Caring For The Astro 220 System - Garmin Astro Dog Tracking System Owner's Manual

Appendix
of the dog's movements. These tracks can be transferred
to MapSource on your computer using the Astro 220 as a
wireless transfer device to a computer.
To transfer dog unit (DC 30) tracks:
1. Open Garmin MapSource Trip and Waypoint Manager.
2. Connect the Astro 220 to a computer using the USB
cable provided. Turn the Astro 220 on.
3. Turn the DC 30 on and place it within 12 inches of the
Astro 220.
4. Open the Dog Information page on the Astro 220
(page 9).
5. Press MENU > Transfer Dog Unit Track
Wait until the track data is buffered in to your
Astro 220 and "Ready to communicate with PC"
appears.
6. Go to MapSource, and click the Tracks tab on the left
side of the screen.
7. Click Receive from Device
MapSource.
0
> ENTER.
from the Transfer menu in
8. Check Tracks in the Receive from Device
and click Receive.
9. When "The Data was successfully received" appears,
click OK in MapSource.
10. Press ENTER on the Astro 220.

Caring for the Astro 220 System

Cleaning the Case
Clean the outer casing of each unit (except for the
Astro 220 screen) using a cloth dampened with a mild
detergent solution, and then wipe it dry. Avoid cleaners
that may damage the plastic components.
Cleaning the Astro 220 Screen
Clean the Astro 220 screen using a soft, clean, lint-free
cloth. Use water, isopropyl alcohol, or eyeglass lens
cleaner. Apply the liquid to the cloth, and then gently
wipe the screen with the moistened cloth.
Astro Dog Tracking System Owner's Manual
window
