CrimeStopper SV-6930.LM.IR Installation Instructions

WATERPROOF CAMERA
FEATURE
1. Waterproof without extra housing needed.
2. Night vision available.
3. IR distance: 3m ~ 5m.
4. Yellow socket is for video output.
5. Power socket is connected to DC 12V.
Image Device
TV System
Effective Pixels
Sensing Area
Scanning System
Sync. System
Resolution
Horizontal Sync Frequency
Vertical Sync Frequency
Minimum Illumination
Video Output
Gamma Consumption
AGC
S/N Ratio
White Balance
Electronic Shutter
BLC
Current Consumption
Power Supply
Operating Temperature
Storage Temperature
Lens
Lens Angle
1/3" SHARP SENSOR CCD
PAL NTSC
512×582pixels 512×492 pixels
4.9mm×3.7mm
2:1 Interlace
Internal
420TV Lines
15,625 kHz 15,734 kHz
50 Hz 60 Hz
0 Lux / F2.0
1.0Vp-p, 75Ohm
0.45
Auto
Better than 48dB
Auto
1/50(PAL)or1/60(NTSC) ～1/10,000 Second
Auto
Max. 200mA
DC12V
–20℃ ~ 70℃, RH95%MAX
–40℃ ~ 80℃, RH95%MAX
f=3.8mm / F=2.0
95°
