GARLAND COMMERCIAL INDUSTRIES
185 East South Street
Freeland, Pennsylvania 18224
Phone: (570) 636-1000
Fax: (570) 636-3903
Part # 4526029 (02/22/11)
Part # 4526029 (02/22/11)
SERVICE MANUAL
MODUL-LINE
BUILT-IN INDUCTION COOKERS
86037
MODEL: IN/MO 7000
GARLAND COMMERCIAL RANGES, LTD.
1177 Kamato Road, Mississauga, Ontario L4W 1X4
CANADA
Phone: 905-624-0260
Fax: 905-624-5669
C
CM
Enodis UK LTD.
5E Langley Business Centre
Station Road, Langley SL3 8DS Great Britain
Phone: 01753 485900
Fax: 01753 485901
© 2008 Garland Commercial Industries, Inc.
Page 1
Advertisement
Table of Contents
Related Manuals for Garland 7000
Summary of Contents for Garland 7000
- Page 1 1177 Kamato Road, Mississauga, Ontario L4W 1X4 CANADA Phone: 905-624-0260 Fax: 905-624-5669 Enodis UK LTD. 5E Langley Business Centre Station Road, Langley SL3 8DS Great Britain Phone: 01753 485900 Fax: 01753 485901 © 2008 Garland Commercial Industries, Inc. Page 1...
- Page 2 Page 2 Part # 4526029 (02/22/11)
-
Page 3: Table Of Contents
Repair by Garland ........ -
Page 4: Section 1 - Requirements
SECTION 1 – REQUIREMENTS Authorized Personnel The operator has to insure that all installation, maintenance and inspection work is carried out by authorized and qualifi ed personnel who has done a training course at Inducs Ltd. “Operation Instructions“ Knowledge In order to do service work on an induction generator, the operator must have an extended knowledge of the “Operating Instructions“. -
Page 5: Section 2 - System Description
SECTION 2 – SYSTEM DESCRIPTION Block Schematic 23VAC 208VAC L1,L2,L3 230VAC heatsink coil Part # 4526029 (02/22/11) 230VAC 300VDC filter coil c014 ST2/3,4 ST1/1,4 supply 24VDC c026 24VDC 1x,2x,3x,4 x c014 ST2/1,2 c018 Relay 24VDC 24VDC 230VAC Page 5... -
Page 6: Voltage Supply
Voltage Supply The power board voltage supply is wired with the power contactor. On starting the generator, voltage is supplied to the power board. The transformer is connected directly at the entrance of the power supply. The transformer supplies two diff erent voltages: 230VAC for the power contactor and the fan as well as 23VAC for the low voltage supply. -
Page 7: Error Messages
Error Messages LED 8 LED 7 LED 6 Code — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —... -
Page 8: Section 3 - Initial Operation
SECTION 3 – INITIAL OPERATION Function control To check the function controls, the induction generator must be totally connected. Display 1. The external lamps must be checked. 2. The operation lamp fl ashes if a coil is not used (Searching function). -
Page 9: Section 4 - Trouble Shooting And Repairs
SECTION 4 – TROUBLE SHOOTING AND REPAIRS This section includes a list of the main errors, their causes and the respective steps to correct. Trouble Shooting Error-Code Problem Code No. No coil current Hardware overcurrent High coil current Software overcurrent S03 Temperature heat sink Temperature cooking platform... - Page 10 Problem Code No. S06 Inside temperature Cooking platform Sensing element Communication error (Serial interface) Legend: W = Who should complete “Measure” E = End user L = Supplier Page 10 Possible Cause Normal operation Ambient temperature too high CPU-circuit board defective Sensing element Coil temperature...
-
Page 11: Additional Errors
Additional Errors Problem Code No. Cooking platform does not heat enough Cooking platform continuously on maximum power Empty cooking platform switches “on“ Little metallic objects are heated on the cooking platform Cooking platform does not heat at all Legend: W = Who should complete “Measure” E = End user L = Supplier Part # 4526029 (02/22/11) Possible Cause Operation lamp is continuously “ON”... -
Page 12: Repair Of Problems
Problem Code No. Unit does not heat, no reaction, contactor does not work Building fuses blow when unit is switched on Some cooking platforms do not heat Unit does not heat, no reaction, no contactor Legend: W = Who should complete “Measure” E = End user L = Supplier Repair Of Problems Measure •... - Page 13 Measure • Measure the resistance of coil temperature sensor resistor at 25º Celsius (77º F) resistor will read 1kOhm at 180º Celsius (356ºF) resistor will read 3,5kOhm • Resistor is higher on a higher temperature (PTC-resistor) • Replace sensor with a value less than 900Ohm •...
-
Page 14: Adjustments
Please note the positions of the power switches from the above table. Type Switch setting MO/DU 7000, 208V MO/DU 7000, 400V Pan detection The potentiometer on the rectifi er circuit board is used to adjust the pan detection: Page 14 2. -
Page 15: Section 5 - Appendix
SECTION 5 – APPENDIX Internal Connections Rectifi er Circuit Board C014 View solder side poti for pan detector 230V Venti Part # 4526029 (02/22/11) Page 15... -
Page 16: Cpu-Circuit Board C018
CPU-Circuit Board C018 View components side field 4(8 field 4(7 field 3(6 coil- field 3(5 sensor field 2(4 field 2(3 field 1(2 field 1(1 field 4(8 field 4(7 field 3(6 heatsink- field 3(5 sensor field 3(4 field 2(3 field 1(2 field 1(1 field 4(8 field 4(7... -
Page 17: Power Circuit Board C026
Power Circuit Board C026 View components side adjustment IGBT pre drive Coil connection field 1 Part # 4526029 (02/22/11) power Connection current with measure field 1 c018 – signal POT1-4 und ST5 logic board power adjustment field 2 IGBT pre drive optional Coil connection... -
Page 18: Transformer
Transformer supply transformer for logic board contactor ignition and fan Rectifi er And Transistor Module solder side view rectifier board Item . 1: rectifier Page 18 230VAC outlet (fan) 230VAC outlet (contactor ignition) mains supply voltage ( 208V/ 230V / 400V AC) 23VAC outlet (logic supply) C2/E1 solder side view... - Page 19 Part # 4526029 (02/22/11) Page 19...
