Summary of Contents for Vivotek SF8172V
-
Page 2: Package Contents
Do not insert sharp or tiny objects Do not drop the Network Camera. into the Network Camera. Package Contents SF8172V Mounting Plate / Screwdriver Alignment Stickers Screws / Desiccant Bag / Double-sided Tape / Rubber Seal... -
Page 3: Physical Description
Physical Description Contacts for Internal Microphone (B) Inner View Lens Spring Contacts (A) Align (B) to (A) when attaching the dome cover Header (J6) Ethernet 10/100 RJ45 Header (J7) Socket Status LEDs Reset Button Outer View MicroSD/SDHC/SDXC Card Slot IP66-rated Vandal-proof Dome Cover Built-in Microphone 083236... -
Page 4: Hardware Installation
Hardware Installation First, use the supplied screwdriver to loosen the four screws and detach the dome cover from the camera base. Then, follow the steps below to install the camera to either a ceiling or a wall. Tamper-proof Screw Remove the stoppers and route cables through the openings. -
Page 5: Connecting Dc Power Cable
3. You will need an RJ45 crimping tool to attach the Ethernet wires to a connector. When done, connect the cable to the camera’s Ethernet RJ45 socket. o: white/orange stripe O: orange solid g: white/green stripe B: blue solid b: white/blue stripe G: green solid br: white/brown stripe BR: brown solid... -
Page 6: Ceiling Mount Installation
IMPORTANT: Refer to the "Panoramic PTZ Installation Guide" in your product CD for design considerations before you proceed with physical installation. Attach Camera to Mounting Adapter To attach the camera to AM-51A mounting adaptor, Hole marked as D+ 1. Remove the camera's top cover. 2. - Page 7 Install to the Ceiling 1. Drill pilot holes into the ceiling. Then hammer four anchors into the holes. 2. Secure the pendant head to the ceiling using four screws. 3. Connect the two white header connectors to the J6 and J7 connectors. 4.
-
Page 8: Wall Mount Bracket Installation
Wall Mount Bracket Installation Below is a sample procedure using a wall mount bracket and a pendant pipe: 1. Determine a hard surface ceiling location. Use the four mounting holes on the wall mount bracket to mark the positions where holes will be drilled to secure the bracket and routing cables. Note that screws are user-supplied and they should be at least 11mm long. -
Page 9: Network Deployment
7. Install the speed dome camera next to the fisheye, with their lens positioned at approximately the same height. For details about speed dome installation, please refer to its documentation. 8. Connect all cabling, including the IO cables to J6 and J7, and the Ethernet cable to RJ-45 connector. 9. -
Page 10: Power Over Ethernet (Poe)
Power over Ethernet (PoE) When using a PoE-enabled switch The Network Camera is PoE-compliant, allowing transmission of power and data via a single Ethernet cable. Follow the below illustration to connect the Network Camera to a PoE-enabled switch via Ethernet cable. NOTE: 1. -
Page 11: Assigning An Ip Address
2. The program will conduct an analysis of your network environment. After your network is analyzed, please click on the “Next” button to continue the program. 3. The program will search for VIVOTEK Video Receivers, Video Servers, and Network Cameras on the same LAN.
