NB 3000
EXERCISE BIKE
Assembly Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NB 3000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Nautilus NB 3000

Summary of Contents for Nautilus NB 3000

  • Page 1 NB 3000 EXERCISE BIKE Assembly Manual...
  • Page 2 TOOLS AND HARDWARE ASSEMBLY INSTRUCTIONS STEP 1: Attaching the Front Stabilizer Description Quantity Phillips Head Screw M5 (12mm) Hex Bolt M8 (90mm) Flat Washer Allen Bolt M8 (16mm) Spring Washer Allen Bolt M8 (20mm) Spring washer Attach the front stabilizer (#8) to the frame (#1), using two washers (#13), two spring washers (#25) and two hex bolts (#12).

  • Page 3: Assembly Instructions

    NB 3000 EXERCISE BIKE ASSEMBLY INSTRUCTIONS STEP 2: Attaching the Rear Stabilizer STEP 3: Assembling Handlebar & Console Mast Attach the rear stabilizer (#9) to the frame (#1), using two washers (#13), two spring washers (#25) and two hex bolts (#12).
  • Page 4 NB 3000 EXERCISE BIKE ASSEMBLY INSTRUCTIONS STEP 4: Attaching Computer Console STEP 5: Attaching Water Bottle Cage Plug the upper computer wire (#21) and the hand grip wire (#70) into the com- Install the bottle bracket (#65) into the shroud using two Allen bolts (#27). Then puter console (#7-1).
  • Page 5 NB 3000 EXERCISE BIKE ASSEMBLY INSTRUCTIONS STEP 6: Installing Seat STEP 7: Installing Pedals & Straps Secure the seat (#5) onto the seat post (#3) by tightening the hex nut below the Attach the pedals (#10-1[L] and #10-1[R]) to crank (#4) using supplied wrench. The seat frame.
  • Page 6 NB 3000 EXERCISE BIKE Final Check Assembly of your Nautilus bike is now complete. Check again to insure that all parts are properly installed and that all nuts and bolts are completely secured. Get on the bike and check to see that the computer console and resistance system are working properly.
  • Page 7 The Nautilus Group 1886 Prairie Way Louisville, Colorado 80027 1.888.471.0014 www.nautilus.com Rev.C...
