EUROCOM Monster 3.0 User Manual page 132

Upgrading The Computer
6
Figure 6 - 6
Primary HDD
Removal
6 - 10 Upgrading the Hard Disk Drive(s)
Removing the Hard Disk
1. Turn off the computer, and turn it over and remove the battery and component bay
covers (see pages 6 - 4
2. Slide the HDD cover in the direction of arrow
3. Remove screws &
3
1
& 6 - 6).
, and lift it out of the bay
1
and the cover .
4 5
5
3
2
2
4
.
