GOLD SERIES
OWNER'S MANUAL
COPYRIGHT: OMEGA RESEARCH & DEVELOPMENT INC. 1998
Introduction
Congratulations on the purchase of your new Excalibur Gold security system and on
joining over 8 million people worldwide who have trusted their vehicle's security to the
designers of Omega Research & Development, Inc. Your Excalibur Gold system combines
state-of-the-art security technology with practical, user-friendly convenience features. You
will have increased peace of mind knowing that your vehicle, and its contents, are protected.
The added convenience features will also enhance the enjoyment and satisfaction of the day-
to-day use of your vehicle. To learn how to operate your security system, please become
familiar with the following three principal user components: the Remote Transmitter, the Red
LED Status Indicator and the Valet Switch.
The Remote Transmitter: Each security system comes with two pre-learned transmitters,
but can learn up to 4 different transmitters. The transmitter has three buttons: one large button
at the top, near the LED* and two smaller buttons below. This system is pre-programmed,
through a built-in learning routine, to have the transmitter buttons work in the following
configuration:
The large upper button is used to arm, disarm and panic the security system.
The small center button may be used to operate the trunk release feature; or, in
conjunction with the large button, for silent arming or disarming of the system, to operate
remote sensor bypass, and temporary remote valet.
The small lower button is used to operate the 3rd Channel Output.
The remote transmitter's operation is explained in more detail on Pages 7-9.
* LED is the abbreviation for Light Emitting Diode, which is used as a visual indicator.
1200
Page - 3
ATV
The Remote Transmitter ........................................................................................................................... 3
The Easy Valet
TM
Switch ............................................................................................................................. 4
The Red LED Status Indicator ................................................................................................................... 4
Transmitter Operations Overview ............................................................................................................ 7
Transmitter Button Operation .............................................................................................................. 8-9
Arming The System Using The Transmitter ........................................................................................... 9
Arming Bypass ....................................................................................................................................... 9-10
Sensor Bypass ............................................................................................................................................. 1 0
Passive System Arming By "Last Door Arming" ............................................................................10-11
Automatic Rearming ........................................................................................................................... 11-12
Security System Armed And Activated ............................................................................................. 12-13
Disarming The Security System Using The Transmitter ............................................................... 14-15
............................................................................................................................................... 1 5
Valet Override - Disarming The Security System Without The Transmitter .................................... 1 6
Exiting Valet Mode ................................................................................................................................... 1 6
Remote Panic Feature ............................................................................................................................... 1 7
Optional Trunk Release And 3rd Channel Output .......................................................................... 17-18
Prewarning Feature .................................................................................................................................... 2 1
Programmable Features ...................................................................................................................... 22-26
Limited Lifetime Warranty ..................................................................................................... Back Cover
The Valet Switch: This switch is used to place the system into Valet Mode, which prevents
manual arming and any automatic system functions which may have been programmed to
operate. The Valet Switch is also used, in conjunction with the ignition key, to perform an
Override function, which will allow you to disarm the security system in the event the
transmitter becomes inoperable. And finally, the Valet Switch is also used as part of the
Programmable Features and Transmitter Programming procedures.
The Red LED Status Indicator: Informs you of the possible conditions the security system
can be in; and also serves as a visual deterrent to break-ins and theft. The LED Status Indicator
is also used as the visual indicator for the Automatic Transmitter Verification
The Valet Switch and the Red LED Status Indicator are supplied with a consolidated
mounting enclosure, which places them together for ease of operation, or, if desired, they may
be located separately and mounted by alternative methods. Please spend time reviewing this
guide to become familiar with your Excalibur Gold vehicle security system. We trust that you
will find the new Excalibur Gold vehicle security system performs to your highest expectations,
and will provide you with years of trouble-free convenience and protection.
Please note that your new Excalibur Gold vehicle security system has 10 user and installer
Programmable Features, described in detail in a later section, which allows customizing the
system's operations, some to suit your personal needs, and others which adapt the system
to a particular vehicle's installation parameters.
Table Of Contents
TM
................................................................................................. 5-6
..................................................................................................................... 6
Page - 2
Page - 4
TM
Feature.
