3. The system operates but it does not sufficiently
cool or heat.
!
Check if the air inlet or outlet of the indoor or the
outdoor unit is blocked with obstacles.
Remove the obstacle and make it well-ventilated.
!
Check if the air filter is clogged.
Clean the air filter(s). (Refer to MAINTENANCE)
!
Check if the set temperature is not proper. (Refer
to OPERATION PROCEDURE)
!
Check if the FAN SPEED CONTROL button is set
to LOW SPEED. (Refer to OPERATION
PROCEDURE)
!
Check if the doors or the windows are open. Shut
doors or windows to prevent wind from coming in.
!
Check if direct sunlight enters the room.
(when cooling) Use curtains or blinds.
!
When there are too many occupants in the room.
(when cooling) Cooling effect decreases if heat
gain of the room is too large.
!
Check if the heat source of the room is excessive.
(when cooling) Cooling effect decreases if heat
gain of the room is too large.

USER MAINTENANCE

IMPORTANT!
!
NO USER SERVICEABLE PARTS ARE INSIDE THE
AIR CONDITIONER. DO NOT REMOVE ANY ACCESS
PANELS OR FIXED COVERS.
!
Before cleaning the air conditioner, be sure to stop
operation, and turn the power switch off. Otherwise,
an electric shock and injury may result.
!
Do not wash the indoor unit with water.
Doing so may result in an electric shock.
!
Be careful with a scaffold or staging.
Caution must be exercised because of work at a high
place.
CLEANING THE AIR FILTER(s)
!
Be sure to always clean the air filter(s) before use at
the beginning of summer and winter. (Dirt and dust
caught in the air filter causes a drop in airflow, which
leads to a decline in performance.)
!
When using the unit in a location where dirt may easily
accumulate, clean the filter(s) more frequently. Once
every 2 weeks is recommended.
NOTE
The air filter(s) and the suction grille(s) are supplied by
your dealer.
Ask your DAIKIN dealer how to clean them.
HOW TO CLEAN AIR OUTLET GRILLE
!
Clean with soft cloth.
!
When it is difficult to remove stains, use water or neutral
detergent.
NOTE
!
Do not use gasoline, benzene, thinner, polishing
powder, liquid insecticide. It may cause discoloring or
warping.
!
Do not let the indoor unit get wet. It may cause an
electric shock or a fire.
MAINTENANCE OF THE OUTDOOR UNIT
!
Regularly inspect the outdoor unit to ensure the heat
exchanger coil (aluminium fins) and fan outlet are not
obstructed by vegetation or any other foreign objects.
!
Clean the outdoor unit heat exchanger coil annually or
as required by location or outdoor air quality. The coil
may be cleaned by spraying the fins with low pressure
water in a downwards direction (ie. simulating heavy
rain). Alternatively have the work done by your installer.
!
Regularly check the paint work of the outdoor unit for
scratches or signs of corrosion. Apply touch up or
anti-corrosion paint as necessary.
START UP AFTER A LONG STOP
Confirm the following
!
Check that the air inlet and outlet are not blocked.
Remove any obstacle.
Clean the air filter(s) and outside grille
!
After cleaning the air filter, make sure to reattach it.
Turn on the main power supply switch
!
The display on the remote controller will be shown
when the power is turned on.
!
To protect the unit, turn on the main power switch at
least 6 hours before operation.
WHAT TO DO WHEN STOPPING THE SYSTEM
FOR A LONG PERIOD
Turn on FAN OPERATION for a half day and dry the unit.
!
Refer to "FAN OPERATION".
Cut off the power supply.
!
When the main power switch is turned on, some
power is being used even if the system is not operating.
Turn off the main power supply switch for saving energy.
!
The display on the remote controller will vanish when
the main power switch is turned off.
11
