Ronda 5030.D User Manual

Cal. 5030.D
English
User's Manual
Description of the display and control buttons
Display elements
Second hand
Minute hand
Hour hand
Centre stop-second
Minute counter
Hour counter
Date
Minute counter
Push-button A
Hour counter
Push-button B
Minute counter
Center
stop-second
I II III
Hour counter
Push-button A
III
Push-button B
Second hand
I II III
I II III
Crown
I II
Date
I II
Control buttons
Push button A
Crown
Push button B
Chronograph:
Accumulated timing
Example:
Start: (start timing)
Stop: (e.g. 15 min 5 sec following
Restart: (timing is resumed)
*
Stop: (e.g. 13 min 5 sec following
= 28 min 10 sec
(The accumulated measured time is
Reset:
The three chronograph hands are returned
to their zero positions.
Please note:
* Following , the accumulation of the
timing can be continued by pressing push-
button A
(Restart / Stop, Restart / Stop, ...)
Adjusting the chronograph
hands to zero position
Example:
One or several chronograph hands are not in
their correct zero positions and have to be
adjusted (e.g. following a battery change).
Pull out the crown to position III (all 3
chronograph hands are in their correct or
incorrect zero position).
Keep push-buttons A and B depressed
simultaneously for at least 2 seconds
(the centre stop-second rotates by
360° corrective mode is activated).
Setting the time
* Pull out the crown to position III
(the watch stops).
Turn the crown until you reach the correct
time 8:45.
* Push the crown back into position I.
Please note:
* In order to set the time to the exact second,
must be pulled out when the second hand
is in position «60» (I).
Once the hour and minute hands have been
set, must be pushed back into position I at
the exact second.
Setting the date/time
following a battery change
Example:
– Date / time on the watch: 17 / 1:25 AM
– Present date / time: 4 / 8:30 PM
Pull out the crown to position II
(the watch continues to run).
Turn the crown until yesterday's date
appears
3
.
RONDA AG
CH-4415 Lausen/Switzerland
www.ronda-startech.com
Battery type: 395 (diameter 9.5mm x 2.6mm / SR 927 SW)
Accuracy: +20 / -10 seconds per month
In case your watch needs to be repaired or to raise claims
under a guarantee, please contact the point of sales
Minute counter
Push-button A
Hour counter
Push-button B
Minute counter
Push-button A
)
)
Hour counter
Push-button B
shown)
Push-button B
A
B
A
B
A
I II
Second hand
Chronograph: Basic function
(Start / Stop / Reset)
Example:
Start: Press push-button A.
Stop: to stop the timing, press push-
button A once more and read the three
chronograph hands:
Zero positioning:
Press push-button B.
(The three chronograph hands will be reset
to their zero positions).
Chronograph:
Intermediate or interval timing
Example:
Start: (start timing)
Display interval:
e.g. 10 minutes 10 seconds (timing
continues in the background)
*
Making up the measured time:
(the 3 chronograph hands are quickly
advanced to the ongoing measured time).
Stop: (Final time is displayed)
Reset:
The 3 chronograph hands are returned to
their zero position
Please note:
* Following , further intervals or inter-
mediates can be displayed by pressing
push-button B (display interval / make up
measured time, ...)
Adjusting the centre stop second
Single step A
Continuous A
Adjusting the next hand B
Adjusting the hour counter hand (position 6h)
Single step A
Continuous A
Adjusting the next hand B
Adjusting the minute counter hand (position 9h)
Single step A
Continuous A
Returning the crown to position I
III
Termination of the chronograph hands adjustment
(can be carried out at any time).
Setting the date (quick mode)
Pull out the crown to position II (the watch
continues to run).
I II
Turn the crown until the correct
date 1 appears.
Push the crown back into position I.
Please note:
I II
During the date changing phase between
9 PM and 12 PM; the date must be set to the
date of the following day.
**
Pull out the crown to position III
(the watch stops).
**
I II III Turn the crown until the correct date
4 appears.
** Continue to turn the crown until the
correct time 8:30 PM appears.
**
Push the crown back into position I.
Please note:
*
I II III
* To set your watch to the exact second,
please refer to the chapter entitled «setting
the time».
** Please observe the AM/PM clock rhythm.
1h / 20min / 10 sec.
1 x short
long
1 x short
long
1 x short
long
