Easypix GoXtreme Race User Manual

Action camcorder
Hide thumbs Also See for GoXtreme Race:

Advertisement

Quick Links

Download this manual
ACTION CAMCORDER
Functions
Functions
This user's manual has referred to the latest information we had when this user's manual was made. The screen
display and illustrations are used in this user's manual for the purpose of introducing details of this digital camera
in a more specific and direct way. Difference may arise between these displays and illustrations and the digital
camera actually available for you due to difference in technological development and production batch, under
which case, the actual functions of this video camera shall prevail.

Advertisement

loading
Need help?

Need help?

Do you have a question about the GoXtreme Race and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Easypix GoXtreme Race

Summary of Contents for Easypix GoXtreme Race

  • Page 1 ACTION CAMCORDER Functions Functions This user's manual has referred to the latest information we had when this user’s manual was made. The screen display and illustrations are used in this user's manual for the purpose of introducing details of this digital camera in a more specific and direct way.
  • Page 2 Announcements Announcements Please read the Announcements carefully before using this video camera for proper and safe operation, so as to bring its optimum performance into play and extend its service life. u Do not expose the video camera to sunshine directly, nor point its lens to sunlight. Otherwise, the image sensor of the video camera may be damaged.
  • Page 3 agent of video camera for wiping if necessary. Do not use organic solvent to clean the video camera. u Do not touch the lens surface with fingers. u Please back up the data if the memory card inside this video camera is used for the first time. u...

  • Page 4: Waterproof Case Using Notice

    Waterproof Case Using Notice Waterproof Case Using Notice u Before sealing the waterproof case, keep the camera housing’s rubber seal clean, a single hair or grain of sand can cause a leak. You can test by closing the case without inserting the camera. Submerse the case completely in water for about a minute.

  • Page 5: System Requirements

    System Requirements System Requirements System Requirements Operating System Microsoft Windows2000, XP, Vista, 7 Intel Pentium III of more than 800MHz or other CPU with equivalent performance Internal Memory Larger than 512MB Sound Card and The sound card and display card shall support DirectX8 or higher Display Card version.

  • Page 6: Introduction To Appearance And Keypad

    Introduction to Appearance and Keypad Introduction to Appearance and Keypad Lens Memory card slot LCD TFT Reset Working Indicator Light USB slot Indicator Light for charging Power button Wrist strap eyelet Shutter button Mode Switch:...
  • Page 7 Usage Usage 1. Charge the built-in lithium battery Indicator Light for charging is on. USB Cable Connect the video camera with computer for charging in the shutdown state. The indicator light for charging is on at this time and will be off after charging. In general, it can be fully charged after 2-4 hours.
  • Page 8 Use of Memory Card Push the memory card into the card slot according to the concave lettering beside the slot of memory card till it is completely inserted. To take out the memory card, gently press the end of the memory card inward and it will pop up. Note: No built-in memory is available in this video camera.
  • Page 9 Startup/Shutdown 3.1 Startup: Press the POWER button for 3 seconds, the screen is displayed and the camera is on. 3.2. Shutdown: Press the POWER Key, and the camera will be shut down. . Automatic shutdown: when the idle time of the video camera reaches the time for automatic shutdown, it will be shut down automatically to save power.
  • Page 10 Conversion between Function Modes Three modes are available for this video camera, i.e. picture taking mode, video recording mode and vehicle-mounted mode. Conversion is available via the mode switch after startup. Picture taking mode: pictures can be taken; Video recording mode: video can be recorded; Vehicle-mounted mode: videotape can be recorded.
  • Page 11 Indicator light Busy light: when the camera is busy (such as, recording a film, taking photos, automatic off-screen), the busy light will be on. Charging light: when the light is on for a long time, it prompts the user that the camera is charging. Video recording mode When the mode switch is turned to video recording mode, press the shutter button once or click the LCD center once to begin recording under previewing state;...
  • Page 12 : digital zoom icon, click it and enlarge it. : digital zoom icon, click and minify it. : visual shutter, touch this visible frame for taking photos or recording. : battery icon, represents the power status of the battery. : represents the status of digital zoom. : click this icon to switch to the playback mode.
  • Page 13 : digital zoom icon, click it to enlarge. : digital zoom icon, click it to minify. : visual shutter, touch this visible frame for taking photos or recording. : battery icon, indicates the power status of the battery. : represents the status of digital zoom. : click this icon to switch to the playback mode.
  • Page 14 : mode icon, representing that the camera is in vehicle-mounted mode. : video size, click this icon to select 720P, VGA. : represents that the memory card has been inserted . : digital zoom icon, click it to enlarge. : digital zoom icon, click it to minify. : visual shutter, touch this visible frame for taking photos or recording.
  • Page 15 Playback mode: 9.1 After starting up and entering the previewing state, click the playback icon ( ) at the lower right corner of the LCD to switch to the playback mode: Click : represents that the current file is an AVI video file. : represents that there is one file in the current folder/one file in total.
  • Page 16 Click to pause playing, click to play forward, and click to play backward. 9.3 File deletion: Click YES to delete the current file immediately, or click NO to cancel the request of deletion.
  • Page 17 Apply on the personal computer Connect to personal computer The camera is provided with the plug and play function. Connect the device to the computer with USB line under turning-on state, then it will be switched into the movable hard disk mode. Icon of movable disk will appear on the window of “my computer”.

  • Page 18: Technical Parameters

    Technical parameters Image sensor 1.3 million pixel (CMOS) Function mode videoing, taking photos, vehicle-mounted mode, removable disk Camera lens F3.1 f=9.3mm Digital zooming 4 times Shutter Electronic shutter LCD display screen 2.0-inch touch screen Image resolution 5M (2592×1944), 3M (2048×1536), 1M(1280×1024) Video resolution VGA: 640x480 (60 frames/second), 720P:1280x720 (30 frames/second) White balance...
  • Page 19 This symbol indicates that the relevant electrical product or battery should not be disposed of as general household waste in Europe. To ensure the correct waste treatment of the product and battery, please dispose them in accordance to any applicable local laws of requirement for disposal of electrical equipment or batteries.
  • Page 20 DECLARATION OF CONFORMITY Easypix herebly declares that the product GoXtreme Race is in conformity to all the essential requirements of Directive 1999/5/EC. The declaration of conformity can be downloaded here: http://www.easypix.info/download/pdf/doc_goxtreme_race.pdf For technical help please visit our support area on www.easypix.eu.
