Introduction
The DP Industrial PCI Express Serial Adapter Card
is a high-speed serial card that provides
additional serial ports to your system.
Key Features and Benefits
•
Provides serial ports to PCI Express enabled
system.
•
Supports serial port data transfer rate up to
921.6Kb/s
•
Built-in 15KVDC ESD serial interface
protection
•
Built in 128-byte FIFO buffer for ID-E80011-
S1 & ID-E80111-S1; built-in 256-byte FIFO
buffer for ID-E20211-S1
•
Built in H/W, S/W data direction flow
control
04-0821B
DP Industrial PCI Express
Serial Adapter Card
Quick Installation Guide
1
Advertisement
Table of Contents
Related Manuals for SIIG PCI Express Serial
Summary of Contents for SIIG PCI Express Serial
-
Page 1: Quick Installation Guide
DP Industrial PCI Express Serial Adapter Card Quick Installation Guide Introduction The DP Industrial PCI Express Serial Adapter Card is a high-speed serial card that provides additional serial ports to your system. Key Features and Benefits • Provides serial ports to PCI Express enabled system. -
Page 2: System Requirements
® Vista (32-/64-bit) / XP (32-/64-bit) / Server 2003 & 2008 (32-/64-bit) / Server 2008 R2 / 2000 Package Contents • DP Industrial PCI Express Serial Adapter Card • Connector adapter cable: For ID-E20211-S1: 2x RJ-45 to DB9 (male) cable For ID-E80011-S1 &... - Page 3 Layout JP1* JP2* RJ 45 port * NOTE: Short JP1 and JP2 for 120 ohm terminal resistance to get signal reflection elimination. Figure 1: ID-E20211-S1 Layout Figure 2: ID-E20211-S1 Jumper Setting...
- Page 4 VHDI68 port Figure 3: ID-E80111-S1 Layout Figure 4: ID-E80111-S1 Jumper Setting - RS-422/485...
- Page 5 Figure 5: ID-E80111-S1 Jumper Setting - RS-232 VHDI68 port Figure 6: ID-E80011-S1 Layout...
-
Page 6: Db9 Pin Assignment
Pin Assignment ID-E20211-S1 Pin Assignment RJ-45 Pin Assignment RS-485 RS-485 RJ45 Pin# RS-422 (4-wire) (2-wire) RxD-(A) RxD+(B) TxD-(A) Data-(A) TxD+(B) Data+(B) Figure 7: ID-E20211-S1 RJ-45 pin assignment DB9 Pin Assignment RS-485 RS-485 DB9 Pin# RS-422 (4-wire) (2-wire) TxD-(A) Data-(A) TxD+(B) Data+(B) RxD-(A) RxD+(B) - Page 7 ID-E80011-S1/ID-E80111-S1 Pin Assignment DB9 Pin Assignment Figure 9: ID-E80011-S1 DB9 Pin Assignment Note: for RS-485 (2-wire), need to control input(RTS) and output(DTR). IMPORTANT: Please loop pin 1 and pin6, pin4 and pin7 when using RS-485 (2- wire) Figure 10: ID-E80111-S1 DB9 Pin Assignment...
- Page 8 VHDI68 Pin Assignment Figure 11: ID-E80011-S1 / ID-E80111-S1 VHDI68 Pin Assignment - RS-232 Mode...
- Page 9 Figure 12: ID-E80111-S1 VHDI68 Pin Assignment - RS-422/485 (4-wire) Mode...
-
Page 10: Hardware Installation
Hardware Installation General instructions for installing the card are provided below. The design of computer cases and motherboards may vary, refer to your computer's reference manual for further information, if needed. Static Electricity Discharge may permanently damage your system. Discharge any static electricity build up in your body by touching your computer's case for a few seconds. - Page 11 To install the card, carefully align the card's bus connector with the selected PCIe slot on the motherboard. Push the board down firmly, but gently, until it is well seated. Replace the slot bracket's holding screw to secure the card. Replace the computer cover and reconnect the power cord.
-
Page 12: Driver Installation
Driver Installation This section provides instructions to install the driver for the DP Industrial PCI Express Serial Adapter Card. Make sure the card is installed before beginning the driver installation. Windows 8 (32-/64-bit) / Windows 7 (32-/ 64-bit) / Server 2008 R2 Install the board and boot up Windows. - Page 13 Windows Vista (32-bit) / Server 2008 (32- bit) Install the board and boot up Windows. At Found New Hardware, click Cancel. Insert the driver CD, close AutoPlay box if prompted. Go to Device Manager, right click PCI Serial Port under Other devices. Click Update Driver Software, then click Browse my computer for driver software.
- Page 14 Windows Vista (64-bit) / Server 2008 (64- bit) Install the board and boot up Windows. At Found New Hardware, click Locate and install driver (recommended) For Windows Vista: Click Continue, and click Don't search online. For Server 2008 : Click Don't search online. Insert the driver CD.
- Page 15 Check Include this location in the search, uncheck another box, type D:\PCIe\32bit or D:\PCIe\64bit, then click Next. (Change D: to match your CD/DVD-ROM drive letter) Click Finish. Repeat steps 2-6 to complete the installation. Windows 2000 At Found New Hardware Wizard, click Next.
- Page 16 To Verify Windows Installation Check in Device Manager to verify installation. For Windows 8 / 7 / XP / Server 2008 R2 / 2003 / 2000: Right click Computer or My Computer, click Manage, click Device Manager. For Windows Vista: Right click Computer, click Manage, click Continue, then click Device Manager.
- Page 17 Changing Serial Port Number Some serial port devices need a specific communication port in order to function properly. If your serial port device works, do not make any changes. Right click My Computer, click Manage, then click Device Manager. Double click Ports (COM & LPT), and double click the PCI Express UART Port.
- Page 18 Blank Page...
-
Page 19: Technical Support And Warranty
Go to www.siig.com, click Support, then REQUEST A PRODUCT REPLACEMENT to submit a request to SIIG RMA or fax a request to 510-657-5962. Your RMA request will be processed, if the product is determined to be defective, an RMA number will be issued. - Page 20 Fremont, CA 94538-3152, USA Phone: 510-657-8688 DP Industrial PCI Express Serial Adapter Card is a trademark of SIIG, Inc. SIIG and the SIIG logo are registered trademarks of SIIG, Inc. Microsoft and Windows are registered trademarks of Microsoft Corporation. All other names used in this publication are for identification only and may be trademarks of their respective owners.
