruster Wheel Assembly For Models Mfd. Between September 15, 1997 And April 6, 1998

    Rear Thruster Wheel Assembly Between September 15, 1997 and April 6, 1998 Illus. No. Part No. Qty. Description 154277 5/16” x 3/8” Shoulder Bolt -------- Rear Thruster Wheel with hardware (use wheel assembly on page 20) 153001 5/16” Flat Washer 150220 3/8-24 Hex Nut (for models with 3/8”...

  • Page 20: Rear Thruster Wheel Assembly For Models Mfd. Prior To September 15, 1997

    Illus. No. Part No. Qty. Description 152004 5/16” Hex Nut 153001 5/16” Flat Washer 180046 Rear Thruster Wheel ONLY 881752 White Rear Thruster Wheel Cover 881753 Blue Rear Thruster Wheel Cover 150301 #8-18 x 7/16” Phillips Pan Head TEK Screw American Dryer Corporation Rear Thruster Wheel Assembly Prior to September 15, 1997...

  • Page 21: Front Thruster Wheel Assembly For Models Mfd. As Of April 6, 1998

    Front Thruster Wheel Assembly As of April 6, 1998 Illus. No. Part No. Qty. Description 150220 3/8-24 Hex Nut 150501 5/16-18 x 3/4” Hex Head Machine Bolt 882096 Front Thruster Wheel Bracket 881720 Front Thruster Wheel Assembly (includes illus. nos. 1 and 3 through 5) 881988 Front Thruster Wheel ONLY (includes illus.

  • Page 22: Rear Thruster Wheel Assembly For Models Mfd. As Of April 6, 1998

    Illus. No. Part No. Qty. Description 150220 3/8-24 Hex Nut 153001 5/16” Flat Washer 881988 Front Thruster Wheel ONLY (includes illus. nos. 1 through 3) 881752 White Rear Thruster Wheel Cover 881753 Blue rear Thruster Wheel Cover 150301 #8-18 x 7/16” Phillips Pan Head Screw 150501 5/16-18 x 3/4”...

  • Page 23: Idler Shaft Assembly For Models Mfd. As Of December 15, 1997

    Idler Shaft Assembly As of December 15, 1997 Illus. No. Part No. Qty. Description 881825 Idler Shaft Assembly Complete (includes illus. nos. 1 through 7) For models mfd. as of December 15, 1997 390134 Drive Shaft ONLY 180037 6” Drive Wheel 180038 1”...

  • Page 24: Idler Shaft Assembly For Models Mfd. Prior To December 15, 1997

    Illus. No. Part No. Qty. Description 881718 Idler Shaft Assembly Complete (includes illus. nos. 1 through 7) For models mfd. prior to December 15, 1997 390009 Idler Shaft ONLY 180039 6” Wheel 180006 1” Trantorque 100205 1” Pillow Block Bearing 152004 5/16”...

  • Page 25: Drive Shaft Assembly For Models Mfd. As Of December 15, 1997

    Drive Shaft Assembly As of December 15, 1997 Illus. No. Part No. Qty. Description 881826 Drive Shaft Assembly Complete (includes illus. nos. 1 through 11) 390154 Drive Shaft ONLY 180037 6” Drive Wheel 180038 1” Taperlock 880205 1” Pillow Block Bearing 152004 5/16”-18 Hex Nut 153002...

  • Page 26: Drive Shaft Assembly For Models Mfd. Prior To December 15, 1997

    Illus. No. Part No. Qty. Description 881717 Drive Shaft Assembly Complete (includes illus. nos. 1 through 9) For models mfd. prior to December 15, 1997 390008 Drive Shaft ONLY 180039 6” Wheel 180006 1” Trantorque 880205 1” Pillow Block Bearing 152004 5/16”...

  • Page 27: Drive Motor Assembly

    Drive Motor Assembly Illus. No. Part No. Qty. Description 881715 Drive Motor Assembly Complete - 60 Hz (includes illus. nos. 1 through 7 and 9) 881716 Drive Motor Assembly Complete - 50 Hz (includes illus. nos. 1 through 7 and 9) 859012 Drive Motor Mount Assembly ONLY 150501...

  • Page 28: Blower (Fan/Impellor) Motor Assembly

    Illus. No. Part No. Qty. Description 881713 Blower (Fan/Impellor) Motor Assembly Complete - 60 Hz (includes illus. nos. 1 through 9) 881714 Blower (Fan/Impellor) Motor Assembly Complete - 50 Hz (includes illus. nos. 1 through 9) 859039 Blower (Fan/Impellor) Motor Slide Assembly ONLY 181105 3 HP / 3ø...

  • Page 29: Sail Switch Assembly

    Sail Switch Assembly Illus. No. Part No. Qty. Description 319203 Sail Switch Mounting Bracket 319202 Sail Switch Damper (flat) 319201 Sail Switch Box Cover 319200 Sail Switch Box 154004 Twin Speed Nut 154002 1/8” Push-on Fastener 150309 #10-16 x 1/2” Hex Head TEK Crimptite Screw 150303 #4 x 3/4”...

  • Page 30: Blower (Fan/Impellor) Wheel Assembly (With Air Jet) For Models Mfd. As Of July 1, 1998

    Blower (Fan/Impellor) Wheel Assembly (with Air Jet) As of July 1, 1998 American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...
  • Page 31 Blower (Fan/Impellor) Wheel Assembly (with Air Jet) As of July 1, 1998 Illus. No. Part No. Qty. Description 101215 5/8” x SH Bushing 101216 2B x 4.2 Pulley - 50/60 Hz 100240 1” Flange Bearing 100701 3/16” x 3/16” x 1” Key 859014 Idler Mount - Top 390053...

  • Page 32: Blower (Fan/Impellor) Wheel Assembly (Without Air Jet) For Models Mfd. Prior To July 1, 1998

    Blower (Fan/Impellor) Wheel Assembly (without Air Jet) Prior to July 1, 1998 American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...
  • Page 33 Blower (Fan/Impellor) Wheel Assembly (without Air Jet) Prior to July 1, 1998 Illus. No. Part No. Qty. Description 101215 5/8” x SH Bushing 101216 2B x 4.2 Pulley - 50/60 Hz 100240 1” Flange Bearing 100701 3/16” x 3/16” x 1” Key 859014 Idler Mount - Top 390053...

  • Page 35: Burner Assembly

    Burner Assembly Illus. No. Part No. Qty. 142924 331291 150309 142829 141300 142701 142601 142710 142504 142734 390125 140026 882098 140411 331291 141208 140836 140855 141123 390124 --------- 390098 881597 128921 150001 151000 130401 319703 881709** 881708** 881707 881498* 335031 151001 881797 Consult factory for elevations over 2,000 feet.

  • Page 36: Reversing Relay Panel Assembly For 208/230/240/380/416 Volt Models Only

    Reversing Relay Panel Assembly For 208/230/240/380/416 Volt Models ONLY American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...

  • Page 37: Reversing Relay Panel Assembly

    Reversing Relay Panel Assembly For 208/230/240/380/416 Volt Models ONLY Illus. No. Part No. Qty. Description 132467 9-13-Amp Blower Overload (for 208/230/240 volt models Only) 132468 4-6-Amp Blower Overload (for 380/416 volt models Only) 132445 12-Amp 3ø Contactor - 24 VAC 150300 #10 x 1/2”...

  • Page 38: Reversing Relay Panel Assembly For 460/480 Volt Models Only

    Illus. No. Part No. Qty. Description 132468 4-6-Amp Blower Overload (for 460/480 volt models Only) 132445 12-Amp 3ø Contactor - 24 VAC 150300 #10 x 1/2” Hex Washer TEK Screw 150008 #6-32 x 1-1/4” Phillips Round Head Machine Screw 120701 4-Position Terminal Block 132448 Reversing Contactor - 24 VAC...

  • Page 39: Transition Piece Assembly With Damper For Models Mfd. As Of September 12, 1997

    Transition Piece Assembly with Damper As of September 12, 1997 Illus. No. Part No. Qty. Description 881705 White Transition Piece Assembly with Damper Complete 881809 Blue Transition Piece Assembly with Damper Complete 152014 1/4-20 Free Spin Wash Nut Telephone: (508) 678-9000 Fax: (508) 678-9447...

  • Page 40: Exhaust Adapter Assembly For Models Mfd. Prior To September 12, 1997

    Illus. No. Part No. Qty. Description 881704 White Exhaust Adapter Assembly without Damper 881808 Blue Exhaust Adapter Assembly without Damper 152014 1/4-20 Free Spin Wash Nut American Dryer Corporation Exhaust Adapter Assembly Prior to September 12, 1997 88 Currant Road / Fall River, MA 02720-4781...

  • Page 41: Pneumatic Valve Assembly For Models Mfd. As Of July 1, 1998

    Pneumatic Valve Assembly As of July 1, 1998 Illus. No. Part No. Qty. Description 330987 Micro Valve Bracket 836002 Air Jet Solenoid 150111 1/4-20 Phillips Machine Screw 152014 1/4-20 Free Spin Wash Nut 151000 #6-32 Pal Nut 100472 1/4” x 1/8” Male Connector 150002 #6-32 x 1”...
  • Page 42 ADC 450155 1 - 12/16/97-50 4 * 08/12/98-50 7 * 02/26/02-25 2 * 01/15/98-50 3 * 05/21/98-50 5 * 12/23/98-50 6 * 03/02/00-50...
