Pro-Form 14.0 Re Elliptical Manual page 14

17. Have a second person hold the Handlebar (10)
near the Upright (5).
See the inset drawing. Locate the Pulse Wire
(135) in the Handlebar (10). Insert the Pulse
Wire into the front of the Upright (5) and pull it
out of the hole in the Upright as shown.
Tie the end of the wire tie to the Upright Wire
(60) and the Pulse Wire (135). Then, insert the
other end of the wire tie upward through the
Handlebar (10). Next, pull the upper end of the
wire tie until the Upright Wire and the Pulse Wire
are routed through the Upright.
18. Tip: Avoid pinching the wires. Attach the
Handlebar (10) to the Upright (5) with two M8 x
16mm Screws (102).
17
Wire
Tie
60, 135
18
102
14
10
135
10
5
Avoid pinching
the wires
10
5
5
