Hard drive

NOTE: The hard drive spare part kit does not include the hard drive connector cable, hard drive
bracket, or screws. The hard drive connector cable is included in the Cable Kit, spare part number
652696-001.
Description
1-TB, 5400-rpm, 12.7-mm
750-GB, 7200-rpm, 7.0-mm
750-GB, 5400-rpm, 7.0-mm
640-GB, 7200-rpm, 7.0-mm
500-GB, 7200-rpm, 7.0-mm
320-GB, 7200-rpm, 7.0-mm
Hard Drive Hardware Kit (includes hard drive bracket and screws)
Before removing the hard drive, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4. Remove the battery (see
5. Remove the memory module/wireless module compartment cover (see
on page
Remove the hard drive:
1. Loosen the captive screw (1) that secures the hard drive compartment cover to the computer.
Battery on page
44).
41).
Component replacement procedures
Spare part number
638974-001
633252-001
634250-001
621046-001
634925-001
634862-001
653525-001
WLAN module
55
