2. Adjust the desired room temperature (if required)
by momentarily pressing on the up or down arrow
TEMPERATURE SET BUTTON's (17) until the
desired temperature is displayed. Each press of
the button will increase or decrease the desired
temperature by 1 degree. The desired temperature
may be set in the range of 16 - 32 degrees.
3. Press the ON / OFF BUTTON (1) to commence
operation. The OPERATION INDICATOR (2) will
illuminate.
4. Select the desired fan speed (if required) by
pressing the FAN SPEED SELECTOR BUTTON
(19).
5. To turn the air conditioner off simply press the ON /
OFF BUTTON (1). The OPERATION INDICATOR (2)
will turn off.
PROGRAM DRY MODE (see Fig. 3)
When the air conditioner is operated in this mode the
microprocessor will give priority to reducing the
humidity level rather than the room temperature.
(Please note that there may still be some reduction in
room temperature depending on ambient conditions).
This mode is normally used in very humid
environments where the conditions may still be
uncomfortable even though the room temperature is
fairly low. The air conditioner will not enter the dry
mode if the room temperature is below 16°C.
1. Press the MODE SELECTION BUTTON (20) (if
required) until the DRY MODE INDICATOR (
is displayed.
2. Press the ON / OFF BUTTON (1) to commence
operation. The OPERATION INDICATOR (2) will
illuminate.
3. To turn the air conditioner off simply press the ON /
OFF BUTTON (1). The OPERATION INDICATOR (2)
will turn off.
Please note that the SELECTED TEMPERATURE DISPLAY (8)
and FAN SPEED DISPLAY (9) will not appear during PROGRAM
DRY operation.
FAN MODE (see Fig. 2)
When the air conditioner is operated in the FAN MODE
only the indoor fan is energised. The outdoor unit will
not operate and therefore heating or cooling will not
be
provided. This mode is useful for circulating the air
within the building.
1. Press the MODE SELECTION BUTTON (20) (if
required) until the FAN MODE INDICATOR (
displayed.
2. Press the ON / OFF BUTTON (1) to commence
operation. The OPERATION INDICATOR (2) will
illuminate.
3. Select the desired fan speed (if required) by
pressing the FAN SPEED SELECTOR BUTTON
(19).
TEST
TEST
4. To turn the air conditioner off simply press the ON /
OFF BUTTON (1). The OPERATION INDICATOR (2)
will turn off.
Please note that the SELECTED TEMPERATURE DISPLAY
(8) will not appear during FAN MODE operation.
PROGRAM TIMER
The air conditioner can be programmed to
automatically turn on or off in 1 hour increments up to
72 hours in advance. It may also be programmed to
turn on for a determined time then off again or vice
versa provided that the last operation (ie. switch on or
)
off) is within 72 hours.
PROGRAMMING THE START / STOP TIME
(see Fig. 4)
1. Press the TIMER MODE START/STOP BUTTON
(13) once to enter the program STOP mode, or
twice to enter the program START mode. The
symbol "O" indicates STOP , and "|" START. The
PROGRAM START/STOP TIME INDICATOR (7) will
flash.
2. Select the desired START/STOP TIME by
momentarily pressing on the up or down arrow
PROGRAM TIME BUTTON's (16) until the desired
elapsed time is displayed. Each press of the button
will increase or decrease the elapsed time by
1hour.
3. Once the desired START/STOP TIME is displayed
press the PROGRAM TIMER ON/OFF BUTTON
(14).
) is
The PROGRAM START or STOP TIME INDICATOR
(7) will stop flashing and remain displayed.
4. Operate the air conditioner in the desired mode as
described above. The PROGRAM START/STOP
TIME INDICATOR (7) will count down towards zero.
When zero is reached the air conditioner will start
or stop operating depending on the program set.
2
hr
C
L H
hr NOT
AVAILABLE
8
Fig. 3
1
9
20
7
