12. Tip: Avoid pinching the wires. Attach the Rear
Upright Cover (24) to the Upright (5) with four M4
x 16mm Screws (93). Tip: It may be necessary
to bend the upper end of the Rear Upright
Cover gently into place around the Upright.
13. Orient the Front Upright Cover (25) as shown.
Attach the Front Upright Cover (25) around the
Upright (5) by pressing it into the Rear Upright
Cover (24).
14. Identify the Right Front Leg Cover (30).
Attach the Right Front Leg Cover (30) to the
Right Upper Body Arm (8) with two M4 x 16mm
Screws (93).
Repeat this step on the other side of the
elliptical.
12
Avoid pinching
the wires
24
13
5
24
14
32
12
5
93
25
8
30
93
