DAIKIN ROOM AIR CONDITIONER
Operation Manual
OPTIONAL SLENDER
REMOTE CONTROLLER
Use wisely, save power
Thank you very much for purchasing the Daikin room air
conditioner.
This manual contains precautions and economical use of
your air conditioner.
For correct use of your air conditioner, please read this
manual carefully before use and keep it at hand for easy
reference.
Fill out the warranty card and store it in a safe place.
BRC944B2
READ BEFORE OPERATION
Safety Precautions ........................2
Corresponding Functions .............4
Preparation before Operation .......5
OPERATION
Operation ......................................7
Adjusting Airflow Direction ............9
ONE TIME Timer .........................11
DAILY Timer ................................13
CARE
Cleaning ......................................15
Advertisement
Table of Contents
Related Manuals for Daikin BRC944B2
Summary of Contents for Daikin BRC944B2
-
Page 1: Table Of Contents
Timer Operation ONE TIME Timer ......11 DAILY Timer ........13 Use wisely, save power CARE Thank you very much for purchasing the Daikin room air conditioner. Cleaning ........15 This manual contains precautions and economical use of your air conditioner. For correct use of your air conditioner, please read this manual carefully before use and keep it at hand for easy reference. -
Page 2: Safety Precautions
• Do not attempt to repair, relocate, modify or reinstall the air conditioner by yourself. Incorrect work or modifications could cause electric shocks, fire or other damage. For repairs and reinstallation, consult your Daikin dealer for advice and information. • If the air conditioner is not cooling (heating) properly, the refrigerant may be leaking, contact your authorized dealer or qualified service repairman. - Page 3 • Arrange the drain hose to ensure smooth drainage. Improper drainage may cause water damage to the building, or it’s furnishing. • Depending on the usage environment, water may leak from the air conditioner. If this happens, contact your Daikin Dealer.
-
Page 4: Controller Commands And Their Corresponding Functions
Controller Commands and their Corresponding Functions Run indicator lamp (green) ON/OFF button Display Press to start the system. Displays the operating Displays the operating Press again to stop the system. conditions. conditions. Timer select button Mode select button Selects one of the following: ONE TIME timer ON Selects an operation mode. -
Page 5: Preparation Before Operation
Preparation before Operation Checking the power If nothing appears on the remote controller's display, turn on the circuit breaker. Setting the current time Press The current time starts blinking. lights up. 1 . 3 Press and set the current time. Hold the button down to rapidly advance the time. - Page 6 Preparation before Operation Setting Temperature Indication change Temperature indication can be changed between Celsius and Fahrenheit before use. To change from Celsius temperature indication to Fahrenheit one Press and hold down at the same time for 5 seconds while the Celsius temperature is indicated.
-
Page 7: Automatic · Dry · Cooling · Heating Operation
Automatic · DRY · Cooling · Heating Operation Select your desired operation mode. Once preset, the system can get restarted in the same operation mode. Run indicator lamp (green) Press to select your desired operation mode. Each time the button is pressed, the mode changes as follows. - Page 8 To adjust the temperature and airflow rate: Operation Automatic Cooling Heating mode Setting to be adjusted Temperature is adjustable. Temperature Recommended temperature cannot be Cooling : 26°C-28°C (79°F~82°F) adjusted. Heating : 20°C-22°C (68°F~72°F) (Temperature) Five levels of airflow rate setting from "...
-
Page 9: Adjusting Airflow Direction
Adjusting Airflow Direction Adjust the airflow direction for maximum comfort. To adjust the Airflow Direction Press during operation . Each time the button is pressed, the airflow direction louvers change their movement. Wall Mounted Types (without horizontal swing function) The horizontal airflow direction louvers Swing move up and down. - Page 10 Wall Mounted Type (with horizontal swing function) The horizontal airflow direction louvers Swing horizontally move up and down. The horizontal airflow direction louvers Swing vertically stop just when the button is pressed. Then the vertical ones start moving right and left. Airflow direction The vertical airflow direction louvers louvers stop...
-
Page 11: Timer Operation
Timer Operation The Timer Operation feature automatically turns off operation when you go to sleep and turns it back on when you wake up. Use the DAILY Timer mode on weekdays, and the ONE TIME timer mode on weekends. To select the ONE TIME timer mode: Press to select the ONE TIME... - Page 12 ONE TIME timer Once the timer has been activated and then deactivated, it is in the OFF mode. The ON or OFF timers can be programmed. Press to select the ONE TIME timer. Press blinks. ONE TIME light up. Press Press to make the OFF timer setting.
-
Page 13: Daily Timer
Timer Operation To select the DAILY timer mode: Timers Two pairs of ON and OFF time Press to select the DAILY timer mode. settings can be programmed. Each time the button is pressed, the modes change as follows. ONE TIME timer ON time 24-hour timer display DAILY timer... - Page 14 DAILY timer After programming, the system starts and stops each day at the preset times. Two pairs of time settings can be programmed. (Example: 8:00 10:00, and 18:00 23:00) DAILY timer indication appears. lights up. Press to select the DAILY timer. Make the ON and OFF time settings.
-
Page 15: Cleaning
Cleaning Cleaning the remote controller Wipe it clean with soft, dry cloth. Do not use any water hotter than 40°C (104°F), or volatile liquids such as benzine, gasoline and thinner, polishing powder, or anything hard such as a scrub brush. When the unit is not used for a long time On a sunny day, keep the system running for half a day in the FAN mode to dry it up inside. - Page 16 Two-dimensional bar code is a code for manufacturing. 3P202922-2B AK HT M08B096(0807)
