Omega Excalibur AL-1000SH Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

"WE'VE GOT THE EDGE ON SECURITY"
OWNER'S MANUAL
SH
MODEL: AL-1000
COPYRIGHT: OMEGA RESEARCH & DEVELOPMENT INC.1997

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Excalibur AL-1000SH and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Omega Excalibur AL-1000SH

Summary of Contents for Omega Excalibur AL-1000SH

  • Page 1 "WE'VE GOT THE EDGE ON SECURITY" OWNER'S MANUAL MODEL: AL-1000 COPYRIGHT: OMEGA RESEARCH & DEVELOPMENT INC.1997...

  • Page 2: Table Of Contents

    T T T T T able Of Contents able Of Contents able Of Contents able Of Contents able Of Contents Note: This manual is written under the assumption that an optional door lock interface and an auxiliary sensor are installed with your Excalibur vehicle security system. Transmitter Features ..................4 Transmitter Operations ..................6 Arming The System Using The Transmitter ............7...
  • Page 3 Congratulations on your purchase of your new Excalibur security system and on joining over 8 million people worldwide who have trusted their vehicle's security to the designers of Omega Research & Development, Inc. To learn how to operate your security system, please become familiar with the following three principal user components: the Remote Transmitter, the Red LED Status Indicator and the Easy Valet Switch.

  • Page 4: Transmitter Features

    The Easy Valet Switch: This switch prevents the security system from arming during extended stopovers at service stations, valet parking, car washes, etc. The Valet Switch is also used to temporarily override and disarm your security system in the event you lose your transmitter and to initiate the transmitter code learning process. The Red LED Status Indicator: Informs you of 12 possible conditions the security system can be in and also serves as a visual deterrent to break-ins and theft.
  • Page 5 transmitters are coded to operate your system. In the event the system alerts you to a recent transmitter addition, or if the LED Status Indicator flashes a total different from the number of transmitters you have programmed to operate your system, you can now immediately reprogram your transmitters, effectively erasing any unauthorized transmitters.

  • Page 6: Transmitter Operations

    T T T T T r r r r r ansmitter Oper ansmitter Oper ansmitter Operations ansmitter Oper ations ations ations ansmitter Oper ations Small Left Transmitter Green LED Light- Illu- Large Transmitter But- Button- If this button is minates and confirms ton- Pressing and releasing pressed and then the large transmission whenever a...

  • Page 7: Arming The System Using The Transmitter

    Arming Arming T T T T T he System Using Arming he System Using he System Using T T T T T he he System Using he he he he T T T T T r r r r r ansmitter ansmitter ansmitter Arming...

  • Page 8: Passive System Arming By "Last Door Arming

    the small left transmitter button within 3 seconds after pressing the large transmitter button when arming the system. You will hear a second siren chirp, confirming the security system has armed without the sensor circuit protecting the vehicle. The next time you arm the security system, the system will reset to its normal condition, and the optional sensor will again be part of your protection.

  • Page 9: Security System Armed And Triggered

    transmitter, because all protected entries must be closed prior to the Automatic Last Door Arming sequence to start. Note: To prevent the system from automatically arming while the vehicle is being refueled you should put the system in Valet Mode (page 14), keep your door open or turn on your dome light switch so that the system thinks your door is still open.

  • Page 10: Disarming The System Using The Transmitter

    sensor still in a triggered state at the end of the 60 seconds, the system will retrigger for two more 60 second cycles. Should this occur the system will stop after a total of 3 minutes, while ignoring only the open entry or triggered circuit. Should the entry be closed, protection will begin instantly for that circuit.
  • Page 11 turning on for 30 seconds, except under the following conditions: 1) the lights will turn off 10 seconds after a door has been opened, or 2) the lights will turn off instantly if the ignition switch is turned "on". Note: If the system was triggered and reset while you are away, the disarm confirmation will change to 4 siren chirps, 4 light flashes, and then the lights will stay on for 30 seconds, to illuminate the way to your vehicle.

  • Page 12: Remote Panic Feature

    rearm itself after 90 seconds and once again lock the doors. This feature is programmable and in some cases may be turned off. See your Excalibur dealer or installer for details. Note: Automatic Rearming can be paused by opening the door or stopped by turning "on" the ignition key. Note: Automatic Rearming is confirmed by a fast flashing LED Status Indicator after disarming, unless the system was triggered and reset, in which case a Zone Violation code will flash instead.

  • Page 13: Optional Trunk Release And 3Rd Channel Output

    flashing the exterior and interior lights for 60 seconds. Should wish to enter your vehicle or disengage Remote Panic, simply press and release the large transmitter button. Optional Optional T T T T T r r r r r unk Release Optional unk Release unk Release...

  • Page 14: Using The Easy Valet Switch

    Using Using Using T T T T T he Easy he Easy he Easy he Easy V V V V V alet alet alet alet Switc Switc Switch h h h h Using Using he Easy alet Switc Switc The primary function of the Easy Valet Switch is to enter your security system into Valet Mode, which prevents the system from arming.

  • Page 15: Red Led Status Indicator

    feature, the doorlocks, and trunk release; the doors will also lock when the ignition switch is turned "on" and unlock when it is turned "off"'. Note: While the security system is in the Valet Mode, every time the ignition switch is turned "off", the siren will chirp once as a reminder.
  • Page 16 observed by the driver. There are 12 possible conditions that the security system can be in, and are reflected by the LED Status Indicator: 1) Off = The security system is disarmed and not performing any automatic functions. 2) On Constant = The security system is in the Valet Mode.

  • Page 17: Electronic Siren And Flashing Lights

    Zone Violation: If the system is triggered, the LED Status Indicator will start to flash and pause the #9 through #12 sequences to indicate which protected circuit triggered the system. This is seen while the system is armed, and after disarming, until the ignition switch is turned "on", which will clear the Zone Violation code from the security system's memory.
  • Page 18 and off. If connected to the security system, a reduction of their useful life may be noticed. Siren Chirp With Light Flash Confirmation For Arming, Disarming & Valet Activation: The following siren chirps and flashing exterior light actions inform you of these conditions of the security system: 1) One siren chirp and one light flash: The system has armed.

  • Page 19: Backup Battery

    9) Siren sounding, changing sounds every 5 seconds, and lights flashing on and off: The system is in a triggered state. 10) One siren chirp (and no lights) when the ignition switch is turned "off": The security system is in Valet Mode. 11) Three siren chirps (and no lights) while the security system is armed: The Prewarn feature has been activated.

  • Page 20: Impact And Glass Sensor With Prewarn Feature

    anywhere batteries are sold. We recommend the battery be replaced with another alkaline battery every 18 months or after the 9 volt battery has operated the alarm on its own for any length of time. Under the following conditions, a new 9 volt alkaline battery's life is anticipated to be approximately: 1.
  • Page 21 available which include those that monitor shock to the vehicle, detect changes in atmospheric pressure within the vehicle, and radar sensors that can detect motion inside and outside the vehicle. The sensor may be temporarily bypassed using the transmitter, which is described on page 7. The following differences in operation of the two auxiliary sensor ports concerning the sensor bypass feature should be noted: Port #1, which is on the corner of the security system control module, will have both the negative instant trigger and...

  • Page 22: Programming Transmitters

    triggered by a sensor plugged into Port #2 the Zone Violation feature will flash the LED Status Light twice between pauses. Prewarning Shock Detection Circuit: This circuit requires connection to an auxiliary detection sensor device. When the sensor is triggered by a light impact or shock to the vehicle, the security system will respond by chirping the siren 3 times and locking all of the doors.
  • Page 23 3) Repeat this procedure for each transmitter desired to operate the security system. The system will chirp once to confirm that each transmitter code was learned. Both of the other two transmitter button's functions will automatically be learned when the arm / disarm button is learned. If a code is not received within a 10 second period, the learning process will automatically terminate.

  • Page 24: Programmable Features

    Programmable Features Programmable Features Programmable Features Programmable Features Programmable Features Your vehicle security system has 18 programmable features that allow your system to be customized to fit your personal needs. To program these features "on" or "off", follow this process: 1) Turn "off"...
  • Page 25 Feature #1: Anti-Carjacking Protection. (Factory Setting: OFF) Feature Turned On: After turning the ignition switch "on" and starting the vehicle, you must press the Easy Valet switch within 60 seconds. If the valet switch is not pressed the security system will begin chirping 53 seconds after the ignition was turned "on".
  • Page 26 Feature #3: Automatic Last Door Arming. (Factory Setting: ON) Feature Turned On: The security system will arm itself automatically when the vehicle's last door is closed. At the moment the last door is closed the siren will chirp, the exterior lights will flash once, and the Status LED will flash fast. Thirty seconds later the siren will chirp once again, the lights will flash, and the Status LED will flash slow, indicating that the security system is fully armed.
  • Page 27 Feature #5: Current Sensing. (Factory Setting: ON) Feature Turned On: When the security system is armed, current sensing can detect a positive current draw from the vehicle's battery. (Example: the dome light comes on when a door is opened or the brake lights come on when the brake pedal is pressed).
  • Page 28 Feature #9: Lights Stay On 30 Or 60 Seconds Upon Disarming: (Factory Setting OFF) Feature Turned On: Upon disarming, the exterior (and interior if connected) lights will stay on for 60 seconds, illuminating the way to your vehicle. Feature Turned Off: The exterior (and interior if connected) lights will stay on for 30 seconds when the system is disarmed.
  • Page 29 Feature #11: The Security System Will Also Disarm Upon Trunk Release: (Factory Setting ON) Feature Turned On: When the trunk release feature is utilized, the security system will also disarm at the same time, chirping the siren twice, unlocking the doors and turning the exterior lights on for thirty or sixty seconds.
  • Page 30 Feature #14: 3 Or 45 Second Fully Armed Delay: (Factory Setting ON) Feature Turned On: The security system will be become fully armed 3 seconds after the arming siren chirp confirmation. Feature Turned Off: The security system will be become fully armed 45 seconds after the arming siren chirp confirmation.
  • Page 31 Feature Turned "Off": The security system will not have the audible indicator, in the form of siren chirps, indicating transmitter programming activity. However, the visual indication remains in the form of the LED Status Indicator, which will still flash the number of active transmitter codes for 10 seconds after the ignition is turned "on". Feature #17: Siren Sounds 30 Or 60 Seconds: (Factory Setting ON) Feature Turned On: Upon activation, the siren will sound for 60 seconds.

  • Page 32: Limited Lifetime Warranty

    Omega Research and Development, Inc.'s labor and return shipping, to the original owner during the lifetime of the car in which it was originally installed.
