Removing The Fan; Replacing The Fan - Dell OptiPlex XE Small Form Factor Service Manual

Back to Contents Page
Fan
Dell™ OptiPlex™ XE Service Manual—Small Form Factor
WARNING: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.

Removing the Fan

NOTE: You may need to install Adobe® Flash® Player from Adobe.com in order to view the illustrations below.
1. Follow the procedures in Before Working Inside Your
2. Remove the optical drive.
3. Remove the hard drive assembly.
4. Disconnect the fan cables from the system board.
5. Remove the screws that secure the fan to heat sink assembly.
6. Remove the fan from the computer.

Replacing the Fan

To replace the fan, perform the above steps in reverse order.
Back to Contents Page
Computer.
