Optical Drive
Dell™ OptiPlex™ XE Service Manual—Small Form Factor
WARNING: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.

Removing the Optical Drive

NOTE: You may need to install Adobe® Flash® Player from Adobe.com in order to view the illustrations below.
1. Follow the procedures in Before Working Inside Your
2. Disconnect the power and data cables from the optical drive.
3. Push down on the drive release latch to release the optical drive from the computer.
4. Slide the optical drive toward the back of the computer and lift up to remove it from the computer.

Replacing the Optical Drive

To replace the optical drive, perform the above steps in reverse order.
Back to Contents Page
Computer.
