GCL-MT
MEDIUM-DUTY TROLLEY OPERATOR
The GCL-MT is designed for standard-lift sectional
doors that have a limited-duty cycle requirement.
Advanced features and robust mechanical design
combine to provide a medium-duty operator that is
the new standard in the industry
UL325-2010 APPROVED
• Allows for monitored entrapment protection and
momentary operation when used with select photo eyes
and/or edge-sensing devices.
• See back for approved list of monitored devices.
GCL-MT Advantages
• Rated for 15 cycles per hour operation. Maximizing the
performance out of a medium-duty operator.
• Modular design with optional expansion boards for
advanced timer to close, and auxiliary output functionality.
• Optional: Intellicode
I plug and play receiver learns up to
®
50 transmitters. Learn and delete individual transmitters
directly from LCD display.
• TensiBelt
primary drive reduction eliminates need to
adjust belt tension.
• Available in either 115V or 230V AC 1Ø 60Hz.
Expanded offering increases applications available for
medium-duty use.
• Motor with built-in thermal protection and ball bearing
drive end. Provides overload protection and bearings
extend life of motor over typical bushings.
• LCD display with intuitive setup menu. Provides real-time
status and trouble-shooting assistance.
• Open/close/stop and setup keys included on control
board. Keeps all controls near the LCD display convenient
for set up.
www.GenieCompany.com/commercial
GCL-MT operators are covered by the following U.S. patents: 7355363, 7878931, 8014966
GENIE
CoMMErCIAL opErATors
®
Standard Features
• 11.5 inches per second door speed.
• Optical limit system with linear travel nuts.
• Max run timer automatically adjusts to up and down run time.
• TensiBelt
primary reduction.
• Delay on reverse.
• 16-character LCD display.
• UL325-2010 approved.
• Drawbar disconnect for emergency manual operation.
• 3-button control station.
• 2-year/20,000-cycle warranty.
• Programmable mid-stop.
|
800.843.4084
