Genie GCL-MH Product Manual

GCL-MH
MEDIUM-DUTY HOIST OPERATOR
The GCL-MH is designed for high or full-lift
sectional and rolling doors that have a limited-duty
cycle requirement. Advanced features and robust
mechanical design combine to provide a medium-duty
operator that is the new standard in the industry.
UL325-2010 APPROVED
• Allows for monitored entrapment protection and momentary
operation when used with select photo eyes and/or
edge-sensing devices.
• See back for approved list of monitored devices.
GCL-MH Advantages
• Rated for 15 cycles per hour operation, maximizing the
performance of a medium-duty operator.
• Modular design with optional expansion boards for advanced
timer to close, and auxiliary output functionality.
• Optional: Intellicode I plug and play receiver learns up to 50
®
transmitters. Learn and delete individual transmitters directly
from LCD display.
• TensiBelt ™ primary drive reduction eliminates need to adjust
belt tension.
• Available in either 115V or 230V AC 1Ø 60Hz. Expanded offering
increases applications available for medium-duty use.
• Motor with built-in thermal protection and ball bearing drive end.
Provides overload protection and bearings extend life of motor
over typical bushings.
• LCD display with intuitive setup menu. Provides real-time status
and trouble-shooting assistance.
• Open/close/stop and setup keys included on control board.
Keeps all controls near the LCD display convenient for set up.
www.GenieCompany.com/commercial
GCL-MH operators are covered by the following U.S. patents: 7355363, 7878931, 8014966
GENIE CoMMErCIAL opErATors
®
Standard Features
• Optical limit system with linear travel nuts.
• Max run timer automatically adjusts to up and down run time.
• TensiBelt primary reduction.
™
• Delay on reverse.
• 16-character LCD display.
• UL325-2010 approved.
• 3-button control station.
• 2-year/20,000-cycle warranty.
• Programmable mid-stop.
• Emergency hoist for manual operation. Available in right hand only.
| 800.843.4084
