Summary of Contents for MF DIGITAL ScribeEC
- Page 1 SCRIBE EC NO PRINTER QUICK INSTALLATION GUIDE...
-
Page 2: Minimum System Requirements
• High quality recordable CD-Rs / DVD-Rs • *One free PCI slot for DVD system, two free PCI slots for CD system (refer to Appendix A). • One external COM Port (COM1 or COM2) for the ScribeEC loader. • IEEE-1394 B Adapter (Included). •... - Page 3 Mounting the Firewire Adapter Card Note: The internal configuration of your computer may be different from the computer picture below DVD dive ScribeEC requires only one PCI firewire B controller card (IEEE-1394B). 1. Shut down the PC. 2. Turn the PC’s power off.
-
Page 4: Making The Connection
* Firewire cable to PC cables to PC PC Connection Power cable RS232 to ScribeEC USB cable (used with OptiEC PRO) Note: * Firewire cables For additional information on to ScribeEC the firewire connection refer to Appendix A Page 4... - Page 5 Scribe EC no Printer Installation Guide Document Revision: 2004/12/28 Installing the SCRIBE EC Software 1. Insert the SCRIBE EC software CD. From the CD ROM drive of the computer, click Install SCRIBE Software. (fig. 1) Click Next (fig. 1). 4. Accept the license agreement and click Next (fig.
- Page 6 Scribe EC no Printer Installation Guide Document Revision: 2004/12/28 Installing the SCRIBE EC Alignment Utility 1. Insert the SCRIBE CD into the CD- ROM drive of your PC. 2. Click on setup.exe of the alignment utility and Click Next (fig. 1). 3.
- Page 7 Scribe EC no Printer Installation Guide Document Revision: 2004/12/28 Aligning the Drive Tower 1. From your Start Menu Open the SCRIBE EC Alignment Utility (fig. 1). It will be located in the folder designated when you installed the alignment utility. Choose the appropriate COM Port number that the Scribe EC loader is connected to and then choose “All other printer type or drive bay”...
- Page 8 Scribe EC no Printer Installation Guide Document Revision: 2004/12/28 Appendix A DVD8Z-9001EC, DVD8Z-9002EC 1 and 2 DVD drive system requires only one PCI firewire B controller card (IEEE- 1394B) to be installed in a host PC. One firewire B cable is connected between a host PC and a drive bay.
-
Page 9: Troubleshooting
Troubleshooting 1. The ScribeEC program did not recognized a loader. a. Check the power cable on the back of the ScribeEC loader. b. Make sure the power switch in the power supply of the loader is in ON position (the I is pressed in).
