Vivotek SF8174/74V Specifications

Fisheye
Network Camera
SF8174/74V
5MP • 360° Surround View • IP66 •
IK10 • Pixel Calculator • Panoramic PTZ
VIVOTEK SF8174/74V are the latest fisheye fixed dome network
cameras featuring a detailed 5-Megapixel resolution sensor with
superb image quality. Equipped with a fisheye lens for 360° surround
view (ceiling/floor/table mount) without blind spots, the camera is
able to provide coverage of wide, open areas, such as airports,
shopping malls, parking lots, retail stores, offices and more.
As with all VIVOTEK true day/night cameras, the SF8174/74V feature
removable IR-cut filters, maintaining clear images 24 hours a day.
SF8174V's IP66-rated housing is designed to help the camera body
withstand rain and dust and ensures operation under a multitude of
harsh weather conditions; additionally, the vandal-proof IK10-rated
housing effectively provides robust protection from physical damage.
Together with 802.3af compliant PoE, MicroSD/SDHC/SDXC card
slot for on-board storage and EN50155 (SF8174V only), the
SF8174/74V are indisputably the top choice for constructing a robust
surveillance system with the greatest coverage possible.
Moreover, SF8174/74V are compatible with the VIVOTEK Panoramic
PTZ solution. Panoramic PTZ is a groundbreaking new technology
developed by VIVOTEK for monitoring open areas with extreme
detail. This feature is realized through the synergy of a VIVOTEK
megapixel fisheye camera with a speed dome camera, and allows
users to simultaneously monitor an area overview from a fisheye
model while providing the capability for a detailed regional view from
a speed dome. Suitable applications for Panoramic PTZ include
department stores, station lobbies, airports, parking lots, and any
wide open areas where comprehensive video surveillance systems
and the capability for extreme video detail are essential.
Features
● 5-Megapixel CMOS Sensor
● 30 fps @ 1080p Full HD
● 1.5 mm Fisheye Lens for 180° Panoramic View and
360° Surround View
● Panoramic PTZ Compatible
● Removable IR-cut Filter for Day & Night Function
● EN50155 Compliance for Professional Mobile Surveillance (SF8174V)
● Real-time H.264, MPEG-4, and MJPEG Compression (Triple Codec)
● WDR Enhancement for Unparalleled Visibility in Extremely
Bright or Dark Environments
● Vandal-proof IK10-rated and Weather-proof IP66-rated
Housing (SF8174V)
● ePTZ for Data Efficiency
● Built-in 802.3af Compliant PoE
● Built-in MicroSD/SDHC/SDXC Card Slot for On-board Storage
● Pixel Calculator for Image Clarity Measurement
City Surveillance
Panoramic View
Mall
