RONDA startech 5000
Chronographs, Big Date & Date,
different calendar systems, Alarm
Caliber 5040.B – 12½'''
Product Specifications
Analog quartz movement
Line
Caliber
Size
Version
Swiss Made
Swiss Parts
Standard battery life
Hand fitting height
Features
– Hand Heights 1 and 2
startech
– Very long battery life
5040.B
– Repairable metal watch movement
12½'''
– Power saving mechanism with pullled out stem: Reduction
of consumption approximately 70%
13 Jewels / gold plated
– Very easy handling by two pushers
6 Jewels / nickel plated
54 months
1
Date: 02.11.2020
www.ronda.ch
Page: 1
Advertisement
Related Manuals for Ronda Startech 5000
Summary of Contents for Ronda Startech 5000
- Page 1 RONDA startech 5000 Chronographs, Big Date & Date, different calendar systems, Alarm Caliber 5040.B – 12½''' Product Specifications Features Analog quartz movement – Hand Heights 1 and 2 Line startech – Very long battery life Caliber 5040.B – Repairable metal watch movement Size 12½'''...
-
Page 2: Technical Specifications
Caliber 5040.B – 12½''' RONDA startech Functions Technical Specifications – Chronograph Diameter Total 28.60 mm – Center stop second (1/1 Case fitting 28.00 mm sec) Movement height 4.40 mm – 1/10 second Height over standard battery 4.40 mm – 1/10 seconds up to 30 Movement rest 0.60 mm... - Page 3 10 : 1 (5 : 1) (A3H) the position must be fullfilled. For pusher angles Sous réserve de modifications of 0° (pusher A and B), see drawing 5000.345. cercle d'entourage Aenderungen vorbehalten RONDA Gehäusering 5040.B, 5040.D, 5030.D, 5021.D, 5040.E Modifications reserved movement holder No. 5000.315...
- Page 4 Winkel der Drücker A und B 10° Released Angle of pusher A and B Tolerance +/- 20 µm Ø Dp 10° ±2 Scale 10 : 1 (5 : 1) (A3H) 20° Sous réserve de modifications Aenderungen vorbehalten RONDA 4xxx.x, 5xxx.x Modifications reserved No. 5000.345...
- Page 6 (dimensions / forces) Artikelnummer Tolerance (min) Part number 10:1 (A3) Scale 3000.040 12.00 1.90 2.60 0.90 0.90 1.35 5010.B, 5020.B, 5021.D, 5030.D, Sous réserve de modifications Aenderungen vorbehalten RONDA 5040.B, 5040.D, 5040.E, 5040.F, Modifications reserved 5050.B, 5050.C, 5051.C, 5130.B, 5130.D 5030.019...
- Page 7 Example: Start: Press push-button A. You have decided to buy a watch, which was assembled by a watch- maker using a Ronda movement. Please note that no watches are Stop: to stop the timing, press push- button A once more and read the produced or distributed under the Ronda Brand.
- Page 8 Put the yellow jumper between the two posts on the closer side. 3622.040 Stator Mark |Z| on stator. 3622.039 Stator (counter 6h, 9h, chrono) 3622.039 Stator (counter 6h, 9h, chrono) 3622.039 Stator (counter 6h, 9h, chrono) 10/2013 M RONDA AG, Lausen, Switzerland, Phone ++41 (0)61 926 50 00, www.ronda.ch, info@ronda.ch...
- Page 9 Third wheel 2020.148.G Train wheel bridge Train wheel bridge held by 3 screws 4000.250. 4000.250 Screw 3715.095.RK Rotor 3147.048.CO Intermediate wheel (counter) 3402.006.CO Minute counting wheel 10/2013 M RONDA AG, Lausen, Switzerland, Phone ++41 (0)61 926 50 00, www.ronda.ch, info@ronda.ch...
- Page 10 3603.034 Battery insulator 3612.144.5040 Electronic module Electronic module held screws 4000.248. Electronic measurements may be realised now. 4000.248 Screw 3603.069 Circuit insulator 3601.107.G Pusher contact spring 10/2013 M RONDA AG, Lausen, Switzerland, Phone ++41 (0)61 926 50 00, www.ronda.ch, info@ronda.ch...
- Page 11 2130.137.G.M01.5040B Electronic module cover Electronic module cover held by 3 screws 4000.250. 3600.010.HGF Battery 395 3601.109.G Bridle + Bridle held by 1 screw 4000.250. 4000.250 Screw 10/2013 M RONDA AG, Lausen, Switzerland, Phone ++41 (0)61 926 50 00, www.ronda.ch, info@ronda.ch...
- Page 12 Tensioning the spring arm. Tens jumper maintaining plate held by 2 screws 4000.306. 4010.306 Screw 3301.241 Hour wheel (Aig.1) 3315.016 Friction spring 3004.224.CO Date indicator driving wheel 3500.049 Date jumper 10/2013 M RONDA AG, Lausen, Switzerland, Phone ++41 (0)61 926 50 00, www.ronda.ch, info@ronda.ch...
- Page 13 Date mechanism maintaining plate Date mechanism maintaining plate held by 2 screws 4000.250 4000.250 Screw 3506.072.G Dial support 8200 Moebius 8200 9014 Moebius 9014 Jismaa 124 9020 Moebius 9020 10/2013 M RONDA AG, Lausen, Switzerland, Phone ++41 (0)61 926 50 00, www.ronda.ch, info@ronda.ch...
- Page 14 -10s/M. .. +20s/M. 1.20 V Lower working voltage limit Setting stem in position III, 60 s measuring interval: 0.10 µA Typical consumption Maximal consumption 0.30 µA 10/2013 RONDA AG, Lausen, Switzerland, Phone ++41 (0)61 926 50 00, www.ronda.ch, info@ronda.ch EM 1...
- Page 15 1.68 kΩ .. 1.88 kΩ Coil resistance M4 ∞ kΩ Coil isolation M1/M2/M3/M4 Signal generator (4.9 ms, 8 Hz): Lower working voltage limit 1.20 V M2/M3/M4 10/2013 RONDA AG, Lausen, Switzerland, Phone ++41 (0)61 926 50 00, www.ronda.ch, info@ronda.ch EM 2...
