This is a digital video camera of exceptional quality and value. You will be able
to capture videos and edit pictures; then send and share them with friends and family.
This digital video camera not only functions as a digital camera for taking
pictures, but is also able to record video and audio. You can also connect to the
computer and function as a webcam.
This manual will introduce you to using your digital video camera and how to
install the accompanying software. Use this manual to learn how to use this digital
video camera to take pictures, record video, record audio, send pictures and video to
your computer, as well as hot to function as a webcam.
This digital video camera is your best choice and companion for whenever you
wish to exchange pictuers and clips through e-mail, create a photo album, record
video, or even chat face to face with your family and friends on the Internet.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Easypix Digital
Summary of Contents for Easypix Digital
- Page 1 This is a digital video camera of exceptional quality and value. You will be able to capture videos and edit pictures; then send and share them with friends and family. This digital video camera not only functions as a digital camera for taking pictures, but is also able to record video and audio.
-
Page 2: Table Of Contents
Ba ck … … … … …… … … … …… … … … … …… … … … …… … … … … …… … … … …5 Le ft……… ……………… …………… ……………… ……………… ………………… 6 Bottom………………………………………………………………………………………7 Battery status indicator…………………………………………………………………………7 3. How to use digital video camera…..…..……………..………8 Preparations before operation………………………………………………………………8 4. Begin to use digital video camera………………………………………9 Function list…………………………………………………………………………………9 Vide o mo de ……………………………………………………………………………11... - Page 3 P r e st o ! M r. P h o t o 3 … … … … … … … … … … … … … … … … … … … … … … … 3 3 XviD 1.03 codec installation………………………………………………………………33 8. Digital recording specifications……………………………..…37 9. Troubleshooting…..…..………………..…………….…..….…..38...
-
Page 4: Precautions
●Copyright related issues All images captured by digital video camera, unless authorized by the rights holder, shall not violate copyright laws. In addition, if filming is prohibited for live performances and exhibitions, even if just for personal use filming is not allowed. Memory card transfers of data and copyrighted images should be bound within the range of copyright lays and not be exceeded. -
Page 5: Precautions Before Operation
3. Please wipe the digital video camera exterior with a soft dry cloth and do not use cleaners or volatile solutions, or the digital video camera exterior shell and paint will disfigure and deteriorate. -
Page 6: Understanding Digital Video Camera
4.Microphone Back: Power/Busy indicator - when the digital video camera is powered on, the power indicator will be lit (green). When the system is busy, the busy indicator will flash (red). Up button(▲) – select up in different menus, selects the previous file in playback mode, increase the volume during playback of video and audio. -
Page 7: Left
1.Power/BUSY indicator 2.Up button（▲） 3.Confirm button（■） 4.Zoom IN button 6.Zoom OUT button 5.Down button（▼） 7.Video mode button 12.TV-OUT port 8.Photo mode button 9.Power on/off button 13.USB port 10.Audio mode button 11.Playback mode button Left: Rewind button- fast rewind during video playback. Play/stop button –... -
Page 8: Bottom
Bottom: Battery cover latch –press in and push the battery cover out to open the battery compartment cover. Battery compartment SD/MMC card slot Battery cover 4.Battery cover 1.Battery 2.Battery coverlatch compart 3. SD/MMC card slot Battery status indicator: full charge half charge battery power low no power... -
Page 9: How To Use Digital Video Camera
Note: When inserting the memory card into the digital video camera, the camera has to be powered off. Turn on the power to the camera after the memory card is inserted and the internal 32MB memory will be deactivated automatically. -
Page 10: Begin To Use Digital Video Camera
4. Begin to use your digital video camera ●Step one Press the Power switch button, and the power indicator light will automatically light up. When the power indicator light is lit, release the power switch button. Function list Video mode... - Page 11 Audio mode Audio mode LCD display: normal/off/all Audio recording Playback mode Playback mode LCD display: normal/off Previous/Next Audio playback Volume adjustment play/stop Photo playback play/stop Video playback Volume adjustment Play/stop FF/RW Playback menu Delete file: delete single file/delete all files Protect file: protect single file/protect all files Undo file protection: undo single file protection / undo all file protections...
-
Page 12: Vide O Mo De
Color effects Image quality Battery status Image size Digital zoom status Built-in storage status Hotkey menu Under the video mode, continuously press the Confirm button■ to select the shortcut functions: you can apply the following to the video to be captured: mage file size, exposure, video quality, white balance, color effect setups. -
Page 14: Video Menu
Video menu Under Video mode, press the MENU button to enter the Video menu. Under the Video menu page, possible controls are as below Select image size: 1. Press the up button ▲ or down button ▼ to select the size option and press the confirm button■. -
Page 15: White Balance Type
Press the MENU button to return to Video mode. Begin capturing: ●Step 1 Press the shutter to begin recording and the recorded image will appear on the screen; press the ZOOM-IN or ZOOM-OUT buttons to perform digital zoom. Press shutter Press shutter... -
Page 16: Photo Mode
●Step 2 Press the shutter during recording to stop, or automatically stop recording when memory is full. Photo mode , to enter photo mode Press mode button [STILL] Status indicator: Photo mode indicator Flash mode White balance status Color effects File quality Battery status Time display Digital zoom Built-in memory status Image size... -
Page 17: Hotkey Menu
Hotkey menu: Under photo mode, press Confirm button■ to select shortcut functions: you can apply the following to the video to be captured: image size, exposure, image quality, white balance, auto timer, color effect setup etc. After pressing the confirm button ■, press the up button ▲ or down button ▼... -
Page 18: Photo Menu
Photo menu: Setup the desired options before filming. Press MENU button to access the photo menu. The control procedures are as below: Select image size: 1. Press up button ▲ or down button ▼ to select image size option, then press the confirm button ■. -
Page 19: Exposure Adjustment
How to take pictures: ●Step one Make sure the digital video camera is turned on ●Step two Aim the digital video camera at the object to capture, and view the filming angle from the LCD screen ●Step three Press the shutter, when capturing a picture, the LCD displayed image will freeze until it is saved into memory. -
Page 20: Audio Mode
Audio mode Press mode button [VOICE] to enter audio mode Status indicator: Audio mode indicator Battery status Memory status Begin recording: Under audio mode, press the shutter to begin recording, then press the shutter to stop recording. Press shutter... -
Page 21: Playback Mode
Playback mode Press the playback button to enter the playback mode If there are no files present, the display will be as below: Otherwise it will display the current file, and press up button ▲ anddown button▼ to browse other files. Photo indicator Audio indicator Video indicator... -
Page 22: Video Playback
Video playback: 1. Press up button▲ or down button▼ to select the video to playback, and then press the Play button to begin playback (this camera supports MP4 format). To playback video clips not recorded by the camera, please rename the file in the format MPEG0001 before copying onto the camera. -
Page 23: Audio Playback
Recording playback: 1: Under playback mode, use the up button▲ or down button▼ to select the audio file. After the file has been selected, press Play button to begin playback. If the user wishes to playback audeo clips not recorded by the camera, please rename the file in the format WAVE0001 before copying onto the camera. -
Page 24: Delete Single File
Return to playback menu: Under playback mode, press the MENU button to returnto the menu page. Delete single file 1. Press up button ▲ or down button ▼ to select the single audio choice to delete, then press the confirm button ■. 2. -
Page 25: Protect All Files
Protect all files 1. Press the up button▲ or down button▼ to select the lock all option, then press confirm button■. 2. Press the up button▲ or down button▼ to confirm or cancel selection, then press confirm button■. If confirm is selected then all files will be protected and the upper right of the LCD will show a locked icon , otherwise no action will be taken and is returned to the main menu. -
Page 26: Dpof
DPOF：DPOF can directly print out the photos stored on the SD card through a DPOF supported printer. DPOF set single 1. Press up button ▲ or down button ▼ to select the “DPOF” option, then press the confirm button ■. 2. -
Page 27: Direct To Print (Dps)
■ to go to the print all interface. 2. At the print all interface, with the hint to connect to printer, connect the digital video camera to printer with the USB cable. Wait for the OK and then press the confirm button ■ to begin printing. -
Page 28: Setup Mode
Setup mode Press the MENU button under any mode (except for Audio mode) to enter the menu for each mode, then press DISP/SET button to enter Setup mode. At the setup mode, the user can modify the followng options: 1. Date/Time 2. Beep 3. Format 4. Default 5. Memory Status 6. Language 7. TV System 8. Auto Power off 9. -
Page 29: Sounds
Beep: Set to on or off, controls as below: Format: Confirm to delete all data in memory. Controls are similar to Sounds setup. Default: Confirm to use factory defaults. Controls are similar to Sounds setup. Memory Status: Show total video/photo/audio files and available space Language: English/Traditional Chinese/Simplified Chinese/French/German/Italian/Japanese/ Spanish/Russian/Korean/Turkish/Portuguese/Dutch/Arabic TV System: Set the video signal format (NTSC/PAL). -
Page 30: Video Output
(such as: TV), the method is as below: ●Step one Insert the black plug of the TV cable to the TV port on the back of the digital video camera, and the yellow plug to the video in of the TV. -
Page 31: How To Connect To Pc
“AA” batteries Note: Please make sure to connect the USB cable properly to prevent damage. ●Step two Connect the smaller end of the USB cable plug to the USB port on digital video camera ●Step three Connect the larger plug of the USB cable to the USB port on the PC... -
Page 32: System Requirements
For Microsoft Windows98SE/Me users, please connect the larger USB plug to the PC USB port and the other end to the digital video camera USB port after installing the drivers and application software. When the camera enters the “connection to PC” page, press the up button ▲ or down button ▼... -
Page 33: Driver Installation And Software Applications
PC webcam. Removable storage The digital video camera is able to provide removable storage functions as a card reader. You can use this camera as an SD card, removable disk. If your operating system is Windows 98SE, you will need to install the camera drivers. Windows XP/ME/2000 operating systems supports Plug-and-play and does not require manual installation of drivers. -
Page 34: P R E St O ! Vi D E O Wo R K
Press the install button to install the drivers. Please follow the on screen instructions. Press “finish” to restart the PC and complete the driver installation. Load the driver 1. Insert the included CD into the CD-ROM. 2. If the CD does not auto-run, use Windows file manager to run the executable InstallMgr.exe under the root directory on the CD. - Page 35 3. Press the install button and the installation screen will be shown, please press “Next” to continue. 4. At the EULA screen, please select “I accept the agreement” and then press “Next” to continue. 5. Please follow the instructions and use “Browse” to choose the installation path to use, press “Next”...
- Page 36 6. Please choose the name of the folder to install program, press “Next” to continue. 7. At the install additional tasks screen, press “Next” to continue. 8. At the ready to install screen, press “Install” to begin installation.
- Page 37 9. Install in progress. To stop installation, please press “Cancel”. 10. The screen below will be shown after installation is complete, press “Finish” to end program installation.
-
Page 38: Digital Recording Specifications
8. Digital video camera specifications: Digital video camera specifications: ●Lens: f=7.35mm ●Sensor: 5.17Mega pixel cmos sensor ●Aperture: F / 3.2 ●Exposure: ISO 100 ●White balance setting: Auto, sun light, light bulb, florescent light, cloudy ●Shutter speed: 1/10 sec ~ 1/500 sec ●Storage format: Built-in 32MB, Flash Memory SD Card (MMC compatible) slot (maximum... -
Page 39: Troubleshooting
Do not attempt to disassemble and please return for repair. For error messages appearing when entering direct printing service, you Error message should remove the USB plug from the digital video camera and check when entering whether the printer is functioning properly; and the digital video camera is direct printing sufficiently charged.
