Bosch D9000 Series Owner's Manual Supplement

Hide thumbs

Advertisement

Quick Links

D9000,G & GV2 Series
Owner's Manual Supplement
D9000, G & GV2
EN
Series

Advertisement

loading

  Summary of Contents for Bosch D9000 Series

  • Page 1 D9000,G & GV2 Series Owner’s Manual Supplement D9000, G & GV2 Series...
  • Page 2: Table Of Contents

    Access Level Control........10 10.0 Door Control ...........12 10.2 Using Door Control? ........12 10.3 Cycle Door? ..........13 10.4 Unlock Door?..........14 11.0 Delete User [COMMAND 53] ....15 12.0 Add/Change User - [COMMAND 56] ..17 12.1 Description............17 Bosch Security Systems | 5/05 | 33267F...
  • Page 3: 1.0 Introduction

    [passcode digits] followed by the [ENTER] key. The keypad shows a request for the SECOND CODE: Enter a second valid pass code with the authority to Passcode Disarm by pressing the [passcode digits] followed by the Bosch Security Systems | 5/05 | 33267F...
  • Page 4: Early Ambush

    [ENTER] key. The keypad shows confirmation that the second passcode was accepted and that the Early Ambush Window was canceled by showing CODE 2 VALIDATED. The area is disarmed and ready for entry. Bosch Security Systems | 5/05 | 33267F...
  • Page 5: Easy Exit Control

    Ensure the keypad shows idle perimeter armed text. Press the [COMMAND] key. The keypad shows SYSTEM COMMAND. Press [1] to Master Arm. The keypad shows the Exit Delay count down. Enter or exit the premises. Bosch Security Systems | 5/05 | 33267F...
  • Page 6: Passcode Follows Scope

    Enter your code by pressing the [passcode digits] followed by the [ENTER] key. The keypad shows ARMING: 12345678, to indicate which areas are about to enter exit delay and arm. The keypad shows the exit delay count down. Exit the premises. Bosch Security Systems | 5/05 | 33267F...
  • Page 7: Passcode-Controlled Menu

    Press the [ESC] key. The keypad responds with the ENTER PASSCODE display. Enter your code by pressing the [passcode digits] followed by the [ENT] key. The first menu item that you have authority to use appears. Bosch Security Systems | 5/05 | 33267F...
  • Page 8: Invisible Walk Test

    Press the [ENT] key to view the untested points. The keypad shows the total number of untested invisible points within the keypad scope: ### PTS UNTESTED. Press the [NEXT] key to view the first point’s name. Bosch Security Systems | 5/05 | 33267F...
  • Page 9 Next PT> <Exit Prev PT> Where [Point State] can be NORMAL,OPEN,SHORT, or MISSNG. Activate the point’s sensor and observe the appropriate state change. Repeat Steps 5 through 8 until all points are tested. Bosch Security Systems | 5/05 | 33267F...
  • Page 10: Door Activated Custom Function

    Use this function to manually enable or disable access authority levels assigned to users. This function can be used to temporarily disable a user’s access level instead of deleting and adding the user. I have this feature. I do not have this feature. Bosch Security Systems | 5/05 | 33267F...
  • Page 11 If the access level is currently disabled, LEVEL # ENABLE? appears. If the access level is currently enabled, LEVEL DISABLE? appears. Press [ENT] to accept the choice. ENTER LEVEL: appears again. Press [ESC]. Bosch Security Systems | 5/05 | 33267F...
  • Page 12: 10.0 Door Control

    Press the [MENU] key to enter the Function List. Press [NEXT] repeatedly until you reach the DOOR CTRL? prompt. Press [ENT]. The first sub-function that appears is CYCLE DOOR? You can cycle through the three sub-functions by pressing [PREV] and [NEXT]. Bosch Security Systems | 5/05 | 33267F...
  • Page 13: Cycle Door

    CYCLE DOOR 1 2 C 4 5 6 7 8 This indicates that all doors are in a normal state, except for Door 3, which is cycled. Press [ESC] to leave this subfunction, or enter another door number to cycle. Bosch Security Systems | 5/05 | 33267F...
  • Page 14: Unlock Door

    For example, to secure Door 5, at the following prompt: SECURE DOOR 1 2 3 4 5 6 7 8 Press [5] then [ENT]. The display shows: SECURE DOOR 1 2 3 4 X 6 7 8 Bosch Security Systems | 5/05 | 33267F...
  • Page 15: Delete User [Command 53]

    I have this feature. I do not have this feature. 11.2 Using DEL USER ? Ensure the display shows idle disarmed text. Press the [COMMAND] bar. The display shows SYSTEM COMMAND. Press [5] and [3]. Bosch Security Systems | 5/05 | 33267F...
  • Page 16 The display shows DELETE USER ##? Press [ENT] to delete user, and USER DELETED appears. If the user number is not in the system, NOT IN USE appears. If you made an error and do not wish to delete this user, press [ESC]. Bosch Security Systems | 5/05 | 33267F...
  • Page 17: Add/Change User - [Command 56]

    Press [ENT] if the correct user number (or user name) appears. Press [ESC] if not. ADD PASSCODE? appears (If the user number already exists, CHANGE PASSCODE? appears). Press [ENT]. ENTER NEW CODE Bosch Security Systems | 5/05 | 33267F...
  • Page 18 8 and 9 for each area (up to 8 areas). LEVEL ADDED (or LEVEL CHANGED) appears when all area assignments are made. Press [ENT]. Bosch Security Systems | 5/05 | 33267F...
  • Page 19 CARD ADDED (or CARD CHANGED if the Sub User number already existed). At the end of each function, press [ESC] to return to the ENTER USER # prompt. Press [ESC] again to return to idle text. Bosch Security Systems | 5/05 | 33267F...
  • Page 20 Bosch Security Systems 130 Perinton Parkway Fairport, NY 14450-9199 Customer Service: (800) 289-0096 Technical Support: (888) 886-6189 © 2005 Bosch Security Systems 33267F...
