Introduction
The Universal DC Power Adapter - 90W is an auto-switching
90 watt universal laptop DC power adapter with USB
charging port.
Features and Benefits
•
Perfect on-the-road DC power adapter/charger
for most laptop computers
•
Power & charge computer from the car, boat, RV
or the power outlet available on airplanes
•
Includes 5V USB charging port for charging mobile
phones, PDA, iPod, etc.
•
Includes 12 adapter tips for a variety of laptop/
notebook computers – including Acer, Asus,
Compaq, Dell, Fujitsu, Gateway, HP, IBM, Lenovo,
Sony, Toshiba & more (optional tips available at
www.siig.com)
•
Coded tips make identifying correct tip to match
laptop computer easy
•
Output voltage settings adjusted automatically
based on adapter tip attached
04-0686B
Universal DC Power
Adapter - 90W
Quick Installation Guide
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for SIIG Universal DC Power Adapter - 90W
Summary of Contents for SIIG Universal DC Power Adapter - 90W
- Page 1 Universal DC Power Adapter - 90W Quick Installation Guide Introduction The Universal DC Power Adapter - 90W is an auto-switching 90 watt universal laptop DC power adapter with USB charging port. Features and Benefits • Perfect on-the-road DC power adapter/charger for most laptop computers •...
-
Page 2: Package Contents
• Do not use the adapter in direct sunlight • Use the Universal DC Power Adapter - 90W in a well ventilation area • Do not open the power adapter under any circumstances. The power adapter is not intended... - Page 3 SIIG website at www.siig.com. Using the Universal DC Power Adapter - 90W The Universal DC Power Adapter - 90W plugs into a standard cigarette lighter outlet to provide reliable power to run your notebook/laptop computer and charge its battery.
- Page 4 Read the following instructions and refer to the Adapter Tip Compatibility List to select the correct tip for your laptop. Note: The Universal DC Power Adapter - 90W is not compatible with Mac notebook/laptop computers Select your notebook/laptop brand and model from the Adapter Tip Compatibility List to find the right adapter tip.
- Page 5 Connect the selected adapter tip to the end of the output cable, make sure that the ridge on the inside of the adapter tip aligns with the groove in the output cable connector. Also, make sure that the adapter tip is pushed all the way into the connector. Plug the Cigarette Lighter Adapter cord into the DC adapter.
- Page 6 Plug the Universal DC Power Adapter - 90W into a reliable cigaretter lighter outlet. Note: The USB charging port does not function like a regular USB port. It will only charge your device. Adapter Tip Specification Tip M1 • Output voltage: 15V •...
- Page 7 Tip M3 • Output voltage: 16V • Voltage range: 15.2 - 16.56V • Output current (max): 5.63A • Connectors: 6.0 x 4.4 x 10.7mm Replacement: voltage and amperage for each notebook the tip can replace. • Sony: 16V/3.42A, 16V/3.75A, 16V/4A •...
- Page 8 Replacement: voltage and amperage for each notebook the tip can replace. • ASUS: 19V/4.74A • Dell: 19V/3.16A, 19V/3.42A • Compaq/HP: 18.5V/4.9A, 19A/4.9A • Toshiba: 19V/3.16A, 19V/3.42A, 19V/4.74A; • Fujitsu: 19V/4.22A • Gateway: 19V/3.16A, 19V/3.42A, 19V/3.68A, 19V/ 4.74A etc • ACER: 19V/4.7A •...
- Page 9 Replacement: voltage and amperage for each notebook the tip can replace. • Acer: 19V/3.16A, 19V/3.42A, 19V/4.74A • Gateway: 19V/3.0A, 19V/3.7A, 19V/4.74A • Compaq/HP: 19V/3.0A • IBM/Lenovo: 19V/4.7A • Dell: 19V/3.0A Tip M8 • Output voltage: 19.5V • Voltage range: 18.72 - 20.18V •...
- Page 10 Tip M10 • Output voltage: 20V • Voltage range: 19.2V - 20.5V • Output current (max): 4.5A • Connectors: 7.3 (OD) x 7.4 (ID) x 8 (L) mm Replacement: voltage and amperage for each notebook the tip can replace. • Dell: 20V/3.5A, 20V/4.5A Tip M11 •...
- Page 11 Adapter Tip Compatibility List ACER Tip M5 Acer Note Series: 367, 390 Extensa Series: 360, 390, 900, ESS3-391, T4120, 5420G, 5620G, 5630G, 7620G, 7630G. Aspire 1300 Series: 1300 (DXV, XC, XV), 1301XV, 1302 (LC, X, XC), 1304 (LC, XC), 1306LC, 1307LC, 1310 (LC, XC), 1312(LC, LM, MX), 1313 (LC), 1314 (LC), 1315 (LC, LM), 1350 (LC, LCe, LM, LMi), 1351(LC, LCi, XC), 1352 (LC, LCe, LCi, XC), 1353 (LC, LCi, LM, LMi, XC), 1354 (LM, LMi),...
- Page 12 4402(WLCI, WLMI), 4404(LMI, WLMI), 4405WLMi, 4670,4730G, 5110, 5220G, 5510, 5520G, 5530G, 5610, 5620, 5710G, 5720G, 5730G, 6410, 6460, 6500, 6592G, 7220(G), 7510, 7520(G), 7530G, 7720G, 7730G, 8200, 8210. Tip M7 Acer TravelMate Series: 345T, 347T, 351TE, 350TE, 352TE, 210 (T, TER), 211T, 212 (T, TE, TXV), 213 (T, TXV), 220, 223 (X, XC), 225 (X, XC, XV-Pro), 230, 233XC, 240, 260, 270 (XV), 280, 290, 330 (T), 340T, 341T, 342, 350, 351TEV, 352TE-N, 353 (TE, TEV), 354 (TE, TEV), 360, 500, 506, 520, 521 (T, TE,TXV),...
- Page 13 6004LMi, 8000, 8000LCi, 8000LMi, 8001, 8001LCib, 8002, 8002 (LC, LCi, LCib), 8003 (LC, LCi, LCib, LM, LMi, LMib), 8004 (LCi, LCib, LM, LMi, LMib), 8005 (LCi, LCib, LMi, LMib), 8006 (LCi, LM, LMi, LMib). TravelMate Alpha: 550 (LC, LV, XV), 551 (XV), a550 (LC, LV, XV), a551 (XV), C300 (XCi, XCi-G), C301 (XCi,XCi-G), C302 (MXi, XMi, XMi-G), C310, K-550.
- Page 14 Compaq / HP Tip M4 Compaq Armada 100 (S), 110, 150, E300, E500 (S), E700, M300, M500, M700, V300, 1500 series. Compaq Evo Series: N110, N150, N160, N180, N200, N400(c), N410c, N600 (c), N610 (c, v), N620c, N800 (c, v, w), N1000 (c, v), N1005V, N1015v, N1010v, N1020 (v), N1050(v).
- Page 15 Special Edition: L2000, L2100, L2200, L2300 series. Compaq Business Notebook: NC8000, NC8100, NC8230. HP/Compaq Notebook PC: 8000 series, 8200 series (NC8230, NX8220), 8400 series (NC8430, NX8420), NC2400, NC4400, NC6000, NC6100 (NC6110, NC6120), NC6200 (NC6220), NC6300 (NC6320), NX6100 (NX6110, NX6115, NX6120, NX6125), NX6300 (NX6310, NX6315, NX6320, NX6325), NX8000 (But not NC8200).
- Page 16 dv8200, dv8300, dv8400, ze2000, ze2100, ze2200, ze4900 series, zt3000, zt3100, zt3200, zt3300, zt4000 series, HP Special edition L2000 series. Tip M7 Contura: 3/20, 3/25, 3/25C, 4/20, 4/25, 4/25C, 4/25CX. Armada: 4100, 4110 (D, T), 4120 (T), 4124D, 4125D, 4130 (T), 4131 (T), 4150 (T), 4160 (T), 4210T, 4220T.
- Page 17 HP/Compaq G: G50, G60, G70, G70T-100 CTO, G70T-200 CTO. HP/Compaq Mini: 2133, 2140, 5101, 5102, MINI-NOTE series. HP/Compaq Probook: 4300, 4310S, 4400, 4410S, 4411S, 4415S, 4416S, 4500, 4510S, 4515S, 4516S, 4700, 4710S, 5300, 5310M series. HP/Compaq Thin Client: 2533T, 4410T series. HP Pavilion: DV3-1000, DV4-1000, DV4-1100, DV4-1200, DV4T-1000, DV4T-1100, DV4T-1200, DV4Z-1000, DV4Z-1100, DV4Z-1200, DV5-1000, DV5-1100, DV5-1200,...
- Page 18 Inspiron: 1150, 1420, 1501, 1705, 1720, 1721, 600m, 3200, 6400, 8500, 8500m, 8600, 9200, 9300, 9400, E1501, E1505, E1705, 300m, 500m, 505m, 510m, 600m, 600mcr, 630m, 640m, 6000, 6400 (E1505), 700m, 710m, 8500, 8600, 8600CR, 9200, 9300, 9400 (E1705). Latitude: 100L, 131L, D400, D410, D420, D430, D500, D505, D510, D520, D530, D531, D531N, D560, D600, D610, D620, D630, D630N, D631, D631N, D800, D810, D820, D830, D830N, X300.
- Page 19 EMachines Tip M4 M2105, M5000, M5105, M5116, M5305, M5309, M5310, M5312, M5313, M5405, M5410, M6805, M6807, M6809, M6810, M6811. Fujitsu Tip M3 Lifebook: Milan, Monte Carlo, Montegro, PenCentra 130, PenCentra 200, Point 1600, Point 510, 270DX, 280DX, 3700X, 400, 420D, 435DX, 500 (SR), 520 (D, T), 530 (T), 531 (T, TX), 535 (T, TX), 555TX, 556TX, 565TX, 585 (T, TX), 600, 635 (T, TX), 655TX, 656TX, 675TX, 690TX, 695, 735DX, 755TX, 765 (DX, TX), 770TX, 780TX, 790TX, A series,...
- Page 20 Siemens Amilo Pro V1 Series: V1000. Siemens Amilo Pro V2 Series: V2000, V2010, V2020, V2030, V2035, V2040, V2045, V2055, V2060, V2065, V2085. Siemens Amilo Pro V3 Series: V3205, V3405, V3505, V3515, V3525, V3545. Siemens Amilo Pro V7 Series: V7010. Siemens Amilo Pro V8 Series: V8010, V8210. Siemens Celcius H Series: H210, H230, H240.
- Page 21 LifeBook S Series: S2210, S6310, S6311, S6410, S7010, S7010D, S7020 (B, D, E), S7021, S7025, S7110, S7111. Gateway Tip M5 Gateway 3000, G93018GZ, 3040GZ, 3520GZ, 3522GZ, 3525GB, 3545GZ, 3550 (GH, GZ), 3610GZ series, 4000 series, 4010 (JP, GZ), 4014GB, 4016JP series, 4023JP, 4024 (GZ, JP), 4025GZ, 4026GZ, 4027JP, 4028 (GZ, JP) series, 4030(GH, GZ), 4046MX series, 4520GZ, 4525GZ, 4528MX, 4529MX series, 4530 (GH, GZ), 4532GB, 4534JP,...
- Page 22 IBM / Lenovo Tip M2 ThinkPad: 130, 235, 240, 240 (X, Z), 290, 310, 360, 365 (CD) CS, CSD, SE, E, ED, X, XD), 370, 380(D, D-MMX, E, ED, XC, XC, XD, XD [Type 2635-Exx], Z [Type 2635-Bxx], Z [Type 2635-Hxx], Z [Type 2635-Jxx]), 385(CD, D, D- MMX, ED, XD, XD [Type 2635-Dxx]), 390 (E, X), 535, 550, 560 (C, E, X, Z), 570(E), 575(E), 600 (A, D, E, X), 660, 701 (C, CS, CX), 770 (D, E, ED, X, Z).
- Page 23 Tip M11 ThinkPad: T60, X60, Z60, Z60M, Z60T, R60. IBM/Lenovo: N100,V100, 3000, C100. Tip M1 Versa LX, Versa LXi, Versa SX, Versa SXi. Tip M5 Ready: 220T, 120LT, 330T, 340T, 360T, 440T, VX. Samsung Tip M6 Samsung P Series: SPA-V20, AD-9019. Samsung: GT9000 series, P series, P10 series, P20 series, NP20 series, P25 series, P30 series, P35 series, NP25 series, P40 series, T10 series, V20 series, V25 series, X20 series,...
- Page 24 VAIO PCG Series: PCG-500, 505, R505, Z505, 1A1N, 1G1N, 5, 6, 7, 8, 181, 384, 3xxx, 4xxx, 500, 5xxx, 6xxx,700, 800, B, C1, CR, F, FX, G, GR, GT, SRX, TR, TR1, U, VX, V505(EC), XR, XG, X505, Z1A, Z1 series. VAIO VGN Series: B1, FZ160E, G1, S2, S1, S3, S5, S6, S7, S9, T, TX, TZ, U, UX, Y70P, Y90PSY, Z1 series.
- Page 25 Satellite M Series: M10, M15, M20, M30, M35, M40, M45, M100, M200, M205. Satellite Pro: 400, Pro 405, Pro 410, Pro 415, Pro 420, Pro 425, Pro 430, Pro 440, Pro 445, Pro 460, Pro 465, Pro 470, Pro 480, Pro 490, Pro 490X, Pro CDX, Pro CDS, Pro 6000, Pro 6050, Pro 6070, Pro 6100.
- Page 26 You can find the correct tip for your laptop by looking in the Adapter Tip Compatibility List. What laptops will this adapter work with? The Universal DC Power Adapter - 90W is compatible with various brands of laptops. For a complete list look on the Adapter Tip Compatibility List.
-
Page 27: Technical Support And Warranty
Step 1: Submit your RMA request. Go to www.siig.com, click Support, then RMA to submit a request to SIIG RMA or fax a request to 510-657-5962. Your RMA request will be processed, if the product is determined to be defective, an RMA number will be issued. -
Page 28: Product Name
Fremont, CA 94538-3152, USA Phone: 510-657-8688 Universal DC Power Adapter - 90W is a trademark of SIIG, Inc. SIIG and the SIIG logo are registered trademarks of SIIG, Inc. Microsoft and Windows are registered trademarks of Microsoft Corporation. All other names used in this publication are for identification only and may be trademarks of their respective owners.
