- Page 1 5906 LX1 Quick Connect Guide 5906 Series www.mfdigital.com...
- Page 2 Scribe EC Quick Installation Guide Document Revision: 2004/12/07 Document Revision: 6/15/2005 with Prism PLUS Printer Connection Using a cross-over cable and ethernet ports from each machine, connect the LX1 to the MF Digital unit with the cross-over cable. Page 2...
-
Page 3: Operation
LX1 Quick Connect Guide Scribe EC Quick Installation Guide Document Revision: 2004/12/07 Document Revision: 6/15/2005 with Prism PLUS Printer Operation Power up PRV-LX1 and MF Digital unit Once MFD unit is powered up, click on "localhost Page 3... - Page 4 LX1 Quick Connect Guide Scribe EC Quick Installation Guide Document Revision: 2004/12/07 Document Revision: 6/15/2005 with Prism PLUS Printer In "localhost" click "send FTP image" The FTPTREE dialog box will pop up. Page 4...
- Page 5 LX1 Quick Connect Guide Scribe EC Quick Installation Guide Document Revision: 2004/12/07 Document Revision: 6/15/2005 with Prism PLUS Printer Here you enter the IP address, username and password of the LX1 unit Enter the IP address of the LX1. The default IP address set by Pioneer is 192.168.0.16 Page 5...
- Page 6 LX1 Quick Connect Guide Scribe EC Quick Installation Guide Document Revision: 2004/12/07 Document Revision: 6/15/2005 with Prism PLUS Printer Enter the User Name for the LX1. The default User Name set by Pioneer is PRVUser [case sensitive] Page 6...
- Page 7 LX1 Quick Connect Guide Scribe EC Quick Installation Guide Document Revision: 2004/12/07 Document Revision: 6/15/2005 with Prism PLUS Printer Enter the Password for the LX1. The default Password set by Pioneer is prv-lx1, [case sensitive] Page 7...
- Page 8 LX1 Quick Connect Guide Scribe EC Quick Installation Guide Document Revision: 2004/12/07 Document Revision: 6/15/2005 with Prism PLUS Printer **Note, the Pioneer factory settings can change, refer to the PRV-LX1 manual for IP Address, Username and Password configurations Click "Browse Site" and the LX1 directory will appear Page 8...
- Page 9 LX1 Quick Connect Guide Scribe EC Quick Installation Guide Document Revision: 2004/12/07 Document Revision: 6/15/2005 with Prism PLUS Printer Click "imagefiles" on the PRV-LX1 directory to retrive DVD image Once the DVD image is selected/highlighted click "OK" Page 9...
- Page 10 The FTPTREE dialog box will automatically close and the LCD simulation display will show "receiving image XXX MBs" on the "localhost" tab of the MF Digital software This indicates the DVD image selected is now being transferred to the MF Digital unit.
