- Page 1 ® Intel Carrier Grade Server TIGI2U & ® Intel IP Network Server NSI2U Tested Hardware and Operating System List Revision 1.3 September, 2006 Enterprise Platforms and Services Marketing...
-
Page 2: Revision History
No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted by this document. Except as provided in Intel's Terms and Conditions of Sale for such products, Intel assumes no liability whatsoever, and Intel disclaims any express or implied warranty, relating to sale and/or use of Intel products including liability or warranties relating to fitness for a particular purpose, merchantability, or infringement of any patent, copyright or other intellectual property right. -
Page 3: Table Of Contents
Table of Contents Table of Contents 1. Introduction .......................... 1 Test Overview......................1 1.1.1 Basic Installation Testing ..................1 1.1.2 Adapter / Peripheral Compatibility and Stress Testing ..........2 Pass/Fail Test Criteria ..................... 3 2. Base System Definitions ..................... 4 3. -
Page 5: Introduction
This document is intended to provide users of the Intel Carrier Grade Server TIGI2U and the ® Intel IP Network Server NSI2U with a list of the operating systems, adapter cards, and ® peripherals tested by Intel on this server platform. The Intel Carrier Grade Server TIGI2U and ®... -
Page 6: Adapter / Peripheral Compatibility And Stress Testing
• Intel will NOT provide support for issues related to use of any add-in adapters or peripherals installed in the server system when an operating system that received basic installation testing only is in use. -
Page 7: Pass/Fail Test Criteria
Intel will enable vendors to provide driver support for add-in adapters using these operating systems. • Intel will go through some of the steps to achieve certification to ensure its customers do not run across any problems, but the actual certification is the responsibility of the individual customer. -
Page 8: Base System Definitions
The adapters and peripherals specified in this document may or may not have been tested on all available board/riser combinations that make up the TIGI2U and the NSI2U product family. However, Intel will provide support for the adapters and peripherals listed when used within this family of products This table is updated when a new test run is performed and a new product/system software combination was used. -
Page 9: Supported Operating Systems
The following table provides a list of supported operating systems for the Intel® Carrier Grade Server TIGI2U and the Intel® IP Network Server NSI2U. Each of the listed operating systems was tested for compatibility with the Intel® Server Board SE7520JR2 in the base system configurations listed in section 2 of this document. -
Page 10: Operating Systems Supported But Not Tested
Operating Systems Supported but not Tested With THOL HW Listed below are the operating systems that Intel has tested only to install and boot properly on the platform. No testing has been done with any of the hardware contained within this Tested Hardware and Operating System document. - Page 11 Supported Operating Systems Operating System Certification Listing Comments SE7520JR2 Board http://bugzilla.redhat.com/hwcert/show.cgi?id=1648 Red Hat* Enterprise Linux 4.0 TIGI2U Server http://bugzilla.redhat.com/hwcert/show.cgi?id=1802 SuSE* Linux Enterprise Server 9, Service Pack 1 SuSE* Linux Enterprise Server 9, Service Pack 2 http://wdb1.sco.com/chwp/owa/hch_model_cert_pa ge?f_model_id=98382&f_release_id=600&f_vendo SCO Unixware 7.1.4 r_search_corp_id= Revision 1.3...
-
Page 12: Adapters And Peripherals
IHVT (IHV Tested) peripherals listed in this document, regardless of whether this adapter or peripheral was tested in an Intel lab or not. IHV test reports remain the property of the IHV (Intel cannot provide copies of these reports). Any variations to the standard adapter installation process or to expected adapter functionality are documented in the Installation Guidelines section of this document. - Page 13 Adapters and Peripherals Testing of adapters cards normally is performed with unused add-in adapters and onboard controller expansion ROMs disabled in BIOS Setup. Intel recommends that customers disable the option ROM for add-in controllers and/or the on-board controllers when not booting from the controller or needing to use its built in utilities.
-
Page 14: Pci Scsi Raid
ASR-2120S PCI-64/66 Similar Adapter ASR-2200S BIOS:7.0.5.D ICP* vortex GDT8514RZ GDT8514RZ PCI-64/66 FW:2.44.02-RC7B BOS:7.05b ICP vortex GDT8524RZ GDT8524RZ PCI-64/66 FW:2.44.02-RC7B BIOS: G401 Intel SRCU41L SRCU41L PCI-64/66 FW:314G BIOS:H423 Intel SRCU42E Rumley PCI-E x8 FW:514F BIOS:7.05C Intel SRCU42L SRCU42L PCI-64/66 2,3 2,3 FW:2.42.02-R07A... -
Page 15: Pci Scsi
SA 9500S-8 AMCC/3ware 9500S-4LP 9500S-4LP PCI-X66 SA 9500S-8 AMCC/3ware 9500S-8ML 9500S-8ML PCI-X66 SA 9500S-8 ICP Vortex GDT8586RZ GDT8586RZ PCI-64/66 BIOS:7.05D FW:2.44.02- RC7B Intel SRCS14L SRCS14L PCI-64/66 BIOS:7.05C FW:2.42.02-R07A Intel SRCS16 SRCS16 PCI-64/66 BIOS:G401 FW:713N Intel SRCS28X SRCS28X PCI-X133 BIOS:H425 FW:813G... -
Page 16: Pci Mromb
1,2,3 2,3 1,2,3 1,2,3 FW:1.3.39 LSI Logic LSI20320-R LSI20320-R PCI-X133 Similar Adapter LSI22320-R LSI Logic LSI22320E-R LSI22320E-R PCI Express PCI MROMB Intel SRCZCRX Palo Verde PCI-X133 BIOS:H424 FW:413Z LSI Logic MegaRAID SCSI 320- MegaRAID SCSI 320-0 PCI-64/66 BIOS:G119 0 (520-0) FW:1Z37... -
Page 17: Pci Nic
PCI NIC 3COM* 3C905C-TX-M EtherLink 10/100 PCI PCI 32/33 ND 1,2 3COM 3C980C-TXM EtherLink Server PCI-32/33 ND 1,2 10/100 PCI Managed Intel PILA8470D3 PRO/100+ S Server PCI-32/33 2,3 2,3 Intel PILA8470C3 PRO/100+ S Server PCI-32/33 Similar Adapter PILA8470D3 Intel PILA8472C3... -
Page 18: Modems
Adapters and Peripherals Manufacturer Model Number Model Name Interface Comments Intel PWLA8490MF PRO/1000MF Gigabit PCI-X133 Similar Adapter Server Adapter PWLA8490MT Intel PWLA8490XT PRO/1000XT Gigabit PCI-X133 1,2,3 2,3 2,3 Server Adapter Intel PWLA8490XF PRO/1000XF Gigabit PCI-X133 Similar Adapter Server Adapter PWLA8490XT... -
Page 19: Cdrom Drives
Adapters and Peripherals Manufacturer Model Number Model Name Interface Comments Rainbow* SRB10741/ERB01221 Sentinel Duo Hardware USB Security Key 1,2 LOGITECH* 930582-0121 Optical mouse PS/2 and USB Mouse LOGITECH 930582-0403 Optical mouse PS/2 and USB Similar Adapter 930582-0403 LOGITECH 967233-0121 Internet Navigator PS/2 and USB Keyboard LOGITECH... -
Page 20: Dvd Drives
Adapters and Peripherals Manufacturer Model Number Model Name Interface Comments 4.10 DVD and Combo Drives Panasonic CW-8123B CW-8123B PIONEER* DVR-S606 DVR-S606 USB2.0 Sony DRX-510UL DRX-510UL USB2.0 Sony CRX835-L1 CRX835-L1 ATA33 Teac DV-28E-BP3 DV-28E-BP3 ATA33 Teac DW-224E-C98 DW-28E-C98 ATA33 3, 4 Teac DV-W28EA-593 DV-W28EA-593... -
Page 21: 4.13 Kvm
Note: Blue shading indicates that the adapter or peripheral is either available or will be available in a lead-free version. Manufacturer Model Number Model Name Interface Comments 4.13 KVM Avocent* 1160ES 1160ES PS/2 Belkin* F1DA108T Omniview PRO2 Series PS/2 [1],2 [1],2 Note: Blue shading indicates that the adapter or peripheral is either available or will be available in a lead-free version. -
Page 22: Hard Disk Drives
Note that not all hard drives were tested under all operating systems. The following notation is used in the tested hard drives table below to indicate the support level that Intel provides for a particular hard drive with a particular operating system: This hard drive has been tested and is supported under the operating system Number (i.e. - Page 23 Intel® Carrier Grade Server TIGI2U & Intel® IP Network Server NSI2U Hard Disk Drives Tested Drive size Manufacturer Model Number Product Family Interface Operating Notes (GB) Systems SCSI Hard Drives Fujitsu* MAP3147NC SCSI/U320 10,000 147GB Fujitsu MAP3367NC SCSI/U320 10,000 36GB...
- Page 24 Hard Disk Drives Tested Drive size Manufacturer Model Number Product Family Interface Operating Notes (GB) Systems Maxtor 8D073J0 Atlas 10K V SCSI /U320 10,000 73GB Maxtor 8D147J0 Atlas 10K V SCSI /U320 10,000 147GB Maxtor 8C073J0 Atlas 15K SCSI/U320 15,000 73GB QSJNZ3 Maxtor...
- Page 25 Intel® Carrier Grade Server TIGI2U & Intel® IP Network Server NSI2U Tested Drive size Manufacturer Model Number Product Family Interface Operating Notes (GB) Systems Western Digital WD360GD WD Raptor SATA/150 10,000 36GB Note: Blue shading indicates that the adapter or peripheral is either available or will be available in a lead-free version Revision 1.3...
-
Page 26: Installation Guidelines & Test Notes
Installation Guidelines & Test Notes Installation Guidelines & Test Notes LSI* Add-in RAID Card Option ROM Utility Access Issue Issue: The system will hang when the BIOS assigns PMM segment 2FE00 and the user tries to enter into the Ctrl-M RAID configuration utility. Implication: A user may be unable to access the option ROM utility (Ctrl-M) for the following LSI adapters: MegaRAID* 320-2, MegaRAID 320-1, MegaRAID 320-0,...
