Icom IC-F51 Instruction Manual page 52

5
BATTERY CHARGING
Optional battery chargers
■
D Rapid charging with the BC-121N+AD-100
The optional BC-121N allows up to 6 battery packs to be charged
simultaneously. The following are additionally required.
• Six AD-100
• An AC adapter (BC-157) or the DC power cable (OPC-656)
43
(purchase separately)
Battery pack
AC adapter
(Purchase
separately)
DC power cable (OPC-656*)
(Connect with a DC power supply;
13.8 V/at least 7 A)
(Continued)
Transceiver
Turn power OFF
CAUTION: NEVER connect the OPC-
*
656 to a power source using reverse po-
larity. This will ruin the battery charger.
Red line: Black line :
AD-100 charger
adapters are installed
in each slot.
